GB/T 41771.5-2022: Field device integration - Part 5: Information model
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 41771.5-2022	984	Add to Cart	8 days	Field device integration - Part 5: Information model	Valid

Similar standards

GB/T 41295.3 GB/T 41295.2 GB/T 41295.4 GB/T 41771.6 GB/T 41771.7 GB/T 41771.2

Basic data

Standard ID: GB/T 41771.5-2022 (GB/T41771.5-2022)
Description (Translated English): Field device integration - Part 5: Information model
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: N10
Classification of International Standard: 25.040
Word Count Estimation: 54,536
Date of Issue: 2022-10-12
Date of Implementation: 2023-05-01
Issuing agency(ies): State Administration for Market Regulation, China National Standardization Administration

GB/T 41771.5-2022: Field device integration - Part 5: Information model

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Field device integration - Part 5.Information model ICS 25.040 CCSN10 National Standards of People's Republic of China Field Device Integration Part 5.Information Model Released on 2022-10-12 2023-05-01 implementation State Administration for Market Regulation Released by the National Standardization Management Committee

Preface III Introduction IV 1 Scope 1 2 Normative references 1 3 Terms and Definitions, Abbreviations and Conventions 2 3.1 Terms and Definitions 2 3.2 Abbreviations 2 3.3 Convention 3 3.4 Conventions of graphic symbols 3 4 OPC Unified Structure Overview 4 4.1 Overview 4 4.2 Overview of OPCUA Devices 5 5 Concept 6 5.1 Overview 6 5.2 Device topology 6 5.3 Online/Offline 8 5.4 Catalog (type definition) 8 5.5 Communication 8 6 AddressSpace Organization 8 7 FDI device model 9 7.1 Overview 9 7.2 Online/Offline 9 7.3 Device Health 10 7.4 User interface elements 11 7.5 Type-specific supporting information 14 7.6 Action 14 8 Networking and Connectivity 19 9 Useful functions 19 9.1 Overview 19 9.2 Locking 19 9.3 EditContext 19 9.4 Direct Device Access 25 10 parameter type 29 10.1 Overview 29 10.2 ScalingFactor properties 30 10.3 Min_Max_Values property 30 11 FDI status code 31 12 Dedicated topology elements 32 13 Audit 32 13.1 Overview 32 13.2 Relevant information provided by FDI clients 33 14 FDI Server Version 33 15 Mapping FDI package information to the FDI information model 34 15.1 Overview 34 15.2 Localization 34 15.3 Equipment 34 15.4 Modular equipment 36 15.5 blocks 36 15.6 Parameters 37 15.7 Function group 44 15.8 AXIS elements in UIDs 45 15.9 Action 45 15.10 UIPs 46 15.11 Protocols, networks, and joinpoints 46 16 Profile 46 Appendix A (Informative) Namespaces and Mappings 47 Reference 48

