GB/T 38265.14-2021 English PDF

US$199.00 · In stock
Delivery: <= 3 days. True-PDF full-copy in English will be manually translated and delivered via email.
GB/T 38265.14-2021: Test methods for soft soldering fluxes - Part 14: Assessment of tackiness of flux residues
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 38265.14-2021	199	Add to Cart	3 days	Test methods for soft soldering fluxes - Part 14: Assessment of tackiness of flux residues	Valid

Similar standards

GB/T 40741   GB/T 37778   GB/T 37910.2   GB/T 38265.8   GB/T 38265.9   GB/T 38265.6

Basic data

Standard ID: GB/T 38265.14-2021 (GB/T38265.14-2021)
Description (Translated English): Test methods for soft soldering fluxes - Part 14: Assessment of tackiness of flux residues
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: J33
Word Count Estimation: 9,929
Issuing agency(ies): State Administration for Market Regulation, China National Standardization Administration

GB/T 38265.14-2021: Test methods for soft soldering fluxes - Part 14: Assessment of tackiness of flux residues

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Test methods for soft soldering fluxes -- Part 14: Assessment of tackiness of flux residues ICS 25:160:50 CCSJ33 National Standards of People's Republic of China Soldering flux test method Part 14: Evaluation of the tackiness of flux residues (ISO 9455-14:2017, Softsolderingfluxes-Testmethods- Published on 2021-12-31 2022-07-01 Implementation State Administration for Market Regulation Released by the National Standardization Administration directory Preface III Introduction IV 1 Scope 1 2 Normative references 1 3 Terms and Definitions 1 4 Principle 1 5 Reagents and Materials 1 6 Instruments 2 7 Specimen 2 8 Test Step 3 9 Inspection of test pieces 4 10 Expression of test results 4 11 Test report 4

foreword

This document is in accordance with the provisions of GB/T 1:1-2020 "Guidelines for Standardization Work Part 1: Structure and Drafting Rules of Standardization Documents" drafted: This document is part 14 of GB/T 38265 "Test Methods for Soldering Flux": GB/T 38265 has released the following parts: --- Part 1: Gravimetric method for determination of non-volatile matter content; --- Part 2: Boiling point method for the determination of non-volatile matter content; --- Part 5: Bronze mirror test; --- Part 10: Test methods for the spreading of the wetting properties of solder fluxes; --- Part 11: Solubility of flux residues; --- Part 13: Determination of flux spatterability; --- Part 14: Evaluation of the adhesiveness of flux residues; --- Part 15: Copper corrosion test; --- Part 16: Wetting balance method for wetting properties of solder fluxes: This document is modified to adopt ISO 9455-14:2017 "Test methods for solder fluxes - Part 14: Evaluation of the adhesiveness of flux residues": The technical differences between this document and ISO 9455-14:2017 and their reasons are as follows: --- Regarding normative reference documents, this document has made adjustments with technical differences to adapt to the technical conditions of our country and the circumstances of the adjustment: The situation is reflected in Chapter 2 "Normative References", and the specific adjustments are as follows: ● Replace ISO 197-1 (see 5:4) with GB/T 11086 modified to adopt international standards; ● Replace ISO 9453:2014 with GB/T 3131 and GB/T 20422 modified to adopt international standards (see 5:6, 8:2:2); ● Replace ISO 9455-1 with GB/T 38265:1 which is modified to adopt international standard (see 8:1:1); ● Replace ISO 9455-2 with GB/T 38265:2 which is modified to adopt international standard (see 8:1:1); ● Added reference to GB/T 686 (see 5:5): The following editorial changes have been made to this document: --- Modify the standard name to "Flux Test Method Part 14: Evaluation of the Adhesiveness of Flux Residues"; --- Added references as informative citations for ease of application: Please note that some content of this document may be patented: The issuing agency of this document assumes no responsibility for identifying patents: This document is proposed and managed by the National Welding Standardization Technical Committee (SAC/TC55): This document is drafted by: Harbin Welding Research Institute Co:, Ltd:, Beijing Compu Xiwei Technology Co:, Ltd:, Shenzhen Weiteou New Materials Co:, Ltd:, Suzhou Keshida Electronic Materials Co:, Ltd:, Harbin Institute of Technology, China Machinery Intelligent Equipment Innovation Research Institute (Ningbo) Co:, Ltd: Company, Nanjing University of Science and Technology, Xiamen Shijiyu Solder Co:, Ltd:, Jiangsu University of Science and Technology, Shaoxing Tianlong Tin Material Co:, Ltd:, Zhongshan Hanhua Tin Industry Co:, Ltd: The main drafters of this document: He Peng, Wang Zhigang, Li Weijun, Li Chunfang, Lv Xiaochun, Long Weimin, Xue Peng, Zheng Xuzhang, Pu Juan, Liu Bin, Li Feng, Li Ailiang, Song Bei, Su Jinhua:

