GB/T 41264-2022 English PDF

Q: How long will the true-PDF of English version of GB/T 41264-2022 be delivered?

Upon your order, we will start to translate GB/T 41264-2022_English as soon as possible, and keep you informed of the progress. The lead time is typically 2 ~ 4 working days. The lengthier the document the longer the lead time.

Q: Can I share the purchased PDF of GB/T 41264-2022_English with my colleagues?

Yes. The purchased PDF of GB/T 41264-2022_English will be deemed to be sold to your employer/organization who actually pays for it, including your colleagues and your employer's intranet.

Q: Does the price include tax/VAT?

Yes. Our tax invoice, downloaded/delivered in 9 seconds, includes all tax/VAT and complies with 100+ countries' tax regulations (tax exempted in 100+ countries). Avoidance of Double Taxation Agreements (DTAs) between Singapore and 100+ Countries: https://www.iras.gov.sg/taxes/international-tax

Q: Do you accept my currency other than USD?

Yes. If you need your currency to be printed on the invoice, please write an email to Sales@ChineseStandard.net. In 2 working-hours, we will create a special link for you to pay in any currencies. Otherwise, follow the normal steps: Add to Cart -- Checkout -- Select your currency to pay.

US$379.00 · In stock
Delivery: <= 4 days. True-PDF full-copy in English will be manually translated and delivered via email.
GB/T 41264-2022: Sheet bending robots - Safety requirements
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 41264-2022	379	Add to Cart	4 days	Sheet bending robots - Safety requirements	Valid

Similar standards

GB/T 41393 GB/T 40575 GB/T 39785 GB/T 45501 GB/T 12643

Basic data

Standard ID: GB/T 41264-2022 (GB/T41264-2022)
Description (Translated English): Sheet bending robots - Safety requirements
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: J28
Word Count Estimation: 19,145
Issuing agency(ies): State Administration for Market Regulation, China National Standardization Administration

GB/T 41264-2022: Sheet bending robots - Safety requirements

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Sheet bending robots - Safety requirements ICS 25.040.30 CCSJ28 National Standards of People's Republic of China Safety requirements for sheet metal bending robots Published on 2022-03-09 2022-10-01 Implementation State Administration for Market Regulation Released by the National Standardization Administration directory Preface I 1 Scope 1 2 Normative references 1 3 Terms and Definitions 1 4 Hazard Analysis 2 5 Safety Requirements 2 5.1 Safety performance of the control system 2 5.2 Axis Limits and Space Limits 2 5.3 Operation mode 3 5.4 Startup 3 5.5 Normal stop 3 5.6 Emergency stop 4 5.7 Interlock protection 4 5.8 Speed Control 4 5.9 Teaching 4 5.10 Prevention of accidental operation 5 5.11 Selection of key components 5 5.12 Manufacturing and Assembly 5 5.13 Electrical Safety 6 5.14 Electromagnetic compatibility 6 5.15 Singularity Protection 6 5.16 Lifting measures 6 5.17 Integration with sheet metal bending machines and related equipment 6 5.18 Commissioning of the integrated system 7 6 Usage information8 6.1 Safety signs8 6.2 Operation flags 8 6.3 Nameplate 8 6.4 Operational Information 8 6.5 User Manual 9 7 Testing and validation 10 7.1 Test and Verification Method Category 10 7.2 Test and verification methods 10 Appendix A (Informative) Hazard List 13 Reference 15

foreword

This document is in accordance with the provisions of GB/T 1.1-2020 "Guidelines for Standardization Work Part 1.Structure and Drafting Rules of Standardization Documents" drafted. Please note that some content of this document may be patented. The issuing agency of this document assumes no responsibility for identifying patents. This document is proposed by China Machinery Industry Federation. This document is under the jurisdiction of the National Automation System and Integration Standardization Technical Committee (SAC/TC159). This document is drafted by. Yangzhou Hengjia Automation Equipment Co., Ltd., Beijing Machinery Industry Automation Research Institute Co., Ltd., Nanjing Aviation Aerospace University, Evert Intelligent Equipment Co., Ltd., AUBO (Beijing) Intelligent Technology Co., Ltd. The main drafters of this document. Pan Diansheng, Yan Wei, Wang Tao, Pan Xinwei, Li Xiaodong, Yang Book Review, Chen Zhan, Liu Ying, Wu Hongtao, Feng Haisheng, Wei Hongxing. Safety requirements for sheet metal bending robots

1 Scope

This document specifies the hazard analysis, safety requirements, usage information, testing and validation of sheet metal bending robots. This document applies to Cartesian coordinate type and joint type sheet metal bending robots (hereinafter referred to as robots).

2 Normative references

The contents of the following documents constitute essential provisions of this document through normative references in the text. Among them, dated citations documents, only the version corresponding to that date applies to this document; for undated references, the latest edition (including all amendments) applies to this document. GB/T 150.1 Pressure Vessels Part 1.General Requirements GB 2894 Safety Signs and Guidelines for their Use GB/T 3797-2016 Electrical Control Equipment GB/T 4208-2017 Protection class of enclosure (IP code) GB/T 5226.1-2019 Mechanical and Electrical Safety Mechanical and Electrical Equipment Part 1.General Specifications GB/T 9969 General Principles of Instruction Manual for Industrial Products GB/T 12643 Robot and Robot Equipment Vocabulary GB/T 19436.2-2013 Electro-sensitive protective equipment for mechanical and electrical safety - Part 2.Use of active optoelectronic protective devices Special requirements for equipment (AOPDs) GB/T 19876 Mechanical safety and the positioning of safety guards related to the approach speed of human body parts GB/T 23821 Safety distance of machinery to prevent the upper and lower limbs from touching the danger zone GB/T 37414.1-2019 Industrial Robot Electrical Equipment and Systems Part 1.Technical Requirements for Control Devices

3 Terms and Definitions

GB/T 12643 and the following terms and definitions apply to this document. 3.1 sheetbendingrobots With more than 5 programmable axes, assist CNC sheet metal bending machine, autonomously perform reclaiming, positioning, feeding, bending follow, return, palletizing and other industrial robots. 3.2 teach mode teach mode The gripper of the robot is manually guided, and the operation mode of the automatic processing program for sheet metal bending is completed according to the technological requirements of sheet metal bending. Note. The manual deceleration method of GB 11291.1-2011 is used for teaching mode. 3.3 reappearingmode Reproduce the teaching program to check whether the program meets the operation mode of the sheet metal bending process requirements. Note. The playback mode is derived from the manual high-speed mode of GB 11291.1-2011. ......
