GB/T 39329-2020 English PDF

US$279.00 · In stock
Delivery: <= 3 days. True-PDF full-copy in English will be manually translated and delivered via email.
GB/T 39329-2020: (Additive Manufacturing Test Method Standard Test Piece Accuracy Inspection)
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 39329-2020	279	Add to Cart	3 days	(Additive Manufacturing Test Method Standard Test Piece Accuracy Inspection)	Valid

Similar standards

GB/T 38898   GB/T 38896   GB/T 39432   GB/T 39334.2   GB/T 39334.1

Basic data

Standard ID: GB/T 39329-2020 (GB/T39329-2020)
Description (Translated English): (Additive Manufacturing Test Method Standard Test Piece Accuracy Inspection)
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: J04
Word Count Estimation: 15,166
Date of Issue: 2020-11-19
Date of Implementation: 2021-06-01
Regulation (derived from): National Standard Announcement No. 26 of 2020
Issuing agency(ies): State Administration for Market Regulation, China National Standardization Administration

GB/T 39329-2020: (Additive Manufacturing Test Method Standard Test Piece Accuracy Inspection)

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
(Additive Manufacturing Test Method Standard Test Piece Accuracy Inspection) ICS 25.030 J04 National Standards of People's Republic of China Additive manufacturing test methods Standard test piece accuracy inspection 2020-11-19 released 2021-06-01 implementation State Administration for Market Regulation Issued by the National Standardization Management Committee

Table of contents

Preface Ⅲ 1 Scope 1 2 Normative references 1 3 Terms and definitions 1 4 General requirements 1 4.1 Unit of measurement 1 4.2 Inspection tool 1 4.3 Inspection sequence 1 4.4 Inspection item 1 4.5 Process parameters 1 4.6 The role of support 2 4.7 Treatment 2 4.8 Environmental requirements 2 5 Structure and dimensions 2 5.1 General 2 5.2 Material 2 5.3 The structure and dimensions of the drum test piece 2 6 Quantity and placement 3 6.1 Principle 3 6.2 Placement Strategy 3 6.3 Other requirements 4 7 Measurement and statistical analysis of data 4 7.1 Measurement 4 7.2 Statistics of error distribution graph 5 7.3 Standard error analysis 6 7.4 Accuracy class 6 8 Inspection report 6 Appendix A (informative appendix) S-shaped test piece 8 A.1 Structure and dimensions of S-shaped test piece 8 A.2 Inspection of S-shaped test piece 10 A.3 Test report 11 Reference 12

Foreword

This standard was drafted in accordance with the rules given in GB/T 1.1-2009. Please note that certain contents of this document may involve patents. The issuing agency of this document is not responsible for identifying these patents. This standard was proposed by China Machinery Industry Federation. This standard is under the jurisdiction of the National Standardization Technical Committee for Additive Manufacturing (SAC/TC562). Drafting organizations of this standard. Xi'an National Research Institute of Additive Manufacturing Co., Ltd., Xi'an Jiaotong University, Hunan Huashu High-Tech Co., Ltd. Company, Shanxi Additive Manufacturing Research Institute Co., Ltd., Antai Technology Co., Ltd., China Machinery Productivity Promotion Center, Guangdong Hanbang Laser Technology Co., Ltd., Dongguan University of Technology, Central Academy of Mechanical Sciences Group Co., Ltd., Northwest Nonferrous Metal Research Institute, Zhejiang Xunshi Technology Co., Ltd. Company, Feilkang Rapid Manufacturing Technology Co., Ltd., Beijing Hengchuang Additive Manufacturing Research Institute Co., Ltd., Harbin Forward Multidimensional Intelligent Equipment Limited company. The main drafters of this standard. Lu Bingheng, Hou Ying, Tian Xiaoyong, Chen Bosheng, Gong Tao, Wang Xuebing, Xue Lian, Zhang Lijuan, Liu Jianye, Chen Shenggui, Shan Zhongde, Wang Jian, Li Haibin, Jin Weigang, Yang Guangshan, Zhao Xin, Zhao Jiyuan, Cao Yi, Zhang Chaofeng, Hu Ligang. Additive manufacturing test methods Standard test piece accuracy inspection

1 Scope

This standard specifies the general requirements, structure and size, quantity and placement of additive manufacturing standard test pieces (hereinafter referred to as "test pieces") Configuration, measurement and data statistical analysis, inspection report. This standard applies to the evaluation of the forming accuracy of additive manufacturing equipment (hereinafter referred to as "equipment").

2 Normative references

The following documents are indispensable for the application of this document. For dated reference documents, only the dated version applies to this article Pieces. For undated references, the latest version (including all amendments) applies to this document. GB/T 35351 Terminology for Additive Manufacturing

3 Terms and definitions

The terms and definitions defined in GB/T 35351 apply to this document.

4 General requirements

4.1 Unit of measurement In this standard, all linear dimensions, standard deviations and standard errors of the test piece are in millimeters (mm). 4.2 Inspection tools The measuring instrument should have a resolution of 0.02mm or higher. Recommend to use micrometer, vernier caliper, coordinate measuring machine, three-dimensional scanning Other inspection tools that meet the requirements of measurement accuracy can also be used. 4.3 Inspection sequence During the inspection, priority should be given to the items specified in the inspection standards, and then other items that are of interest to users. In order to facilitate the assembly and disassembly of tools and inspection, the Both parties agree to proceed in any order. 4.4 Inspection items When additional inspection items are needed for acceptance purposes, the user can negotiate with the equipment manufacturer to determine these items. Indeed proposed. 4.5 Process parameters The equipment commitment conditions or requirements shall be met when processing test pieces. The forming of the test piece of the same manufacturing batch and the internal and external structure of the same test piece The process parameters should be kept consistent, and the outer surface forming accuracy should not be improved by adjusting the process parameters to reduce the density. ......
