GB/T 36290.2-2018 English PDF

US$1464.00 · In stock
Delivery: <= 10 days. True-PDF full-copy in English will be manually translated and delivered via email.
GB/T 36290.2-2018: Process diagrams for power plants -- Part 2: Graphical symbols
Status: Valid
Standard IDUSDBUY PDFLead-DaysStandard Title (Description)Status
GB/T 36290.2-20181464 Add to Cart 10 days Process diagrams for power plants -- Part 2: Graphical symbols Valid

Similar standards

GB/T 42320   GB/T 42322   GB/T 41235   GB/T 44637   GB/T 44636   GB/T 36290.1

Basic data

Standard ID: GB/T 36290.2-2018 (GB/T36290.2-2018)
Description (Translated English): Process diagrams for power plants -- Part 2: Graphical symbols
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: F10
Classification of International Standard: 01.080.30
Word Count Estimation: 77,749
Date of Issue: 2018-06-07
Date of Implementation: 2019-01-01
Regulation (derived from): National Standard Announcement No. 9 of 2018
Issuing agency(ies): State Administration for Market Regulation, China National Standardization Administration

GB/T 36290.2-2018: Process diagrams for power plants -- Part 2: Graphical symbols

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Process diagrams for power plants--Part 2. Graphical symbols ICS 01.080.30 F10 National Standards of People's Republic of China Power station flow chart Part 2. Graphical symbols (ISO 14084-2.2015, IDT) Published on.2018-06-07 2019-01-01 implementation State market supervision and administration China National Standardization Administration issued

Content

Foreword V Introduction VI 1 Scope 1 2 Normative references 1 3 Terms and Definitions 1 4 graphic symbols 1 4.1 General 1 4.2 Graphic Symbol Size 1 4.3 Creation of a new symbol example 1 4.4 Symbols for large/complex objects 2 5 Structure and representation 2 5.1 Overall structure 2 5.2 Registration No. 2 5.3 Representation of graphical symbols in this section 3 5.4 Description of the table representation 3 6 Connections and related devices 3 6.1 Fluid connection 3 6.1.1 Functional connection 3 6.1.2 Process media type connection 4 6.1.3 Simplified representation 5 6.1.4 Flow, branch, cross, etc. 5 6.1.5 Pipe joints, connectors, etc. 5 6.1.6 Connecting Accessories 6 6.1.7 Pipe fittings 7 6.1.8 Pipe insulation, heat insulation, heat tracing, etc. 9 6.2 Mechanical connection 9 7 Fluid Flow Control 9 7.1 Valve 9 7.1.1 Switching valve 9 7.1.2 Check valve 11 7.1.3 Regulating valve 12 7.1.4 Safety and Pressure Relief Valves 13 7.1.5 Special valve 14 7.1.6 Supplementary valve symbol 14 7.1.7 Valve characteristics 16 7.2 flapper door 16 7.2.1 Switch flapper door 16 7.2.2 Checking the flapper door 17 7.2.3 Adjusting the flapper door 17 7.2.4 Safety flapper door 18 7.3 Safety devices other than valves and flapper doors 18 8 Actuator 19 8.1 Manual Actuator 19 8.2 Mechanical Actuators 19 8.3 Automatic Actuator 19 8.4 Supplementary symbol 20 9 fluid delivery 21 9.1 Pump 21 9.2 Fans, fans, blowers and compressors 23 9.3 Vacuum pump, etc. 25 10 Fluid Energy Transfer 25 10.1 Heat exchanger 25 10.2 Mixed mode energy transfer 27 10.3 Cooling Tower 28 11 Fluid treatment 29 11.1 Separation 29 11.1.1 Separation, General 29 11.1.2 Separation of suspended solids in liquids 30 11.1.3 Separation of suspended solids in gas 32 11.2 Treatment of fluids by adsorption, catalysis, conversion, heating, etc. 33 11.2.1 Liquid 33 11.2.2 Gas 34 11.3 Mix 35 11.3.1 General 35 11.3.2 Mixing device 36 12 Storage 36 12.1 Permanent storage 36 12.2 Storage devices, surface identification, etc. 38 12.3 Mobile Storage Device 38 12.4 Energy storage and expansion devices 39 13 Material delivery 40 13.1 Conveyor, hoist, unloader, etc. 40 13.2 Material Flow Control 43 13.3 Feeder 44 13.4 Lifting equipment 45 13.5 Mobile transport equipment 46 14 Material Handling 48 14.1 Separation 48 14.2 Processing, breaking 49 14.2.1 Crushing 49 14.2.2 coarse particle reduction, crusher 50 14.2.3 Fine particle reduction, mill 50 14.2.4 Biomass Processing 51 14.3 Humidification 52 15 thermal energy generating device 52 15.1 Conventional Thermal Energy Generating Device 52 15.2 Boiler Combustion/Heating System 53 15.3 Boiler equipment 54 15.4 Unconventional Energy Generating Device 56 15.5 Thermal Users 56 16 machines, engines 56 16.1 Steam turbines, steam engines 56 16.2 Gas turbines and gas turbines 57 16.3 Electrical Engines, Motors, Generators, Converters 57 17 Mechanical drives, shafts, bearings, couplers, etc. 58 17.1 Axis 58 17.2 Bearing 58 17.3 Transmission 58 17.4 Coupler 59 17.5 Brake 59 17.6 Transmission Mechanism 59 18 Instrumentation, Measurement and Control 60 18.1 Process Control Information (PCI) 60 18.2 Measuring devices, sensors, etc. 60 18.2.1 General Purpose Sensors, etc. 60 18.2.2 Temperature 61 18.2.3 Level 61 18.2.4 Weighing 62 18.2.5 Flow 62 18.2.6 Speed, vibration, etc. 63 18.2.7 Length, displacement, etc. 64 18.3 Signal 64 18.4 Miscellaneous 64 18.5 Control Processing Element 65 Appendix A (informative) Creating a new symbol example 68 Appendix B (informative) Large and complex symbol example 70 Reference 71

