GB/T 15110.2-2023: Register systems for photographic materials, foils and paper - Part 2: Register pin systems for plate making

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
ICS 37.100.10 CCSJ87 National Standards of People's Republic of China Registration systems for photosensitive materials, foils and papers Part 2.Pin positioning systems for plate making Released on 2023-03-17 2023-10-01 implementation State Administration for Market Regulation Released by the National Standardization Management Committee

foreword

This document is in accordance with the provisions of GB/T 1.1-2020 "Guidelines for Standardization Work Part 1.Structure and Drafting Rules for Standardization Documents" drafting. This document is the second part of GB/T 15110 "Registration system for photosensitive materials, foils and paper". GB/T 15110 has been issued The following sections. --- Part 2.Pin positioning system for plate making. This document is equivalent to ISO 11084-2.2006 "Registration system for photosensitive materials, foils and papers in printing technology - Part 2.Manufacturing version of the Pin Positioning System". The following minimal editorial changes have been made to this document. --- In order to coordinate with the existing standard, the name of the standard is changed to "Registration system for photosensitive materials, foils and paper - Part 2.Pins for plate making Positioning System". This document is proposed by China Machinery Industry Federation. This document is under the jurisdiction of the National Printing Machinery Standardization Technical Committee (SAC/TC192). This document is drafted by. Shenzhen Vocational and Technical College, Guangzhou Qiancai Paper Printing Co., Ltd., China Printing Science and Technology Research Institute Co., Ltd., Zhuhai Huijin Quality Standard Technology Co., Ltd., Shenzhen Yuya Technology Co., Ltd., Ruian Chuangbo Machinery Co., Ltd., Guangdong Province Dongguan Quality and Technology Supervision Standard and Coding Institute, Xi'an University of Technology, Guangzhou Tiansheng Printing Co., Ltd., Guangdong Printing and Reproduction Industry Association, Beijing Gaoke Printing Machinery Research Institute Co., Ltd. The main drafters of this document. Xu Xiangyang, Wu Wei, Zheng Mengjun, Yang Qian, Bi Mingzhu, Long Xiaodong, Li Xia, Liu Shanhui, Hou Heping, Li Jiong, Lan Yun, Yu Jie, Chen Yongcheng, Luo Ruiqiu, Huang Shaoyan, Peng Ming. GB/T 15110.2-202×/ISO 11084-2.2006

Introduction

In printing technology, standardization of registration systems can lead to greater adoption by reducing the variety of dowel systems required for prepress operations. economy and efficiency. This approach helps reduce the number of errors and consumable usage. GB/T 15110 aims to establish the The positioning pin of the system is proposed to be composed of two parts. --- Part 1.Three-pin positioning system. The purpose is to establish the size and position of the pins and holes in the three-pin positioning system to realize the original, Precise positioning of color separations and printing plates on presses and prepress equipment. This part will adopt ISO 11084-1.1993 "Printing technology Registration systems for technical photosensitive materials, foils and papers - Part 1.Triple pin positioning system", instead of equivalent use ISO 11084. GB/T 15110-1994 "Printing Positioning System" in.1993. --- Part 2.Pin positioning system for plate making. The purpose is to establish the shape, size and position of the pins and holes in the double pin positioning system. In order to achieve precise image positioning on the printing plate during the plate making operation. This document specifies the dowel structure of the double pin locating system using a metal base plate, describes the shape and size of the pins and holes in the double pin system and location. Since the printing machine uses a variety of special positioning pin arrangements to achieve rapid and accurate positioning of the printing plate, this document is mainly applicable to This document specifies the use of the system to ensure precise positioning of images on printing plates and The bending plate is accurate when brushing and loading. This document also applies to switchable dowel systems that can be switched between different dowel arrangements. GB/T 15110.2-202×/ISO 11084-2.2006 Registration systems for photosensitive materials, foils and papers Part 2.Pin positioning systems for plate making

1 Scope

This document specifies the shape, size and location of pins and holes in dowel pin systems, which are used in plate-making operations during printing plate-making Accurate image positioning on the printing plate. This document also applies to bending machines and switchable types that need to be converted between different pin positioning systems Locating pin system. This document is applicable to the pre-press pin positioning system with a printing plate size of 420mm×594mm (A2) during plate making, and is also applicable to printing presses A pin-type positioning system similar to the above.

2 Normative references

The contents of the following documents constitute the essential provisions of this document through normative references in the text. Among them, dated references For documents, only the version corresponding to the date is applicable to this document; for undated reference documents, the latest version (including all amendments) is applicable to this document. ISO 11084-1 Registration systems for photosensitive materials, foils and papers in printing technology - Part 1.Triple pin positioning system (Graphic tems)

3 Terms and Definitions

The terms and definitions defined in ISO 11084-1 and the following apply to this document. 3.1 Positioning hole registerhole Round or elongated holes that require mutual alignment (positioning) in one or more materials. 3.2 punching centerline punchingcentreline A line passing through the centers of the two punched positioning holes (3.1). 3.3 long positioning hole slottedregisterhole Positioning holes (3.1) with parallel sides, the length of the hole is greater than the width of the hole, and the two ends can be curved or square.

4 requirements

4.1 Arrangement of positioning holes and positioning pins The locating system specified in this document is a double pin system for creating a circular locating hole and a long locating hole in the material. between holes GB/T 15110.2-202×/ISO 11084-2.2006 ......
