GB/T 39011.1-2020: Mechanical pencils for technical drawings - Part 1: Classification, dimensions, performance requirements and testing
Status: Obsolete

GB/T 39011.1: Historical versions

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 39011.1-2020	399	Add to Cart	3 days	Mechanical pencils for technical drawings - Part 1: Classification, dimensions, performance requirements and testing	Obsolete
GB/T 39011.1-2020	399	Add to Cart	3 days	Mechanical pencils for technical drawings - Part 1: Classification, dimensions, performance requirements and testing	Obsolete

Similar standards

GB 21027   GB/T 37624   GB/T 26704   GB/T 39023   GB/T 39024   GB/T 39023

Basic data

Standard ID: GB/T 39011.1-2020 (GB/T39011.1-2020)
Description (Translated English): Mechanical pencils for technical drawings - Part 1: Classification, dimensions, performance requirements and testing
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: Y50
Classification of International Standard: 97.180
Word Count Estimation: 10,131
Date of Issue: 2020-07-21
Date of Implementation: 2020-07-21
Issuing agency(ies): State Administration for Market Regulation, China National Standardization Administration

GB/T 39011.1-2020: Mechanical pencils for technical drawings - Part 1: Classification, dimensions, performance requirements and testing

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Mechanical pencils for technical drawings--Part 1.Classification, dimensions, performance requirements and testing ICS 97.180 Y50 National Standards of People's Republic of China Mechanical drawing pencil Part 1.Classification, dimensions, performance requirements and tests (ISO 9177-1.2016, IDT) 2020-07-21 released 2020-07-21 implementation State Administration for Market Regulation Issued by the National Standardization Management Committee

Foreword

GB/T 39011 "Technical Drawing Mechanical Pencil" is divided into three parts. ---Part 1.Classification, size, performance requirements and tests; ---Part 2.Classification and size of black lead core; ---Part 3.Black lead core HB lead core bending strength. This part is Part 1 of GB/T 39011. This section was drafted in accordance with the rules given in GB/T 1.1-2009. The translation method used in this part is equivalent to the ISO 9177-1.2016 ``Technical Drawing Mechanical Pencil Part 1.Classification, Dimensions, Performance Requirements Summation Test. The Chinese documents that have a consistent correspondence with the international documents cited in this section are as follows. ---GB/T 17450-1998 technical drawing line (ISO 128-20.1996, IDT); ---GB/T 39011.2-2020 Technical drawing mechanical pencil Part 2.Black lead core classification and size (ISO 9177-2. 1989, IDT). This part was proposed by the China National Light Industry Council. This part is under the jurisdiction of the National Pen Standardization Technical Committee (SAC/TC378). Drafting organizations of this section. Shanghai Chenguang Stationery Co., Ltd., Shanghai Pen Industry Research Institute, Shanghai Lemei Stationery Co., Ltd., Bei Development Group Co., Ltd., Anshuo Stationery (Shanghai) Co., Ltd., Qingdao Yingge Stationery Co., Ltd., Shenzhen Qixin Group Co., Ltd., Wenzhou Hobby Pen Co., Ltd., Yiwu Meineng Pen Co., Ltd. The main drafters of this section. Yao Hezhong, Yao Hongjun, Li Chang, Chen Jingqiang, Huang Xiaolei. Mechanical drawing pencil Part 1.Classification, dimensions, performance requirements and tests

1 Scope

This part of GB/T 39011 specifies the classification, size, performance requirements and test methods of mechanical pencils for technical drawing.

2 Normative references

The following documents are indispensable for the application of this document. For dated reference documents, only the dated version applies to this article Pieces. For undated references, the latest version (including all amendments) applies to this document. ISO 128-20 General Principles of Technical Drawings-Part 20.Drawings (Technical Drawings-Generalprinci- plesofpresentation-Part 20.Basicconventionsforlines) ISO 9177-2 Mechanical pencils Part 2.Classification and size of black lead cores (Mechanicalpencils-Part 2.Black leads-Classificationanddimensions)

3 Terms and definitions

The following terms and definitions apply to this document. 3.1 Mechanicalpencil A hand-held writing tool that can hold and output lead cores for writing or drawing.

4 categories

Mechanical pencils should be classified by mechanical structure type (see Table 1) and nominal diameter (see Table 2). Classification and size of lead core (diameter and length) See ISO 9177-2. Table 1 Classified by mechanical structure type Mechanical structure type classification letter description corresponding drawing number Snap Fa Lb Output the lead core in the pen barrel by pressing the snap mechanism figure 1 figure 2 Rotary S The lead core in the barrel is output through the rotating screw mechanism. Figure 3 a There are mainly resin lead cores with a nominal diameter of 0.35mm~1mm. b Mainly graphite lead core with a nominal diameter of 2mm (see ISO 9177-2). ......
