GB/T 33987-2017 English PDF

US$359.00 · In stock
Delivery: <= 4 days. True-PDF full-copy in English will be manually translated and delivered via email.
GB/T 33987-2017: Technical specifications of S/X/Ka tri-band ground receiving system for LEO remote sensing satellite
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 33987-2017	359	Add to Cart	4 days	Technical specifications of S/X/Ka tri-band ground receiving system for LEO remote sensing satellite	Valid

Similar standards

GB/T 23420   GB/T 42852   GB/T 25355

Basic data

Standard ID: GB/T 33987-2017 (GB/T33987-2017)
Description (Translated English): Technical specifications of S/X/Ka tri-band ground receiving system for LEO remote sensing satellite
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: V55
Classification of International Standard: 33.200
Word Count Estimation: 18,196
Date of Issue: 2017-07-12
Date of Implementation: 2018-02-01
Issuing agency(ies): General Administration of Quality Supervision, Inspection and Quarantine of the People's Republic of China, Standardization Administration of the People's Republic of China

GB/T 33987-2017: Technical specifications of S/X/Ka tri-band ground receiving system for LEO remote sensing satellite

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Technical specifications of S/X/Ka tri-band ground receiving system for LEO remote sensing satellite ICS 33.200 V55 National Standards of People's Republic of China S/X/Ka Tri-band Low-Earth Remote Sensing Satellite Ground Receiving system technical requirements 2017-07-12 released 2018-02-01 Implementation General Administration of Quality Supervision, Inspection and Quarantine of the People's Republic of China China National Standardization Management Committee released Directory Preface I Introduction II 1 Scope 1 2 normative reference document 1 3 Terms and definitions 1 4 symbols and abbreviations 2 5 system functions and technical indicators 3 5.1 System components 3 5.2 System functions 4 5.3 System Specifications 4 6 subsystems and functional requirements 5 6.1 day feed subsystem 5 6.2 antenna seat sub-system 6 6.3 Servo subsystem 6 6.4 Tracking Receiving Subsystem 6 Data Logging and Fast Subdivision System 6.6 Test sub-system 10 6.7 station monitoring management subsystem 11 Technical Support Sub - System Other requirements Reference 15

Foreword

This standard is drafted in accordance with the rules given in GB/T 1.1-2009. This standard is proposed by the Chinese Academy of Sciences. This standard by the National Remote Sensing Technology Standardization Technical Committee (SAC/TC327) centralized. The drafting of this standard. Institute of Remote Sensing and Digital Earth, Chinese Academy of Sciences, China Electronics Technology Group Corporation thirty-ninth Institute, Institute of Optics and Fine Mechanics, Chinese Academy of Sciences, Tsinghua University. The main drafters of this standard. Wang Wanyu, Zhang Hongqun, Li An, Lin Bootao, Feng Xuxiang, Wang Yonghua, Chen Jinshu, Hu Jian, Wang Jianping, Wang Qiang, Li Fan, He Yuanchun, Liu Zhi, Li Ziyang, Meng Fanrong, Wang Chaoliang, Jia Yuanyuan, Wang Xinhong.

Introduction

With the development of ground observation technology and remote sensing application requirements, the number of orbiting satellites is increasing, the resolution of satellite payload (package Including temporal resolution, spatial resolution, radiation resolution, spectral resolution, etc.), the amount of raw data acquired at the same time Doubling, resulting in satellite links need to transmit the information rate is getting higher and higher. In order to alleviate the continuous growth of remote sensing observation and data transmission capacity Force is difficult to significantly enhance the contradiction, broadband high-speed transmission has become the inevitable trend of the development of satellite data transmission. In order to solve the contradiction between remote sensing information and data transmission capacity, double circular polarization frequency reuse, Ka frequency data transmission, high order modulation and demodulation And efficient coding and decoding, variable code modulation (VCM) data transmission system has become the development of satellite data transmission to the development trend, the corresponding The terrestrial data receiving system also proposed a higher, updated technical requirements. S/X/Ka three-band terrestrial receiving system for low-range remote sensing Satellite downlink data receiving, recording, will become the remote sensing satellite data ground receiving system development trend. Due to the lack of appropriate standards and regulations Fan, making S/X/Ka tri-band low-frequency remote sensing satellite data ground receiving system design and construction of the lack of technical indicators and performance evaluation The basis of price. Research and development of S/X/Ka tri-band low-frequency remote sensing satellite ground receiving system technical requirements for the development of engineering systems, Test acceptance to provide technical indicators to develop and performance evaluation basis, reduce the technical risks of construction, has become a ground receiving system construction in a Key and critical technical requirements. This standard is based on the development of satellite observation at home and abroad and the technical requirements of the ground receiving system, combined with the current domestic and foreign Technical level and development capability of S/X/Ka tri-band low-frequency remote sensing satellite ground receiving system function and technical specifications and so on. For other low-orbit satellite ground receiving systems that receive high-rate satellite data, such as X, Ka single-band and S/X, S/Ka dual band Face receiving system can refer to the use. S/X/Ka Tri-band Low-Earth Remote Sensing Satellite Ground Receiving system technical requirements

1 Scope

This standard specifies the function and technical specifications of S/X/Ka tri-band low-track remote sensing satellite ground receiving system. This standard is applicable to the development and performance of S/X/Ka tri-band terrestrial receiving system for the construction of low-orbit remote sensing satellites. (Such as X, Ka single band and S/X, S/Ka dual band, etc.) that receive high code rate satellite data, Can refer to use.

2 normative reference documents

The following documents are indispensable for the application of this document. For dated references, only the dated edition applies to this article Pieces. For undated references, the latest edition (including all modifications) applies to this document. Technical code for lightning protection of building electronic information system GB 50343 CCSDS131.0-B-2 synchronization and channel coding (TMSynchronization andChannelCoding) ETSIEN302307-1V1.4.1 digital video broadcasting for broadcast, interactive services, news interviews and other broadband satellites Second-generation frame structure, channel coding and modulation system Part 1. Satellite digital video broadcast second-generation standard (DigitalVideo Broadcasting (DVB); Secondgenerationframingstructure, channelcodingandmodulationsystems forBroadcasting, InteractiveServices, NewsGatheringandotherbroadbandsateliteapplications; Part 1. DVB-S2)

3 terms and definitions

The following terms and definitions apply to this document. 3.1 Gain versus noise temperature ratio gaintonoisetemperatureratio The ratio of the gain of the receiving system to the equivalent noise temperature of the receiving system at the same reference point. 3.2 Bit error rate biterrorrate The number of bits in the digital signal received within a certain period of time and the total number of bits of the digital signal received at the same time Ratio. 3.3 Tracking accuracy tracking accuracy In the automatic tracking mode, the deviation between the actual orientation of the antenna beam axis and the ideal orientation of the target. 3.4 Point to accuracy The deviation between the actual orientation of the antenna beam axis and the direction of the command. ......
