GB/T 38782-2020 English PDF

Q: How long will the true-PDF of English version of GB/T 38782-2020 be delivered?

Upon your order, we will start to translate GB/T 38782-2020_English as soon as possible, and keep you informed of the progress. The lead time is typically 2 ~ 4 working days. The lengthier the document the longer the lead time.

Q: Can I share the purchased PDF of GB/T 38782-2020_English with my colleagues?

Yes. The purchased PDF of GB/T 38782-2020_English will be deemed to be sold to your employer/organization who actually pays for it, including your colleagues and your employer's intranet.

Q: Does the price include tax/VAT?

Yes. Our tax invoice, downloaded/delivered in 9 seconds, includes all tax/VAT and complies with 100+ countries' tax regulations (tax exempted in 100+ countries). Avoidance of Double Taxation Agreements (DTAs) between Singapore and 100+ Countries: https://www.iras.gov.sg/taxes/international-tax

Q: Do you accept my currency other than USD?

Yes. If you need your currency to be printed on the invoice, please write an email to Sales@ChineseStandard.net. In 2 working-hours, we will create a special link for you to pay in any currencies. Otherwise, follow the normal steps: Add to Cart -- Checkout -- Select your currency to pay.

US$339.00 · In stock
Delivery: <= 4 days. True-PDF full-copy in English will be manually translated and delivered via email.
GB/T 38782-2020: Shore connection for liquid cargo vessel
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 38782-2020	339	Add to Cart	4 days	Shore connection for liquid cargo vessel	Valid

Similar standards

GB/T 589 GB/T 592 GB/T 17727 GB/T 43121.1

Basic data

Standard ID: GB/T 38782-2020 (GB/T38782-2020)
Description (Translated English): Shore connection for liquid cargo vessel
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: U55
Classification of International Standard: 47.020.30
Word Count Estimation: 18,177
Date of Issue: 2020-06-02
Date of Implementation: 2020-12-01
Issuing agency(ies): State Administration for Market Regulation, China National Standardization Administration

GB/T 38782-2020: Shore connection for liquid cargo vessel

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Shore connection for liquid cargo vessel ICS 47.020.30 U55 National Standards of People's Republic of China Ship liquid cargo shore connection 2020-06-02 release 2020-12-01 implementation State Administration of Market Supervision and Administration Issued by the National Standardization Management Committee

Foreword

This standard was drafted in accordance with the rules given in GB/T 1.1-2009. This standard is proposed and managed by the National Marine Machinery Standardization Technical Committee (SAC/TC137). This standard was drafted by. Guangchuan International Co., Ltd., China Shipbuilding Industry Comprehensive Technology and Economic Research Institute, Yada Pipeline System Co., Ltd. the company. The main drafters of this standard. Huang Yuan, Zhang Youzhi, Luo Zhinong, Xu Yangyi, Wu Yongfeng, Feng Huijun, Yu Dongling. Ship liquid cargo shore connection

1 Scope

This standard specifies the classification, structure and basic dimensions, marking, technical requirements, Test methods, inspection rules and packaging, transportation and storage. This standard applies to the design, manufacture, and acceptance of pipeline shore connections with a design pressure of 1.6 MPa in the central header area of tankers.

2 Normative references

The following documents are essential for the application of this document. For dated reference documents, only the dated version applies to this article Pieces. For the cited documents without date, the latest version (including all amendments) applies to this document. GB/T 600-2008 General technical requirements for marine pipeline valves GB/T 699-2015 high-quality carbon structural steel GB/T 700-2006 carbon structural steel GB/T 1184-1996 Tolerances for shape and position tolerances are not noted GB/T 1220-2007 stainless steel rod GB/T 1804-2000 General tolerance Tolerance of linear and angular dimensions without tolerance GB/T 1958-2017 Product Geometric Technical Specification (GPS) Geometric Tolerance Inspection and Verification GB/T 3098.1-2010 Mechanical properties of fasteners Bolts, screws and studs GB/T 3098.2-2015 Fastener mechanical performance nut GB/T 3098.6-2014 Mechanical properties of fasteners Stainless steel bolts, screws and studs GB/T 3098.15-2014 Mechanical properties of fasteners Stainless steel nuts GB/T 20878-2007 Stainless steel and heat-resistant steel grades and chemical composition QB/T 5257-2018 polytetrafluoroethylene (PTFE) sheet ASMEB16.5-2017 pipe flanges and flange accessories (PipeFlangesandFlangedFittings) ASMEB16.47-2017 Large Diameter Steel Flange (LargeDiameterSteelFlanges) 3 Classification, structure and basic size, marking 3.1 Classification The shore connection is divided into two structural types according to the purpose. a) Type A --- suitable for cargo oil and fuel oil systems; b) Type B --- suitable for oil and gas recovery system. 3.2 Structure and basic dimensions 3.2.1 The structure and basic dimensions of the A-type shore connection are as specified in Figure 1 and Table 1. 3.2.2 The structure and basic dimensions of the B-type shore connection are as specified in Figure 2 and Table 2. ......
