GB/T 32215-2015: Pneumatic fluid power -- Identification of ports and control mechanisms of control valves and other components
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 32215-2015	274	Add to Cart	3 days	Pneumatic fluid power -- Identification of ports and control mechanisms of control valves and other components	Valid

Similar standards

GB/T 40565.2   GB/T 40565.3   GB/T 40565.4   GB/T 32217   GB/T 32216

Basic data

Standard ID: GB/T 32215-2015 (GB/T32215-2015)
Description (Translated English): Pneumatic fluid power -- Identification of ports and control mechanisms of control valves and other components
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: J20
Classification of International Standard: 23.100.50
Word Count Estimation: 14,135
Date of Issue: 2015-12-10
Date of Implementation: 2016-07-01
Quoted Standard: GB/T 17446-2012
Adopted Standard: ISO 11727-1999, IDT
Regulation (derived from): National Standard Announcement 2015 No.38
Issuing agency(ies): General Administration of Quality Supervision, Inspection and Quarantine of the People's Republic of China, Standardization Administration of the People's Republic of China
Summary: This standard specifies the pneumatic directional control valve identification and labeling rules for air intake. Air intake includes a main gas line connection port, control of air routes connecting port and pilot gas line connection port. This standard applies to the electromagnetic coil cable identification and labeling rules. But not the internal electrical connections for integrated components, such as connection to the bus control system. This standard specifies the directional control valve control mechanism of identification and labeling rules. This standard specifies the filter, regulator, lubricator, check valves, flow control valves and other auxiliary components to identify inlet and (or) flows and labeling rules. This standard does not include pneumatic proportional control valve, pneumatic logic valves, cylinders, air motors, swing cylinder, intake port identification and labeling rules of the air compressor, air dryer or other elements in this standard, no particular description.

GB/T 32215-2015: Pneumatic fluid power -- Identification of ports and control mechanisms of control valves and other components

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
(Logo pneumatic control valves and other components of the air inlet and control mechanism) ICS 23.100.50 J20 National Standards of People's Republic of China Pneumatic control valves and other components of the air intake and Identifies the control mechanism (ISO 11727.1999, IDT) Issued on. 2015-12-10 2016-07-01 implementation Administration of Quality Supervision, Inspection and Quarantine of People's Republic of China Standardization Administration of China released

Table of Contents

Introduction Ⅲ Introduction Ⅳ 1 Scope 1 2 Normative references 1 3 Terms and definitions 4 General Principle 2 5 directional control valve 3 6 quick exhaust valve, shuttle valve and lock valve 5 7 shut-off valve 5 8 flow control valves, check valves and pressure relief valve 5 9 regulator and filter regulator 6 10 filters, oil mist and auxiliary elements 6 Example 6 11 12 label Description 6 Appendix A (informative) Symbol Recognition Example 7 Reference 9

Foreword

This standard was drafted in accordance with GB/T 1.1-2009 given rules. This standard uses the translation method identical with ISO 11727.1999 air inlet and control means "Pneumatic control valves and other components of Identity. " Correspondence between the consistency of the standards of international documents and normative references of the following documents. --- GB/T 17446-2012 Fluid power systems and components - Vocabulary (ISO 5598.2008, IDT). This standard made the following editorial changes. --- References used in the applicable file instead of the international documents and deleted the defunct ISO 5599-3.1990. The standard proposed by China Machinery Industry Federation. This standard by the National Standardization Technical Committee of hydraulic and pneumatic (SAC/TC3) centralized. This standard is drafted by. Ningbo Jia Ling Er Pneumatic Machinery Co., Ltd. Participated in the drafting of this standard. Fenghua Xingyu Electronics Co., Ltd. Ningbo aerodynamic package, Ningbo Sono industrial automation Equipment Co., Ltd., the National Air Quality Supervision and Inspection Center, Ningbo AirTAC Automation Industry Co., Ltd., Weihai Bo wins Qidongyeya Ltd., Yantai Future Automatic Equipment Co., Ltd, Shanghai sets of pneumatic three branch companies. The main drafters of this standard. single Junbo, Yanrui Kang, Cao Jianbo, Zhang Miao Ying, Xia Jiayong unit silver, Zhang excellent wave, Lupo, Ann Hui Wei, Fang Qinghua, Early Chen Yang, Zhang Zhiqing, Caochang Zhen, Guoxue Jing, Caixing Liang.

Introduction

In the pneumatic system, the power is through a closed loop control and compressed air to pass. The flow direction of the fluid flow channel depends pneumatic system components selected conduction and switching. Gas inlet and identification mechanism allows the user to control the pneumatic system components properly connected. Pneumatic control valves and other components of the air intake and Identifies the control mechanism

1 Scope

1.1 standard specifies the pneumatic directional control valve identification and labeling rules for air intake. Air intake includes a main gas line connection port, control of air routes connecting port And pilot gas line connection port. 1.2 This standard applies to the electromagnetic coil cable identification and labeling rules. But it does not apply to internal electrical connections integrated components, such as bus Control connection system. 1.3 This standard specifies the directional control valve control mechanism of identification and labeling rules. 1.4 This standard specifies the filter, regulator, lubricator, check valves, flow control valves and other auxiliary components inlet and (or) the flow of knowledge Do and labeling rules. 1.5 standard does not include pneumatic proportional control valve, pneumatic logic valves, cylinders, air motors, swing cylinder, air compressor, air dryer or Air intake identification and labeling rules for other elements in this standard, no particular description.

2 Normative references

The following documents for the application of this document is essential. For dated references, only the dated version suitable for use herein Member. For undated references, the latest edition (including any amendments) applies to this document. ISO 5598 Fluid power systems and components - Vocabulary (Fluidpowersystemsandcomponents-Vocabulary)

3 Terms and Definitions

As defined in ISO 5598 and the following terms and definitions apply to this standard. 3.1 Control means controlmechanism The elements providing means (e.g., a joystick, electromagnet) of the input signal. Note. Sometimes also used the term "manipulator" and "executing agency" represents this definition, but the "control means" is preferred. 3.2 The pilot inlet pilotcontrolport Change makes state control element is changed by the inlet pressure (pressure change usually signals from an external source). 3.3 External pilot air intake externalpilotsupplyport Receiving continuous, uninterrupted gas supply pressure from the outside air intake (as used by the control means). 3.4 Primary air inlet mainports When the control element operating mechanism, which communicates with another air intake or closed air intakes. 3.5 Solenoid cable solenoidlead Directly connecting wires to the solenoid coil. ......
