GB/T 38399.4-2019 English PDF

US$359.00 · In stock
Delivery: <= 4 days. True-PDF full-copy in English will be manually translated and delivered via email.
GB/T 38399.4-2019: Textile machinery and accessories -- Vocabulary of flat warp knitting machines -- Part 4: Stitch bonding machines and stitch bonding devices
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 38399.4-2019	359	Add to Cart	4 days	Textile machinery and accessories -- Vocabulary of flat warp knitting machines -- Part 4: Stitch bonding machines and stitch bonding devices	Valid

Similar standards

FZ/T 93048.1   FZ/T 93019   GB/T 43018.2   GB/T 38399.3   GB/T 38399.1

Basic data

Standard ID: GB/T 38399.4-2019 (GB/T38399.4-2019)
Description (Translated English): Textile machinery and accessories -- Vocabulary of flat warp knitting machines -- Part 4: Stitch bonding machines and stitch bonding devices
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: W90
Classification of International Standard: 59.120.40; 01.040.59
Word Count Estimation: 18,179
Date of Issue: 2019-12-31
Date of Implementation: 2019-12-31
Issuing agency(ies): State Administration for Market Regulation, China National Standardization Administration

GB/T 38399.4-2019: Textile machinery and accessories -- Vocabulary of flat warp knitting machines -- Part 4: Stitch bonding machines and stitch bonding devices

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Textile machinery and accessories--Vocabulary of flat warp knitting machines--Part 4. Stitch bonding machines and stitch bonding devices ICS 59.120.40; 01.040.59 W90 National Standards of People's Republic of China Vocabulary of flat warp knitting machines for textile machinery and accessories Part 4. Knitting machines and devices Part 4. Stitchbondingmachinesandstitchbondingdevices (ISO 8640-4..1996, Textilemachineryandaccessories-Flatwarp knittingmachines-Part 4. Vocabularyofstitchbondingmachinesand stitchbondingdevices, MOD) 2019-12-31 release 2019-12-31 implementation State Administration of Market Supervision Published by the National Standardization Administration

Contents

Foreword I 1 Scope 1 2 Terms and definitions 1 2.1 Special parts for sewing machine 1 2.2 Feeding device 3 2.3 Auxiliary devices 8 Index 11

Foreword

GB/T 38399 `` Glossary of Flat Warp Knitting Machines for Textile Machinery and Accessories '' is divided into the following four parts. --- Part 1. Basic structure and loop forming mechanism; --- Part 2. let-off, fabric pulling and winding; --- Part 3. Jacquard device; --- Part 4. sewing machine and sewing device. This part is Part 4 of GB/T 38399. This section is drafted in accordance with the rules given in GB/T 1.1-2009. This part uses the redrafting method to modify and adopt ISO 8640-4..1996 "Textile Machinery and Accessories Flat Warp Knitting Machines. Part 4. Sewing Vocabulary for knitting machines and sewing devices. Compared with ISO 8640-4..1996, this section has structural changes. In order to standardize the standard structure, the "Scope" and "Term" chapters have been added. No., and adjusted other article numbers accordingly. The technical differences of this part compared to ISO 8640-4..1996 and their causes are as follows. --- Added "This section is applicable to the production of Tricot warp knitting machines, Raschel warp knitting machines, Knitting machines, crochet belt machines and flat warp knitting machines for the production of warp knitted fabrics ", in order to limit the scope of application of the standard (see Chapter 1). The following editorial changes have been made in this section. --- In keeping with the existing series of standards, the standard name was changed to "Textile Machinery and Accessories Flat Warp Knitting Machine Vocabulary Part 4. Knitting machines and devices "; --- Added note about legend (see note in Chapter 1); --- Added Chinese Pinyin index. This section is proposed by China Textile Industry Federation. This section is under the jurisdiction of the National Technical Committee for Standardization of Textile Machinery and Accessories (SAC/TC215). This section was drafted. Changzhou No. 8 Textile Machinery Co., Ltd., Fujian Nine Dragon Machinery Technology Co., Ltd., Zhejiang Yuejian Intelligent Equipment Co., Ltd., Jiangnan University, Changde Textile Machinery Co., Ltd., KARL MAYER (China) Co., Ltd., Fujian Xingang Textile Machinery Co., Ltd., Wuyang Textile Machinery Co., Ltd., Donghua University, Changzhou Saijia Machinery Co., Ltd., Guangzhou Yehong Electromechanical Technology Co., Ltd., Fu Jianhongyu Electronic Technology Co., Ltd., Jiangsu Runyuan Holding Group Co., Ltd., Changzhou Xiangyun Intelligent Control System Co., Ltd., Zhejiang Fangyuan Inspection Group Co., Ltd., China Textile Machinery Association. The main drafters of this section. Jiang Gaoming, Xu Jun, Tan Yuan, Wang Zhanhong, Li Yanjia, Zheng Chunle, Chen Nanliang, Mo Wenjie, Yin Jisheng, Yang Xingcai, Cong Zheng, Shao Hong, Li Bing, Chen Zhongying, Xu Haiping, Xue Junyong, Wu Jianbin, Long Zhengxiang. Vocabulary of flat warp knitting machines for textile machinery and accessories Part 4. Knitting machines and devices

1 Scope

This section of GB/T 38399 defines terms related to sewing machines and sewing devices. special parts for sewing machines, feeding devices and auxiliary Device. This section applies to the production of Tricot warp knitting machines, Raschel warp knitting machines, and crochet knitting machines with different textile structures Belt machines and flat warp knitting machines for warp knitting. Note. The illustrations in this section only show the working principles of various types of mechanisms, and do not represent the only or the most common type of structure.

2 terms and definitions

2.1 Special parts for sewing machine 2.1.1 Piercing compound needle Separately moving needle cores can open and close the hook, and a composite needle with a hook-shaped needle that can pierce the base cloth (see Figure 1). figure 1 2.1.2 Supporting element A mechanism that prevents the base fabric from slipping when the composite needle punctures. 2.1.2.1 Supporting pin Needle-shaped mechanism with yarn guide eyelet (see Figure 1). 2.1.2.2 Supportingsinker Lamellar mechanism (see Figure 2). ......