Foreword

GB/T 36290 "Power Station Flowchart" is divided into two parts. --- Part 1. Drawing specifications; --- Part 2. Graphical symbols. This part is the second part of GB/T 36290. This part is drafted in accordance with the rules given in GB/T 1.1-2009. This section uses the translation method equivalent to ISO 14084-2.2015 "Power Station Flowchart Part 2. Graphical Symbols". The documents of our country that have a consistent correspondence with the international documents referenced in this part are as follows. ---GB/T 20063 (all parts) Schematic diagram with graphical symbols [ISO 14617 (all parts), IDT] This part is proposed by the China Electricity Council. This part is under the jurisdiction of the National Power Plant Process Monitoring and Information Standardization Technical Committee (SAC/TC376). This section drafted by. China Power Engineering Consulting Group Southwest Electric Power Design Institute Co., Ltd., China Power Engineering Consulting Group, National Power Investment Corporation, China Huadian Corporation, China Nuclear Wuhan Nuclear Power Operation Technology Co., Ltd., University of Electronic Science and Technology, Southwest Jiaotong University, Chengdu Textile College, Yangcheng International Power Generation Co., Ltd., Ningxia Yinxing Power Generation Co., Ltd., Jintou Jincheng Thermoelectric Co., Ltd. The main drafters of this section. Zhang Jinbin, Zhou Weiwei, Zheng Huili, Cui Zhiqiang, Zhu Yuyue, Kang Chengjie, Yan Xinrong, Huang Qi, Zhang Wei, Li Zhongbing, Li Tao, Liu Linhu, Shan Chaolun, Zhou Kai, Zhang Zili, Fan Shengying, Tang Maoping, Xue Jiang, Chen Jingming, Chen Tan.

Introduction

Overview This section deals with the preparation of the power station flow chart. GB , ISO , and IEC drafting standards, including graphical symbols, form the basis of process industry mapping preparation. The relationship between these standards is shown in Figure 1. Note. The standard for marking * is the common application standard. Figure 1 Interrelationship between ISO , IEC and GB mapping standards for power stations Common application standard The following criteria. ---ISO 15519 Series. Process Industry Drawing Specification; ---ISO 14617 (all parts). Graphical symbols; Both are generic, basic class standards for all application areas. Allow technical committees in specialized application areas to add Refining and publishing standards to serve as a common application standard for ISO 15519 series, ISO 14617 (all parts) or both. Application field This section applies to the field of power stations, including various types of conventional fossil fuel power stations, biomass fuel power stations, hydropower stations, wave power stations, wind Power stations, nuclear power plants, geothermal power stations, solar power stations, osmotic power stations, waste incineration power stations and industrial power stations. Power station flow chart Part 2. Graphical symbols

1 Scope

This part of GB/T 36290 specifies the graphical symbols for power station flow diagrams and guidelines for creating new graphical symbol examples. This part is a common application standard for ISO 14617 (all parts). Hydraulic graphic symbols are shown in ISO 1219-1. Graphical symbols for electricians are given in IEC 60617.

