GB/T 41771.2-2022 English PDF

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 41771.2-2022	RFQ	ASK	3 days	Field device integration - Part 2: Client	Valid

Similar standards

GB/T 41295.3   GB/T 41295.2   GB/T 41295.4   GB/T 41771.6   GB/T 41771.7   GB/T 41771.3

Basic data

Standard ID: GB/T 41771.2-2022 (GB/T41771.2-2022)
Description (Translated English): Field device integration - Part 2: Client
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: N10
Classification of International Standard: 25.040
Word Count Estimation: 134,195
Date of Issue: 2022-10-12
Date of Implementation: 2023-05-01
Issuing agency(ies): State Administration for Market Regulation, China National Standardization Administration

GB/T 41771.2-2022: Field device integration - Part 2: Client

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Field device integration - Part 2.Client ICS 25.040 CCSN10 National Standards of People's Republic of China Field Device Integration Part 2.Client Side Released on 2022-10-12 2023-05-01 implementation State Administration for Market Regulation Released by the National Standardization Management Committee

table of contents

Preface III Introduction IV 1 Scope 1 2 Normative references 1 3 Terms, Definitions, Abbreviations and Conventions 2 3.1 Terms and Definitions 2 3.1.1 Terms used for services2 3.1.2 Terms used for device access services3 3.2 Abbreviations 3 3.3 Convention 3 4 Overview 3 5 FDI Client 4 5.1 Device Access Service 4 5.1.1 Overview 4 5.1.2 Device model 5 5.1.3 Node model 6 5.1.4 Services 11 5.1.5 Basic feature service 16 5.1.6 Device model service 17 5.1.7 Locking service 28 5.1.8 Direct Access (DirectAccess) service 30 5.1.9 Data types 33 5.2 Hosting Services 38 5.2.1 Overview 38 5.2.2 Services 38 5.2.3 Parameter type specification 49 6 UIP 51 6.1 UIP service 51 6.1.1 Services 51 6.1.2 Parameter type specification 54 6.2 UIP instantiation rules 56 6.3 UIP state machine 56 6.3.1 State 56 6.3.2 State transitions 57 6.4 UIP Permissions and Restrictions 58 6.4.1 Introduction 58 6.4.2 Accessing the local file system 58 6.4.3 File export/import 58 6.4.4 Interprocess Communication (IPC) 58 6.4.5 Opening files based on MIME type 58 6.4.6 Accessing resources 59 6.5 UIP Deployment 59 6.5.1 Download UIP from FDI server 59 6.5.2 Manage UIP 60 in FDI client 7 actions 60 7.1 Overview 60 7.2 Sequence Diagram 60 7.3 FDI Action Graph Definition 63 8 User Interface Description (UID) 63 8.1 Overview 63 8.2 UID Execution 65 Appendix A (Normative) XML Schema 68 Appendix B (Informative) Action Example 120 Appendix C (Informative) Typical FDI Client Usage Example 128 References 129

