GB/T 39567-2020 English PDFUS$409.00 · In stock
Delivery: <= 4 days. True-PDF full-copy in English will be manually translated and delivered via email. GB/T 39567-2020: General specification for brushless servo motor systems for multi-rotor unmanned aircraft Status: Valid
Basic dataStandard ID: GB/T 39567-2020 (GB/T39567-2020)Description (Translated English): General specification for brushless servo motor systems for multi-rotor unmanned aircraft Sector / Industry: National Standard (Recommended) Classification of Chinese Standard: K24 Classification of International Standard: 29.160.30 Word Count Estimation: 22,220 Date of Issue: 2020-12-14 Date of Implementation: 2021-07-01 Quoted Standard: GB/T 755; GB/T 2423.1-2008; GB/T 2423.2-2008; GB/T 2423.3; GB/T 2423.10; GB/T 2423.17; GB/T 2423.21; GB/T 2423.22-2012; GB/T 2828.1-2012; GB/T 4208; GB/T 9254-2008; GB/T 16422.3-2014; GB/T 17618 Regulation (derived from): National Standard Announcement No. 28 of 2020 Issuing agency(ies): State Administration for Market Regulation, China National Standardization Administration Summary: This standard specifies the communication interface and working system, technical requirements and test methods, inspection rules and preparations for delivery of the brushless servo motor system for multi-rotor drones. This standard applies to brushless servo motor systems for multi-rotor drones (hereinafter referred to as "servo systems") and permanent magnet brushless servo motors (hereinafter referred to as "motors") and brushless servo motor drives (hereinafter referred to as " Drive") design, manufacture, inspection and acceptance. GB/T 39567-2020: General specification for brushless servo motor systems for multi-rotor unmanned aircraft---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order. (General Specification for Brushless Servo Motor System for Multi-rotor UAV) ICS 29:160:30 K24 National Standards of People's Republic of China Brushless Servo Motor System for Multi-rotor UAV General specification 2020-12-14 release 2021-07-01 implementation State Administration for Market Regulation Issued by the National Standardization Management Committee Table of contentsForeword Ⅰ 1 Scope 1 2 Normative references 1 3 Terms and definitions 1 4 Communication interface and working system 3 5 Technical requirements and test methods 3 6 Inspection rules 15 7 Delivery preparation 18ForewordThis standard was drafted in accordance with the rules given in GB/T 1:1-2009: This standard was proposed by China Electrical Equipment Industry Association: This standard is under the jurisdiction of the National Micromotor Standardization Technical Committee (SAC/TC2): Drafting organizations of this standard: Shenzhen DJI Innovation Technology Co:, Ltd:, Xi'an Micromotor Research Institute, Chengdu Precision Motor Factory, Shenzhen Zhengde Smart Control Co:, Ltd:, Dongguan Weichuang Power Technology Co:, Ltd:, Shandong Depuda Motor Co:, Ltd:, Nanjing Jinqi New Energy Power Power Research Institute Co:, Ltd:, Zhejiang Julong Automation Equipment Co:, Ltd:, Nanjing Gaoqi Electric Co:, Ltd:, Southeast University, Jiangsu Yunneng Electric Research Institute Co:, Ltd:, Xiamen Laikesheng Intelligent Technology Co:, Ltd:, Shenyang University of Technology, Zhejiang Rujing Technology Co:, Ltd:, Foshan Fengxu Technology Limited company: The main drafters of this standard: Tao Ye, Qiu Jianda, Guo Qiaobin, Peng Shengjun, Li Hao, Chen Weijie, Jia Jia, Long Biao, Wang Fujie, Cao Shenghua, Chen Zhaoming, Xu Rongfeng, Jin Long, Yang Yang, Wei Jianzhong, Lin Xingle, Xie Wenlin, Chen Lixiang, Wang Guangjian, Zhang Hongzhao: Brushless Servo Motor System for Multi-rotor UAV General specification1 ScopeThis standard specifies the communication interface and working system, technical requirements, test methods, and inspection of the brushless servo motor system for multi-rotor drones: Inspection rules and delivery preparation: This standard applies to brushless servo motor systems for multi-rotor drones (hereinafter referred to as "servo systems") and the permanent magnet brushless systems that constitute the system Servo motor (hereinafter referred to as "motor"), brushless servo motor driver (hereinafter referred to as "drive") design, manufacturing, inspection and acceptance:2 Normative referencesThe following documents are indispensable for the application of this document: For dated reference documents, only the dated version applies to this article Pieces: For undated references, the latest version (including all amendments) applies to this document: GB/T 755 Rotating motor rating and performance GB/T 2423:1-2008 Environmental testing of electric and electronic products Part 2: Test method Test A: Low temperature GB/T 2423:2-2008 Environmental testing of electric and electronic products Part 2: Test method Test B: High temperature GB/T 2423:3 Environmental Test Part 2: Test Method Test Cab: Constant Damp Heat Test GB/T 2423:10 Environmental Test Part 2: Test Method Test Fc: Vibration (Sine) GB/T 2423:17 Environmental testing of electrical and electronic products Part 2: Test method Test Ka: Salt spray GB/T 2423:21 Environmental testing of electrical and electronic products Part 2: Test methods Test M: Low air pressure GB/T 2423:22-2012 Environmental Test Part 2: Test Method Test N: Temperature Change GB/T 2828:1-2012 Sampling inspection procedures by attributes Part 1: Batch inspection sampling plan retrieved by acceptance quality limit (AQL) GB/T 4208 Shell protection grade (IP code) GB/T 9254-2008 Information Technology Equipment Radio Disturbance Limits and Measurement Methods GB/T 16422:3-2014 Plastic laboratory light source exposure test method Part 3: Fluorescent ultraviolet lamp GB/T 17618 Information Technology Equipment Immunity Limits and Measurement Methods3 Terms and definitionsThe following terms and definitions apply to this document: 3:1 Brushless servo motor system brushlessservomotorsystem The brushless servo motor is used as the actuator, so that the position, speed and torque of the object can follow the target value of the input control signal (or give Fixed value) automatic control system with arbitrary changes: 3:2 Brushlessservomotor Used in motion control systems, and output parameters such as position, speed, acceleration or torque are controllable permanent magnet brushless motors: ...... |