2 Normative references

The following documents are indispensable for the application of this document. For dated references, only dated versions apply to this article. Pieces. For undated references, the latest edition (including all amendments) applies to this document. ISO 10209 Technical product documentation vocabulary terms related to technical drawings, product definitions and related documents (Technical productdocumentation-Vocabulary-Termsrelatingtotechnicaldrawings,productdefinitionand Relateddocumentation) ISO 14617 (all parts) Graphical symbols (Graphicalsymbolsfordiagrams) ISO 15519 Industrial Process Profile Specification (Specificationfordiagramsforprocessindustry)

3 Terms and definitions

The following terms and definitions defined by ISO 15519 series and ISO 10209 apply to this document. 3.1 Symbol example symbolexample Graphic symbols created by basic and supplementary graphic symbols.

4 graphic symbols

4.1 General Graphical symbols shall comply with the ISO 14617 (all parts) standards. General rules for graphical symbols are given in GB/T 16901.1. The graphical symbol CAx application rules are given in GB/T 16901.2. Special rules and guidelines for the application of graphical symbols in drawings are given in ISO 15519-1. 4.2 Graphic symbol size The graphical symbols in this section are represented in a grid system with a modulus of M = 2.5 mm. 4.3 Creation of a new symbol example This section covers the most commonly used graphical symbols in power plant drawings. Cannot find what is needed in this section or in ISO 14617 (all parts) For graphic symbols, the required graphic symbols should be created based on the basic and supplementary graphic symbols in ISO 14617 (see Appendix A). When the required graphical symbols are not specified in ISO 14617, and cannot be based on basic and supplementary graphical symbols in ISO 14617 When created, a new graphical symbol request shall be made in accordance with ISO /IEC Guide Part 1..2016 Appendix SH. 4.4 Symbols of large/complex objects In this section, the graphic symbols of large and complex objects such as boilers, steam turbines, flue gas treatment plants, boiler feed pumps, etc. are not marked. Normalization. In drawings, large and complex objects should be represented by outlines, and considering the correct placement of the devices that make up the large and complex objects, Connect and measure graphical symbols such as PCI (process control information; see 18.1). Appendix B gives examples of large and complex object symbols.

5 Structure and representation

5.1 Overall structure This section is divided into the following group categories. ---Chapter 6 - Connections and related devices; ---Chapter 7 - Fluid flow control, valves, flapper doors, safety devices; ---Chapter 8 - Executive Agency; ---Chapter 9 - Fluid delivery, pumps, fans, compressors; --- Chapter 10 - fluid energy transfer, heat exchangers, condensers, cooling towers, etc.; --- Chapter 11 - fluid handling, filtration, separation, mixing, etc.; ---Chapter 12 - Storage, boxes, tanks, containers, accumulators, etc.; --- Chapter 13 - material conveying and flow control, conveyors, feeders, conveyors, etc.; --- Chapter 14 - material processing, separation, crushing, mixing, etc.; ---Chapter 15 - Thermal energy generating devices, boilers, boiler equipment, etc.; --- Chapter 16 - engine, steam turbine, generator, motor, etc.; ---Chapter 17 - Mechanical transmission, shafts, bearings, couplers, etc.; --- Chapter 18 - Instrumentation, Measurement and Control. 5.2 Registration Number Graphical symbols, symbolic examples and application rules in ISO 14617 are assigned a unique registration number, see ISO 14617-1. The symbol example created in this section assigns its registration number during the 6000~7999 series, as shown in Table 1. Note. In the standard preparation stage of this section, the new graphic symbols created in this section and implemented in ISO 14617 are assigned the initial “P” registration number. (P = power station). If these preliminary registration numbers have not been approved by ISO 14617 before the release of this section, this section will be issued under these preliminary registration numbers. Subsequently, in the first round of periodic review of this section, these preliminary registration numbers are replaced by the final registration number approved by ISO 14617. Table 1 Overview of ISO 14617 and the registration number type of this standard Theme ISO 14617 This standard Graphic symbol nnn Nnn Pnnn Registration number from ISO 14617 Initial registration number for the new ISO 14617 symbol Symbol example Xnnn Xnnn X6nnn Registration number from ISO 14617 Registration number for this standard symbol example 5.3 Representation of graphical symbols in this section In this section, the graphical symbols are represented in a 2.5M lattice grid system with imaginary connections, as shown in Figure 2. These ones The imaginary connections and lattice grids are not part of the graphical symbols. When there is a mandatory flow requirement, the imaginary connection will be accompanied by an arrow, as shown in Figure 2b). a) heat exchanger b) spring relief valve Description. 1---graphic symbol; 2---imaginary connection; 3---2.5M lattice grid. Figure 2 Representation of graphical symbols in this section 5.4 Description of the table representation In this section, the graphical symbols are represented in a table with column headings, as shown in Table 2. Table 2 column headings Column description Serial number in each clause/sub-clause Graphic symbol represented by a solid line on a lattice grid Preferred description of symbolic name graphic symbols Reference number is used for the registration number of the actual symbol Encoding a 2-digit code according to IEC 81346-2

