GB/T 34118-2017: Terminology for voltage-sourced converters (VSC) for high voltage direct current (HVDC) systems
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 34118-2017	679	Add to Cart	5 days	Terminology for voltage-sourced converters (VSC) for high voltage direct current (HVDC) systems	Valid

Similar standards

GB/T 39572.1 GB/T 37404 GB/T 31487.3 GB/T 30425 GB/T 30843.1

Basic data

Standard ID: GB/T 34118-2017 (GB/T34118-2017)
Description (Translated English): Terminology for voltage-sourced converters (VSC) for high voltage direct current (HVDC) systems
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: K46
Classification of International Standard: 29.200; 29.240
Word Count Estimation: 34,381
Date of Issue: 2017-07-31
Date of Implementation: 2018-02-01
Issuing agency(ies): General Administration of Quality Supervision, Inspection and Quarantine of the People's Republic of China, Standardization Administration of the People's Republic of China

GB/T 34118-2017: Terminology for voltage-sourced converters (VSC) for high voltage direct current (HVDC) systems

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Terminology for voltage-sourced converters (VSC) for high voltage direct current (HVDC) systems ICS 29.200; 29.240 K46 National Standards of People's Republic of China Terms for voltage source converters for high voltage direct current systems Terminology forvoltage-sourcedconverters (VSC) forhighvoltagedirect current (HVDC) systems (IEC 62747.2014, IDT) 2017-07-31 Posted 2018-02-01 implementation General Administration of Quality Supervision, Inspection and Quarantine of People's Republic of China China National Standardization Administration released Directory Preface Ⅰ 1 Scope 1 2 Normative references 1 3 symbols and abbreviations 1 4 graphic symbol 3 5 General Terms Related to Converter Circuits 4 6 voltage source converter topology 5 7 inverter unit and valve 6 8 converter running status 11 High Voltage DC System and Converter Station High Voltage DC Converter Station Equipment Control mode 19 Control system 20 References 23 Index 24

Foreword

This standard was drafted in accordance with the rules given in GB/T 1.1-2009. This standard uses the translation method identical with IEC 62747.2014 "high voltage DC system voltage source converter terminology." The documents of our country that are consistent with the corresponding international documents that are normative references in this standard are as follows. --- GB/T 4728 (all parts) Electrical diagrams with graphical symbols [IEC 60617 (all parts)]. For ease of use, this standard made the following editorial changes and errata. --- Removed the first paragraph of 3.1, due to the statement does not match the content of Chapter 3; Errata "NGB S" to "NBGS" (see 3.3); --- Corrigendum "CTL" to "CTLC" (see 3.3, 6.5 and Figure 4); --- Figure 2 will be changed to Table 1, followed by the figure number change in turn; --- Correct the "See Figure 3" in 7.10 note as "See Figure 4" and "See Figure 4" Corrigendum "See Figure 3". And, for the sake of easy expression, that's it Note the first sentence and the second sentence of the position of exchange; --- The formula (1) "M = 2 · Ucl 3 · Udc Corrigendum to "M = 2 × Ucl 3 × Udc "(See 8.11). This standard proposed by the China Electrical Equipment Industry Association. This standard by the National Standardization Technical Committee power electronic systems and equipment (SAC/TC60) centralized. This standard was drafted unit. Xi'an West Power System Co., Ltd., Xi'an Institute of High Voltage Electric Co., Ltd., State Grid Beijing economy Technology Research Institute, China Southern Power Grid Research Institute Co., Ltd., State Grid Smart Grid Research Institute, Beijing West Power Huaqing Technology Co., Ltd., South Power Grid EHV Transmission and Maintenance Company test center. The main drafters of this standard. Ma Zhirong, Ma Weimin, Wei Wei, Yang Xiaohui, Zhao Yan, Yang Xiaoping, Wang Hefei, Willow, Zhou Hui, Tian Enwen, Zhang Yanzhu, Lei Ying, Lok Bo, Ma Yulong, Yang Yiming, Zhao Zheng, Zhang Su Ning, He Yuan, Peng Yanghan, Wei Sanmin. Terms for voltage source converters for high voltage direct current systems

1 Scope

This standard defines the terms related to self-commutating voltage source converters for High Voltage Direct Current (HVDC) transmission. This standard applies mainly to voltage source converter (VSC) based on IGB T (Insulated Gate Bipolar Transistor), based on the open Voltage source converters (VSC) for other types of semiconductor devices on and off can also be used for reference. This standard does not apply to high-voltage direct current (HVDC) transmission system used in commutation converter and current source converter.

2 Normative references

The following documents for the application of this document is essential. For dated references, only the dated version applies to this article Pieces. For undated references, the latest edition (including all amendments) applies to this document. IEC 60027 (all parts) Letters used in electrotechnical symbols (Lettersymbolstobeusedinelectricaltechnology) IEC 60617 (all parts) electrical diagrams with graphical symbols (Graphicalsymbolsfordiagrams)

3 symbols and abbreviations

3.1 symbol This list covers only the most commonly used symbols (see Figure 1). A more complete symbol table for stationary converters is given in IEC 60027, Chapter and references listed in the standard. Ud DC voltage Udc converter DC voltage Udpe extremely - DC voltage Udpp pole - very direct voltage UdppN rated pole - very DC voltage UdpeN rated pole - the DC voltage UL connection transformer network side line voltage, RMS, including harmonics ULe phase voltage transformer network side, root mean square, including harmonics ULN connection transformer network side line voltage rating Uv connection Transformer valve side line voltage, RMS, including harmonics Uve Transformer valve side phase voltage, root mean square, including harmonics Uc converter wire - Line voltage, rms value, including harmonics Note .Uc is equal to Uv minus the voltage drop across the phase reactor and the valve reactor. However, Uc is of practical significance only under balanced conditions (steady state). Uce Converter phase voltage, rms value, including harmonics Voltage across the Uvalve valve (can be any defined value) Id DC current (can be any defined value) IdN Rated DC current IL connection transformer network side current, square rooted, including harmonics ILN Connection transformer network side current rating ......