foreword

This document is in accordance with the provisions of GB/T 1.1-2020 "Guidelines for Standardization Work Part 1.Structure and Drafting Rules for Standardization Documents" drafting. This document is part 2 of GB/T 41771 "Field Device Integration". GB/T 41771 has issued the following parts. --- Part 1.Overview; --- Part 2.Client; --- Part 3.Server; --- Part 4.Package; --- Part 5.Information Model. This document is equivalent to IEC 62769-2.2021 "Field Device Integration (FDI) Part 2.FDI Client". The following minimal editorial changes have been made to this document. --- Change the name of this document to "Field Device Integration Part 2.Client". Please note that some contents of this document may refer to patents. The issuing agency of this document assumes no responsibility for identifying patents. This document is proposed by China Machinery Industry Federation. This document is under the jurisdiction of the National Process Measurement Control and Automation Standardization Technical Committee (SAC/TC124). This document is drafted by. Mechanical Industry Instrumentation Comprehensive Technical Economic Research Institute, Southwest University, Beijing Jiaotong University, Electric Power Planning and Design General Institute, Chongqing Chuanyi Automation Co., Ltd., Shanghai Automation Instrument Co., Ltd., Shenzhen Wanxun Automation Co., Ltd., Shenzhen Smart Ruihua Technology Co., Ltd., Beijing Hollysys System Engineering Co., Ltd., Fujian Shangrun Precision Instrument Co., Ltd., Beijing Dongtu Technology Co., Ltd. Co., Ltd., Shanghai Institute of Metrology and Testing Technology, Haier Group Corporation, Schneider Electric (China) Co., Ltd., B&R Industrial Automation (China) Co., Ltd., Siemens (China) Co., Ltd., Rockwell Automation (China) Co., Ltd., CITIC Dicastal Co., Ltd., Harbin Institute of Technology Robotics (Yueyang) Civil-Military Integration Research Institute, Harbin Institute of Technology Robotics (Shandong) Intelligent Equipment Research Institute, FCG Field Communication Group. The main drafters of this document. Wang Shuo, Liu Xiaojing, Liu Feng, Sun Xin, Zhang Jinbin, Tian Yingming, Bao Weihua, Cheng Jixun, Ren Junmin, Luo An, Ge Jian, Xue Baihua, Zhang Yi, Wang Yong, Yan Xinhua, Song Huazhen, Xu Bin, Gao Jingmei, Huang Liang, Zhou Fengwei, Zhao Fang, Wang Jun.

Introduction

The field device integration series standards are important technical standards to guide related activities such as industrial process measurement and control. GB/T 41771 aims to Establish the normative criteria applicable to equipment integration, which is proposed to be composed of 15 parts. --- Part 1.Overview. The purpose is to define the concept and overview of field device integration specifications. --- Part 2.Client. The purpose is to specify the relevant requirements for field device integration clients. --- Part 3.Server. The purpose is to specify the relevant requirements for field device integration servers. --- Part 4.Package. The purpose is to build a field device integration package model that provides the integration of devices, network components and communication servers into All elements required by the system. --- Part 5.Information Model. The purpose is to specify the topology of the automation system, used to describe the equipment and communication of the automation system Connect Network. --- Part 6.Technology Mapping. The purpose is to specify the technical mapping of the concepts described in field device integration. --- Part 7.Communication equipment. The purpose is to specify the elements that implement the communication capability. --- Part 8.General protocol of the profile. The purpose is to specify the required communication servers, gateways and devices described by the field device integration package Details of the general protocol. --- Part 9.Profile Foundation Fieldbus H1.The purpose is to specify the field device integrated communication of H1 fieldbus technology regulation. --- Part 10.Profile Foundation Fieldbus HSE. The purpose is to specify the field device integration communication of HSE fieldbus technology letter rules. --- Part 11.Profile PROFIBUS. The purpose is to specify the field device integration communication profile of PROFIBUS technology. --- Part 12.Profile PROFINET. The purpose is to specify the field device integration communication profile of PROFINET technology. --- Part 13.Profile HART and WirelessHART. The purpose is to specify the HART and WirelessHART technology Field device integration communication profile. --- Part 14.Profile Modbus-RTU. The purpose is to specify the field device integration communication profile of Modbus-RTU technology. --- Part 15.Profile ISA100.The purpose is to specify the field device integration communication profile of ISA100 technology. Field Device Integration Part 2.Client Side

1 Scope

This document specifies the requirements for FDI clients. The entire FDI architecture is shown in Figure 1.The architectural components within the scope of this document are in the Indicated in dark color in the figure. This document applies to the integration of field devices in automation systems. Figure 1 FDI Architecture Diagram

2 Normative references

The contents of the following documents constitute the essential provisions of this document through normative references in the text. Among them, dated references For documents, only the version corresponding to the date is applicable to this document; for undated reference documents, the latest version (including all amendments) is applicable to this document. GB/T 35673-2017 Industrial Communication Network Network and System Security System Security Requirements and Security Levels (IEC 62443-3-3. 2013, IDT) ......