6 connections and related devices

6.1 Fluid connection 6.1.1 Functional connection Number symbol symbol name reference number code 6.1.1.1 Pipes, flue, duct Line width 0.5 X6001 WP 6.1.1.2 Instrument connection, control connection in process control chart (PCD) Line width 0.25 X6002 WPWG 6.1.1.3 Control lines, control connections in the process flow diagram (PFD) Line width 0.25, ISO 128-20 basic line type 02 422 WG (continued) Number symbol symbol name reference number code 6.1.1.4 Pipeline representation in adjacent diagrams Adjacent pipeline representation in the same figure Line width 0.5, ISO 128-20 basic line type 12 X6017 WG 6.1.2 Process media type connection Number symbol symbol name reference number code 6.1.2.1 steam pipes Line width 1.0 X6005 WP 6.1.2.2 Condensate, cooling water, water supply pipe Line width 0.5 X6006 WP 6.1.2.3 Oily water pipeline The line width is 0.25. Circle. Line width 0.25, D = 2.0. Interval 7.5 X6007 WP 6.1.2.4 Oily steam pipe The line width is 0.7. Circle. Line width 0.25, D = 2.0. Interval 7.5 X6008 WP 6.1.2.5 Raw water, untreated water pipeline The line width is 0.25. Line segment. line width 1.0, length 9 and 3. Interval 3 X6009 WP 6.1.2.6 Sewage and waste water pipeline The line width is 0.25. Dot. D = 2.0. Interval 7.5 X6010 WP 6.1.2.7 Air duct The solid line width is 0.5. Dash = 422. Line gap 1.0 X6011 WP 6.1.2.8 Solvent, chemical pipeline The line width is 0.25. Line segment. Line width 1.0, length 5. Interval 5 X6012 WP 6.1.2.9 Solid fuel, bulk fuel pipeline The line width is 0.25. Line gap 1.0. Line segment/interval 4.0 X6013 WP 6.1.2.10 Combustible waste pipeline The line width is 0.25. Line gap 1.0. Dot. D = 2.0, interval 7.5 X6014 WP 6.1.2.11 Oil pipeline The line width is 0.25. Line gap 1.0 X6015 WP 6.1.2.12 Combustible gas pipeline The line width is 0.25 0.7. Line gap 1.0 X6016 WP 6.1.2.13 Non-combustible gas, flue gas, inert gas The center line width is 0.7. The outer line is 0.25 wide. Line gap 1.0 X6018 WP 6.1.2.14 Ash, slag pipe The line width is 0.25. Vertical line. interval 4.0 X6019 WP 6.1.2.15 Fly ash pipe The line width is 0.25. Line gap 1.0. Line segment/interval 2.0 X6020 WP 6.1.3 Simplified representation Number symbol symbol name reference number code 6.1.3.1 Transition between multi-line and single-line X6030 WP 6.1.4 Flow, branch, cross, etc. Number symbol symbol name reference number code 6.1.4.1 Mainstream to 241 6.1.4.2 Mainstream to 242 6.1.4.3 Energy or signal flow 249 6.1.4.4 T-branch, Form 1 X504 6.1.4.5 T-branch, Form 2 X505 6.1.4.6 Connection type crossover X506 6.1.4.7 Unconnected Cross X6031 6.1.4.8 Cable break P078 6.1.5 Pipe joints, connectors, etc. Number symbol symbol name reference number code 6.1.5.1 Flange connection 511 XL 6.1.5.2 Clamping flange connection 513 XL 6.1.5.3 Threaded connection 514 XL (continued) Number symbol symbol name reference number code 6.1.5.4 Solder connection 515 XQ 6.1.5.5 Quick connector, shown as non-connected state P032 XM 6.1.5.6 Self-closing quick connector, shown as non-connected