US$449.00 · In stock
Delivery: <= 4 days. True-PDF full-copy in English will be manually translated and delivered via email.
GB/T 43511-2023: Railway application - Electric traction overhead conductor rail
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 43511-2023	449	Add to Cart	4 days	Railway application - Electric traction overhead conductor rail	Valid

Similar standards

TB/T 2809 TB/T 3111 TB/T 2075.13 GB/T 25020.1 GB/T 25020.2

Basic data

Standard ID: GB/T 43511-2023 (GB/T43511-2023)
Description (Translated English): Railway application - Electric traction overhead conductor rail
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: S82
Classification of International Standard: 29.280
Word Count Estimation: 22,292
Date of Issue: 2023-12-28
Date of Implementation: 2024-04-01
Issuing agency(ies): State Administration for Market Regulation, China National Standardization Administration

GB/T 43511-2023: Railway application - Electric traction overhead conductor rail

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
ICS 29:280 CCSS82 National Standards of People's Republic of China Rail transit electric traction overhead rigid catenary Published on 2023-12-28 2024-04-01 Implementation State Administration for Market Regulation Released by the National Standardization Administration Committee

PrefaceⅠ 1 Scope 1 2 Normative references 1 3 Terms and Definitions 2 4 symbols 3 5 Application conditions 3 6 System composition and technical requirements 5 7 Equipment and Parts Requirements 7 8 Test methods 8 9 Inspection Rules 11 Appendix A (informative) Environmental temperature value of rigid contact network in electrified railway tunnel 14 Appendix B (informative) Supporting device load calculation example 15 Reference 18

Foreword

This document complies with the provisions of GB/T 1:1-2020 "Standardization Work Guidelines Part 1: Structure and Drafting Rules of Standardization Documents" Drafting: Please note that some content in this document may be subject to patents: The publisher of this document assumes no responsibility for identifying patents: This document is proposed by the National Railway Administration: This document is under the jurisdiction of the National Rail Transit Electrical Equipment and Systems Standardization Technical Committee (SAC/TC278): This document was drafted by: China Railway First Survey and Design Institute Group Co:, Ltd:, Guangzhou Metro Group Co:, Ltd:, China Railway Electrification Bureau Group Co:, Ltd:, China Academy of Railway Sciences Group Co:, Ltd: The main drafters of this document: Zhao Wei, Gong Yansheng, Jin Shoujie, Huang Deliang, Luo Bing, Guo Fengping, Han Tongxin: Rail transit electric traction overhead rigid catenary

1 Scope

This document specifies the application conditions, system composition and technical requirements, equipment and components of rail transit electric traction overhead rigid contact network Requirements, inspection rules, and test methods for rail transit electric traction overhead rigid catenaries are described: This document is applicable to rail transit electric traction overhead rigid contact network with operating speed of 160km/h and below (hereinafter referred to as "rigid contact network"): The design, construction, testing, acceptance and operation of "Touching the Internet"):

2 Normative reference documents

The contents of the following documents constitute essential provisions of this document through normative references in the text: Among them, the dated quotations For undated referenced documents, only the version corresponding to that date applies to this document; for undated referenced documents, the latest version (including all amendments) applies to this document: GB/T 19443-2017 Insulators for overhead lines with nominal voltage higher than 1500V Porcelain or glass insulators for DC systems String component definitions, test methods and acceptance criteria GB/T 22707 Artificial contamination test of high-voltage insulators for DC systems GB/T 26869-2011 Test of organic material pillar insulators in systems with nominal voltage higher than 1000V and lower than 300kV GB/T 28026:3-2018 Electrical safety, grounding and return current of rail transit ground installations Part 3: AC and DC traction Interactions of power supply systems GB/T 32347:2 Environmental conditions for rail transit equipment Part 2: Ground electrical equipment GB/T 32350:1-2015 Rail transit insulation coordination Part 1: Basic requirements for electrical clearances and electronic equipment Creepage distance GB/T 32578-2016 Electric traction overhead catenary for rail transit ground installations GB/T 32586-2016 Specific requirements for composite insulators for electric traction overhead catenary systems for rail transit ground installations GB 50009 Code for load of building structures GB 50010 Specification for design of concrete structures GB 50017 steel structure design standards GB 50157-2013 Subway design specifications CJJ/T 288-2018 Technical Standard for Overhead Catenary Networks for Urban Rail Transit TB/T 2073-2020 Technical conditions for electrified railway catenary components TB/T 2074-2020 Test methods for electrified railway catenary components TB/T 2809-2017 Copper and copper alloy contact wires for electrified railways TB/T 3036-2016 Segmented insulators for electrified railway contact networks TB/T 3199:1-2018 Insulators for electrified railway contact networks - Part 1: Rod-shaped porcelain insulators TB/T 3199:2-2018 Insulators for electrified railway contact networks Part 2: Rod composite insulators TB/T 3252-2022 Electrified railway rigid suspension contact network busbars and components TB10009-2016 Design specifications for railway electric traction power supply ......
