GB/T 32069-2015 English PDFUS$274.00 ยท In stock
Delivery: <= 3 days. True-PDF full-copy in English will be manually translated and delivered via email. GB/T 32069-2015: Earth-moving machinery -- Wheeled loader coupler for attachments Status: Valid
Basic dataStandard ID: GB/T 32069-2015 (GB/T32069-2015)Description (Translated English): Earth-moving machinery -- Wheeled loader coupler for attachments Sector / Industry: National Standard (Recommended) Classification of Chinese Standard: P97 Classification of International Standard: 53.1 Word Count Estimation: 14,156 Date of Issue: 2015-10-09 Date of Implementation: 2016-06-01 Quoted Standard: ISO 6165 Adopted Standard: ISO 23727-2009, IDT Regulation (derived from): National Standard Announcement 2015 No.31 Issuing agency(ies): General Administration of Quality Supervision, Inspection and Quarantine of the People's Republic of China, Standardization Administration of the People's Republic of China Summary: This standard applies to wheel loaders with a working mass of 8 000 kg to 17 500 kg as defined in IS0 6165. The attachment means may have alternative designs and dimensions, but may not have a wide range of attachment interchangeability. GB/T 32069-2015: Earth-moving machinery -- Wheeled loader coupler for attachments---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.Earth-moving machinery-Wheeled loader coupler for attachments ICS 53.100 P97 National Standards of People's Republic of China Moving machinery wheel loaders Connecting means of attachment (ISO 23727.2009, IDT) Issued on. 2015-10-09 2016-06-01 implementation Administration of Quality Supervision, Inspection and Quarantine of People's Republic of China Standardization Administration of China released ForewordThis standard was drafted in accordance with GB/T 1.1-2009 given rules. This standard uses the translation method identical with ISO 23727.2009 "moving machinery wheel loaders attachment connection means." Correspondence between the consistency of the standards of international documents and normative references of the following documents. --- GB/T 8498-2008 moving machinery - Basic types - Identification and terms and definitions (ISO 6165.2006, IDT). This standard and ISO 23727.2009 main editorial differences are as follows. --- 3 added connecting means and lifting link icon to facilitate understanding; --- By way of drawing FIG. 4 again been modified; --- Modified Figs. 3, 6, 7, 8 in the marked way; --- Deleted the title of Chapter 5, footnote 1). The standard proposed by China Machinery Industry Federation. This standard by the national earthmoving machinery Standardization Technical Committee (SAC/TC334) centralized. This standard is drafted by. Tianjin Institute of Mechanical Engineering. Participated in the drafting of this standard. Xiamen, Xiamen Engineering Machinery Company Limited. The main drafters of this standard. Chen Shu Qiao, Duan Lin, Li Wei Ping.IntroductionThe standard dimensions and deviation by means of provisions to ensure interchangeability wheel loaders appurtenances. This standard It does not limit the use of other connecting device structure, but the structure of the provisions of interchangeability more common connecting device. Design attachment bracket locking system self-determined by the manufacturer, this standard does not do limited. This standard is under development, not considered for the other wheel loaders, skid steer loader or backhoe loaders, but if the general attachment Require swaps, may apply. Attachment can be assembled without connecting means, mounted directly to the upgrade link. Moving machinery wheel loaders Connecting means of attachment1 ScopeThis standard applies to the quality of work defined in ISO 6165 is 8000kg ~ 17500kg of wheel loaders. Connecting means may There are alternative designs and sizes, but it may not have a wide range of interchangeable attachments.2 Normative referencesThe following documents for the application of this document is essential. For dated references, only the dated version suitable for use herein Member. For undated references, the latest edition (including any amendments) applies to this document. ISO 6165 Earth - moving machinery - Basic types - Identification and terms and definitions (Earth-movingmachinery-Basictypes- Identificationandtermsanddefinitions)3 Terms and DefinitionsThe following terms and definitions apply to this document. 3.1 Attachment attachment Mounted on wheel loaders lifting linkage connecting device parts assembly (buckets, forks, etc.). see picture 1. 3.2 Connecting device coupler Using a common connection face so many attachments mounted lift linkage end devices. see picture 1. 3.3 Lift Linkages liftinglinkage Mounted on the front wheel loaders, means the lift arm and bucket linkage thereof. see picture 1. 3.4 Quality of work operatingmass; OM Including with the host specified by the manufacturer of the work equipment most commonly used configuration and no-load accessory devices, the driver (75kg), the fuel tank to fill, Fuel and other liquids systems (such as hydraulic oil, transmission oil, engine oil, engine coolant) raised to the level specified by the manufacturer, sprinkler tank half Full quality (when applicable) when. NOTE 1. Non-driving machines not including the driver quality. Note 2. The ballast quality delivery may be included (such as when the manufacturer). [GB/T 21154-2014, the definition 3.2.1] 3.5 Connecting means maximum calibrated load couplermaximumloadrating The maximum vertical lifting force coupling means locking pin in the front portion of the horizontal distance of 800mm generated at, for connecting the device manufacturer to determine even Coupling device level, in order to select attachments match. ......Tips & Frequently Asked Questions:Question 1: How long will the true-PDF of GB/T 32069-2015_English be delivered?Answer: Upon your order, we will start to translate GB/T 32069-2015_English as soon as possible, and keep you informed of the progress. The lead time is typically 1 ~ 3 working days. The lengthier the document the longer the lead time.Question 2: Can I share the purchased PDF of GB/T 32069-2015_English with my colleagues?Answer: Yes. The purchased PDF of GB/T 32069-2015_English will be deemed to be sold to your employer/organization who actually pays for it, including your colleagues and your employer's intranet.Question 3: Does the price include tax/VAT?Answer: Yes. Our tax invoice, downloaded/delivered in 9 seconds, includes all tax/VAT and complies with 100+ countries' tax regulations (tax exempted in 100+ countries) -- See Avoidance of Double Taxation Agreements (DTAs): List of DTAs signed between Singapore and 100+ countriesQuestion 4: Do you accept my currency other than USD?Answer: Yes. If you need your currency to be printed on the invoice, please write an email to Sales@ChineseStandard.net. In 2 working-hours, we will create a special link for you to pay in any currencies. Otherwise, follow the normal steps: Add to Cart -- Checkout -- Select your currency to pay. |