state P033 XM 6.1.6 Connecting accessories Number symbol symbol name reference number code 6.1.6.1 lyophobic, draining, draining (eg hydrophobic), funnel 2040 6.1.6.2 lyophobic tray, drain pan, drain tank (such as drain tank) X6035 6.1.6.3 Exhaust (steam), deflation (steam), export to the atmosphere 2039 6.1.6.4 Exhaust (steam), deflation (steam), outlet to the outside of the enclosure or construction Outside the object X6040 6.1.6.5 Siphon 2038 6.1.6.6 Pipeline slope 3061 6.1.6.7 Through the wall or roof, the general symbol P009 (continued) Number symbol symbol name reference number code 6.1.6.8 Through the wall, etc., general symbol 3001 6.1.6.9 Through the wall, sealed “*” should be replaced with some type of seal logo, for example Fire prevention 6.1.7 Pipe fittings Number symbol symbol name reference number code 6.1.7.1 Reducer pipe, pipe size head P069 XL 6.1.7.2 Monolithic flange P023 XL 6.1.7.3 Flange cover P029 XL 6.1.7.4 Threaded Cap 518 XL 6.1.7.5 Plug P028 XL 6.1.7.6 Retractor, compensator Form 1 533 XM 6.1.7.7 Retractor, compensator Form 2 P052 XM 6.1.7.8 Flexible pipe, hose 444 XM 6.1.7.9 Multi-stage throttling device X6032 RN 6.1.7.10 Closed orifice plate P087 RN (continued) Number symbol symbol name reference number code 6.1.7.11 Flanged orifice plate Form 1 772 RN 6.1.7.12 Flanged orifice plate Form 2 P053 RN 6.1.7.13 Rotary blocking plate, close 2044 RN 6.1.7.14 Rotary blocking plate, open 2045 RN 6.1.7.15 Flow Rectifier 2032 W_ 6.1.7.16 Silencer 2033 RP 6.1.7.17 Glass observation window 2034 6.1.7.18 Hose reel, fire hose P031 WN 6.1.7.19 Rupture disc 2035 FL 6.1.7.20 Air inlet or outlet grille P030 HQ 6.1.8 Pipe insulation, heat insulation, heat tracing, etc. Number symbol symbol name reference number code 6.1.8.1 Insulation pipe, insulated pipe X322 RQ 6.1.8.2 Jacket pipe X409 EP 6.1.8.3 Heating or accompanying cooling P068 X8174 EB 6.1.8.4 Electric Heat Tracing X6050 EB 6.2 Mechanical connection Number symbol symbol name reference number code 6.2.1 Mechanical linkage, shaft Form 1 Line width 0.5, line gap 1.0 402 WQ 6.2.2 Mechanical linkage, shaft Form 2 Line width 0.5 403 WQ 6.2.3 Electrical insulation mechanical linkage, shaft wire Line width 0.5, short stroke 4.0, gap 2.0 404 WQ

7 fluid flow control

7.1 valve 7.1.1 On-off valve Number symbol symbol name reference number code 7.1.1.1 Straight-through two-way switching valve, general symbol 2101 QM (continued) Number symbol symbol name reference number code 7.1.1.2 Angle two-way valve, general symbol 2102 QM 7.1.1.3 Three-way valve, general symbol 2103 QM 7.1.1.4 four-way valve, general symbol 2104 QM 7.1.1.5 Two-way on-off valve with membrane actuator, fault off X2101 QM 7.1.1.6 Two-way switching valve with cylinder or hydraulic cylinder actuator X6101 QM 7.1.1.7 Two-way switching valve with cylinder or hydraulic cylinder actuator, fast closing - Fault off X6102 QM 7.1.1.8 Two-way electric switch valve X2104 QM 7.1.1.9 Two-way electric switch valve and integrated electric bypass valve X6103 QM 7.1.2 Check valve......
