US$119.00 · In stock
Delivery: <= 3 days. True-PDF full-copy in English will be manually translated and delivered via email.
GB/T 36586.2-2018: Tools for pressing -- Wear plates -- Part 2: Type B
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 36586.2-2018	119	Add to Cart	3 days	Tools for pressing -- Wear plates -- Part 2: Type B	Valid

Similar standards

GB/T 45677 GB/T 6110 JB/T 3943 GB/T 45382 GB/T 45361 GB/T 36586.1

Basic data

Standard ID: GB/T 36586.2-2018 (GB/T36586.2-2018)
Description (Translated English): Tools for pressing -- Wear plates -- Part 2: Type B
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: J46
Classification of International Standard: 25.120.10
Word Count Estimation: 6,628
Date of Issue: 2018-09-17
Date of Implementation: 2019-04-01
Issuing agency(ies): State Administration for Market Regulation, China National Standardization Administration

GB/T 36586.2-2018: Tools for pressing -- Wear plates -- Part 2: Type B

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Tools for pressing - Wear plates - Part 2. Type B ICS 25.120.10 J46 National Standards of People's Republic of China Die wear plate Part 2. Type B (ISO 9183-2.2011, Toolsforpressing-Wearplates forpressdies-Part 2. TypeB, MOD) Published on.2018-09-17 Implementation of.2019-04-01 State market supervision and administration China National Standardization Administration issued

Foreword

GB/T 36586 "die wear plate" consists of 2 parts. --- Part 1. Type A; --- Part 2. Type B. This part is the second part of GB/T 36586. This part is drafted in accordance with the rules given in GB/T 1.1-2009. This section uses the redrafting method to modify the use of ISO 9183-2.2011 "die die wear plate part 2. B type". There are technical differences in this section compared to ISO 9183-2.2011, and the terms involved in these differences have been passed on the outside margins. The vertical single line (—) of the position is marked. The corresponding technical differences and their reasons are as follows. ---Modified the dimension "21±0.25" in Figure 1 as t, t is the actual size, no need to reserve machining allowance; delete the original drawing t and the double-dot line indicating the corresponding requirement. --- Change the value 20 of t in Table 1 to 20 0-0.02 to meet the current technology and product actual conditions. This section has made the following editorial changes. ---Modified standard name; --- Deleted the description of "Unit is mm" in "1 Scope"; ---In the "1 Scope", added "this part is suitable for B-type wear plates for large die"; --- In the "2 size", the "B type wear plate size should comply with the requirements of Figure 1, Figure 2 and Table 1" modified to "B type wear plate knot The configuration and dimensions shall comply with the requirements of Figure 1, Figure 2 and Table 1"; --- Modified "Figure 1" picture title "size" as "B type wear plate"; --- In the upper right corner of Figure 2, the label "in millimeters" has been added; ---Modified the location of some dimensions, tolerances, and roughness in Figure 1, Figure 2, and modified the marking according to the national standard of technical drawings. the way; --- References, replaced by ISO 1302.2002 with GB/T 131-2006 equivalent to the international standard. This part is proposed and managed by the National Die Standardization Technical Committee (SAC/TC33). This section drafted by. Anhui Hefei Auto Forging Co., Ltd., Anhui Jianghuai Automobile Group Co., Ltd., Youde Precision Industrial (Kunshan) Co., Ltd., Guilin University of Electronic Technology, Shenzhen Guobiao Easy Technology Co., Ltd., Dongguan City, the company has a hardware Company, Ningbo Hongxiecheng Auto Parts Co., Ltd., Xiamen Meike Security Technology Co., Ltd., Yiwu Jianghao Plastic Technology Co., Ltd., Xi'an Yuntuo Electric Co., Ltd., Guilin Electric Apparatus Research Institute Co., Ltd. The main drafters of this section. Tao Shanhu, Zhao Liewei, Chen Zhiwei, Liu Fei, Lin Qiwen, Chen Tianbao, Zhang Fengwei, Kong Fanyan, Lin Shaolian, Xu Yueping, Liu Junhua, Zhang Li, Chen Qiang, Tao Wei, Liao Hongyi, Zhao Wei, Sun Lianhe, and You Limin. Die wear plate Part 2. Type B

1 Scope

This part of GB/T 36586 specifies the basic dimensions and tolerances of B-type wear plates for large die and specifies the dimensions of the mounting holes. And location. This section gives a description of the material and hardness, and specifies the marking of the B-type wear plate for the die that meets the requirements of this section. This section applies to B-type wear plates for large die.

2 size

The structural type and dimensions of the B-type wear plate shall comply with the requirements of Figure 1, Figure 2 and Table 1. Dimensions in millimeters Surface roughness value in microns Figure 1 B type wear plate ......