Introduction

As a key supporting material in the soldering process, solder flux has a decisive influence on the quality of soldered joints: In the implementation of the strong foundation project, the national science and technology major project "core electronic devices, high-end general-purpose chips and basic software products" and "super large-scale Technology research and development of core electronic devices, high-end chips and integrated circuit complete sets of technology in the "Special Project for Molded Integrated Circuit Manufacturing Equipment and Complete Sets of Technology" Among them, solder flux is the key basic material, and it is of great significance to formulate the test method standard for its quality performance evaluation: Since:2001, my country has successively promulgated and implemented "Tin-Lead Soldering Materials", "Lead-Free Soldering Materials", "Solder Flux Classification and Performance Requirements" and "Solder Soldering Materials": As an important component of the solder, solder flux is not only important for the solderability and processability of the solder It is also critical to the environment, reliability of solder joints and applications: GB/T 38265 "Solder Flux Test Method" is a General test method standard, it is proposed to consist of the following parts: --- Part 1: Gravimetric method for determination of non-volatile matter content; --- Part 2: Boiling point method for the determination of non-volatile matter content; --- Part 3: Determination of acid value by potentiometric titration and visual titration; --- Part 5: Bronze mirror test; --- Part 6: Determination of halide (excluding fluoride) content; --- Part 8: Determination of zinc content; --- Part 9: Determination of ammonia content; --- Part 10: Test methods for the spreading of the wetting properties of solder fluxes; --- Part 11: Solubility of flux residues; --- Part 13: Determination of flux spatterability; --- Part 14: Evaluation of the adhesiveness of flux residues; --- Part 15: Copper corrosion test; --- Part 16: Wetting balance method for wetting properties of solder flux; --- Part 17: Surface insulation resistance comb brush test and electrochemical migration test of flux residues: This document adopts the method of chalk powder to qualitatively evaluate the adhesiveness of solder flux brazing residues, which has the advantages of simple operation, strong applicability, With the advantages of accurate and reliable results, it has become an important detection method in flux products: Soldering flux test method Part 14: Evaluation of the tackiness of flux residues

1 Scope

This document specifies the qualitative evaluation method for the adhesiveness of solder flux brazing residues, including principles, reagents and materials, equipment, test panels, Test steps, inspection of test pieces, expression of test results, test report, etc: This document applies to all types of fluxes, solder pastes and cored solder wires:

2 Normative references

The contents of the following documents constitute essential provisions of this document through normative references in the text: Among them, dated citations documents, only the version corresponding to that date applies to this document; for undated references, the latest edition (including all amendments) applies to this document: GB/T 686 Chemical Reagent Acetone (GB/T 686-2008, ISO 6353-2:1983, NEQ) GB/T 3131 Tin-lead solder GB/T 11086 Terms for Copper and Copper Alloys (GB/T 11086-2013, ISO 197-1:1983, ISO 197-2:1983, ISO 197-3: 1983, ISO 197-4:1983, ISO 197-5:1980, MOD) GB/T 20422 Lead-free solder (GB/T 20422-2018, ISO 9453:2014, MOD) GB/T 38265:1 Test Methods for Soldering Flux Part 1: Determination of Non-volatile Matter Content Gravimetric Method (GB/T 38265:1- 2019, ISO 9455-1:1990, MOD) GB/T 38265:2 Test Methods for Soldering Flux Part 2: Determination of Non-volatile Matter Content Boiling Point Method (GB/T 38265:2- 2019, ISO 9455-2:1993, MOD)

3 Terms and Definitions

There are no terms and definitions that need to be defined in this document:

4 Principles

Solder flux is melted with standard quality solder on copper sheet test pieces; for flux cored solder wire and solder paste, standard quality test The sample melted on the copper test piece: After the test piece was cooled to room temperature, chalk powder was used to evaluate the adhesiveness of the flux brazing residue:

5 Reagents and Materials

5:1 Pickling solution Carefully add 75 mL of sulfuric acid (1:84 g/mL) to 210 mL of distilled or deionized water, stirring while adding: After cooling, Then add 15mL of nitric acid (1:42g/mL) and mix well: ......
