GB/T 33523.2-2017 English PDF

US$999.00 · In stock
Delivery: <= 6 days. True-PDF full-copy in English will be manually translated and delivered via email.
GB/T 33523.2-2017: Geometrical product specifications (GPS) -- Surface texture: Areal -- Part 2: Terms, definitions and surface texture parameters
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 33523.2-2017	999	Add to Cart	6 days	Geometrical product specifications (GPS) -- Surface texture: Areal -- Part 2: Terms, definitions and surface texture parameters	Valid

Similar standards

GB/T 34018   GB/T 33877   GB/T 32073   GB/T 33523.600   GB/T 33523.3   GB/T 33523.1

Basic data

Standard ID: GB/T 33523.2-2017 (GB/T33523.2-2017)
Description (Translated English): Geometrical product specifications (GPS) -- Surface texture: Areal -- Part 2: Terms, definitions and surface texture parameters
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: J04
Classification of International Standard: 17.040.20
Word Count Estimation: 50,589
Date of Issue: 2017-11-01
Date of Implementation: 2018-05-01
Regulation (derived from): National Standard Announcement 2017 No. 29
Issuing agency(ies): General Administration of Quality Supervision, Inspection and Quarantine of the People's Republic of China, Standardization Administration of the People's Republic of China

GB/T 33523.2-2017: Geometrical product specifications (GPS) -- Surface texture: Areal -- Part 2: Terms, definitions and surface texture parameters

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Geometrical product specifications (GPS) -Surface texture. Areal-Part 2. Terms, definitions and surface texture parameters ICS 17.040.20 J04 National Standards of People's Republic of China Product Geometry Specifications (GPS) Surface structure area method Part 2. Terms, definitions and surface texture parameters Geometricalproductspecifications (GPS) -Surfacetexture.Areal- Part 2.Terms, definitionsandsurfacetextureparameters (ISO 25178-2.2012, IDT) Posted.2017-11-01 2018-05-01 implementation General Administration of Quality Supervision, Inspection and Quarantine of People's Republic of China China National Standardization Administration released

Foreword

GB/T 33523 "Geometrical Product Specifications (GPS) Surface Area Method" is divided into the following sections. --- Part 2. Terms, definitions and surface texture parameters; --- Part 3. Specification operation set; --- Part 6. Classification of surface texture measurement methods; --- Part 7. Software measurement standards 1; --- Part 601. Contact (stylus) type instrument nominal characteristics; --- Part 602. Non-contact (confocal color-difference probe) type instrument of the nominal characteristics; --- Part 603 of the non-contact (phase-shift interference microscope) instrument of the nominal characteristics; --- Part 604. Non-contact (coherent scanning interference) type instrument nominal characteristics; --- Part 605. Non-contact (point AF) nominal characteristics of the instrument; --- Part 701. Contact (stylus) type instrument calibration and measurement standards. This section GB/T 33523 Part 2. This section drafted in accordance with GB/T 1.1-2009 given rules. This section uses the translation method identical with ISO 25178-2.2012 "Geometrical Product Specifications (GPS) Surface Area Method Part 2. Terms, definitions and surface texture parameters ". This part of the National Product Geometrical Specifications Standardization Technical Committee (SAC/TC240) and focal point. This part of the drafting unit.Huazhong University of Science and Technology, Machine Productivity Promotion Center, Shandong Road for Intelligent Technology Co., Ltd., Zhengzhou University, Beijing peak era Technology Co., Ltd. The main drafters of this section. Lu Wenlong, Ming Cuixin, Liu Xiaojun, Lang Yanmei, Zhao Fengxia, Hao Jianguo, Zhu Yue. Product Geometry Specifications (GPS) Surface structure area method Part 2. Terms, definitions and surface texture parameters

1 Scope

This section GB/T 33523 specifies the terms, definitions and parameters of the surface structure assessment method.

2 Normative references

The following documents for the application of this document is essential. For dated references, only the dated version applies to this article Pieces. For undated references, the latest edition (including all amendments) applies to this document. Geometrical product specifications (GPS) - Generic concept - Part 1. Geometrical norms and validated modes GB /Z 24637.1-2009 (ISO /T S17450-1.2005, IDT) Geometrical product specifications (GPS) filtering Part 1. Overview and basic concepts (ISO / TS16610-1.2006, IDT) ISO 25178-3-2012 Geometrical Product Specification (GPS) Surface Area Methodology Part 3 - Geo- metrical productspecifications (GPS) -Surfacetexture.Areal-Part 3.Specificationoperators)

3 Terms and definitions

GB /Z 26958.1-2011 and GB /Z 24637.1-2009 defined by the following terms and definitions apply to this document. 3.1 General Terms 3.1.1 Non-ideal surface model non-idealsurfacemodel Skin model skinmodel A model that physically exists and separates the entire workpiece from the surrounding medium. [GB /Z 24637.1-2009, Definition 3.2.2] 3.1.1.1 Mechanical surface mechanicalsurface With a radius of r of the actual surface of the workpiece corroded surface of the operation, that is, with an ideal radius r ball rolling The actual surface of the workpiece when the ball center of the track. [ISO 14406.2010, definition 3.1.1] 3.1.1.2 Electromagnetic surface electro-magneticsurface Electromagnetic radiation swept the surface of the workpiece when the non-ideal surface model. [ISO 14406.2010, definition 3.1.2] ......