foreword

This document is in accordance with the provisions of GB/T 1.1-2020 "Guidelines for Standardization Work Part 1.Structure and Drafting Rules for Standardization Documents" drafting. This document is Part 5 of GB/T 41771 "Field Device Integration". GB/T 41771 has issued the following parts. --- Part 1.Overview; --- Part 2.Client; --- Part 3.Server; --- Part 4.Package; --- Part 5.Information Model. This document is equivalent to IEC 62769-5.2021 "Field Device Integration (FDI) Part 5.Information Model". The following minimal editorial changes have been made to this document. --- Modify the standard name to "Field Device Integration Part 5.Information Model"; --- Move the informative referenced IEC 62541-6 from Chapter 2 into references; --- Include the normative referenced IEC 61804-4 in Chapter 2. Please note that some contents of this document may refer to patents. The issuing agency of this document assumes no responsibility for identifying patents. This document is proposed by China Machinery Industry Federation. This document is under the jurisdiction of the National Industrial Process Measurement Control and Automation Standardization Technical Committee (SAC/TC124). This document is drafted by. Zhejiang Datang Wushashan Power Generation Co., Ltd., Harbin Institute of Technology Robot Group Hefei Co., Ltd., Machinery Industry Institute of Comprehensive Technology and Economics of Instrumentation, Fujian Shunchang Hongrun Precision Instrument Co., Ltd., Wuxi Internet of Things Innovation Center Co., Ltd., Beijing Automec Technology Co., Ltd., Harbin Institute of Technology Robotics (Yueyang) Military-civilian Integration Research Institute, Beijing University of Technology, Shenzhen Biaoli Technology Development Co., Ltd. Development Co., Ltd., Southwest University, Shanghai Automation Instrument Co., Ltd., Shanghai Institute of Metrology and Testing Technology, Hunan University of Science and Technology, FCG Now Field Communication Group, CITIC Dicastal Co., Ltd., Beijing Institute of Technology, Fujian Shangrun Precision Instrument Co., Ltd., Schneider Electric (China) Co., Ltd. Co., Ltd., Chongqing Chuanyi Automation Co., Ltd., Torch High-tech Industry Development Center of the Ministry of Science and Technology, ZTE Changtian Information Technology (Nanchang) Co., Ltd., Heilan Zhiyun Technology Co., Ltd., Beijing Zhengheshan Standardization Consulting Firm (Limited Partnership), Siemens Industrial Software (Shanghai) Co., Ltd., Rockwell Automation (China) Co., Ltd., Chongqing University of Posts and Telecommunications. The main drafters of this document. Zhou Baozhu, Lu Tielin, Li Wenxing, Chen Zhiyang, Dong Jielian, Liu Xiaojing, Wu Yuxiao, Zhou Fengwei, Li Yong, Ren Junmin, Liu Feng, Zhao Yong, Zhang Yi, Cheng Jixun, Wang Jun, Huang Liang, Kong Lingqin, Ge Jian, Yan Xinhua, Tian Yingming, Fan Zitian, Huang Huiying, Xu Guoping, Chen Dapeng, Zheng Qiaoying, Zhang Xiaoxia, Dong Libin, Yue Lei, Gao Jingmei, Huang Qingqing.

Introduction

The field device integration series standards are important technical standards to guide related activities such as industrial process measurement and control. GB/T 41771 aims to Establish the normative criteria applicable to equipment integration, which is proposed to be composed of 15 parts. --- Part 1.Overview. The purpose is to define the concept and overview of field device integration specifications. --- Part 2.Client. The purpose is to specify the relevant requirements for field device integration clients. --- Part 3.Server. The purpose is to specify the relevant requirements for field device integration servers. --- Part 4.Package. The purpose is to build a field device integration package model that provides the integration of devices, network components and communication servers into All elements required by the system. --- Part 5.Information Model. The purpose is to specify the topology of the automation system, used to describe the equipment and communication of the automation system Connect Network. --- Part 6.Technology Mapping. The purpose is to specify the technical mapping of the concepts described in field device integration; --- Part 7.Communication equipment. The purpose is to specify the elements that implement the communication capability. --- Part 8.General protocol of the profile. The purpose is to specify the required communication servers, gateways and devices described by the field device integration package Details of the general protocol. --- Part 9.Profile Foundation Fieldbus H1.The purpose is to specify the field device integrated communication of H1 fieldbus technology regulation. --- Part 10.Profile Foundation Fieldbus HSE. The purpose is to specify the field device integration communication of HSE fieldbus technology letter rules. --- Part 11.Profile PROFIBUS. The purpose is to specify the field device integration communication profile of PROFIBUS technology. --- Part 12.Profile PROFINET. The purpose is to specify the field device integration communication profile of PROFINET technology. --- Part 13.Profile HART and WirelessHART. The purpose is to specify the HART and WirelessHART technology Field device integration communication profile. --- Part 14.Profile Modbus-RTU. The purpose is to specify the field device integration communication profile of Modbus-RTU technology. --- Part 15.Profile ISA100.The purpose is to specify the field device integration communication profile of ISA100 technology. Field Device Integration Part 5.Information Model

1 Scope

This document specifies the FDI information model. One of the main tasks of the information model is to reflect the topology of the automation system. Therefore, letter The information model represents the equipment of the automation system and the communication connection network. The network of communication links consists of properties, relationships, and The action to perform. The types in the AddressSpace of the FDI server constitute some sort of FDI package-generated directory. The basic type of device FDI information model is defined in OPCUA (IEC 62541-100). The FDI information model specifies some characteristics example, and explains how to use these types and how to generate content from elements of DevicePackages. The entire FDI architecture is shown in Figure 1.Architectural components within the scope of this document are indicated in darker colors in the figure. Figure 1 FDI Architecture Diagram
