GB/T 304.3-2023: Spherical plain bearings - Part 3: Fits

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
ICS21:100:10 CCSJ11 National Standards of People's Republic of China Replace GB/T 304:3-2002 spherical plain bearings part 3 : fits Released on 2023-05-23 2023-12-01 Implementation State Administration for Market Regulation Released by the National Standardization Management Committee

foreword

This document is in accordance with the provisions of GB/T 1:1-2020 "Guidelines for Standardization Work Part 1: Structure and Drafting Rules for Standardization Documents" drafting: This document is the third part of GB/T 304 "Spherical Bearings": GB/T 304 has released the following parts: ---GB/T 304:1-2017 Classification of spherical plain bearings; ---GB/T 304:2-2015 Code method for spherical plain bearings; ---GB/T 304:9-2021 Spherical bearings Part 9: General technical rules: This document replaces GB/T 304:3-2002 "Spherical Bearing Fits": Compared with GB/T 304:3-2002, except for editorial changes, The main technical changes are as follows: a) Two chapters "Terms and Definitions" and "Symbols" have been added (see Chapters 3 and 4); b) Deleted the description of coordination category (see 3:1 and 3:2 of the:2002 edition); c) The requirements for the fit of large-size bearings are added (see Table 3, Table 4, Table A:1 and Table A:2); d) Changed the expression of the overall principle of coordination selection (see Chapter 5, 4:1~4:4 of the:2002 edition); e) Added the requirements for the thread tolerance zone connected with the bearing (see 6:2); f) Integrates the geometric tolerance table (see Table 3, Table 4 and Table 5 of the:2002 edition): Please note that some contents of this document may refer to patents: The issuing agency of this document assumes no responsibility for identifying patents: This document is proposed by China Machinery Industry Federation: This document is under the jurisdiction of the National Rolling Bearing Standardization Technical Committee (SAC/TC98): This document is drafted by: Luoyang Bearing Research Institute Co:, Ltd:, Fujian Longxi Bearing (Group) Co:, Ltd:, Taizhou Kejin Bearing Co:, Ltd: Co:, Ltd:, Henan University of Science and Technology, Zhejiang Jingjiu Bearing Industry Co:, Ltd:, China Railway Engineering Equipment Group Co:, Ltd: The main drafters of this document: Song Yucong, Yang Binghua, Lin Zhixun, Zhan Songhua, Qiu Ming, Lai Shenghua, Jia Lianhui: The release status of previous versions of this document and the documents it replaces are as follows: ---GB 304:3-1981, GB 304:3-1990, GB/T 304:3-2002; --- This is the third revision:

Introduction

Joint bearings are spherical plain bearings, mainly suitable for swinging motion, tilting motion and low-speed rotary motion: GB/T 304 "joint shaft "Bearing" is the basic and universal standard to guide the production of spherical plain bearings in my country, and consists of four parts: --- Part 1: Classification: It aims to clarify the product types and classification management of spherical plain bearings: --- Part 2: Code method: It aims to standardize the compilation method of joint bearing codes: --- Part 3: Coordination: It is designed to guide bearing users to correctly select the shaft and housing hole diameters that match the bearings according to the working conditions: Differential belt to ensure the normal operation of the bearing in use: --- Part 9: General technical rules: It aims to guide the production, selection, procurement, inspection and acceptance of bearings: spherical plain bearings part 3 : fits

1 Scope

This document specifies the cooperation between spherical plain bearings (hereinafter referred to as "bearings"), shafts and housing holes and threaded connections under general working conditions: The selection principle, the recommended tolerance zone, the geometric tolerance and surface roughness of the shaft and bearing housing hole, etc: This document applies to the design of bearing fits in the following cases: ---Bearing dimensions comply with GB/T 9161-2001 (except K series), GB/T 9162-2001, GB/T 9163-2001 (except for K, W series), GB/T 9164-2001 and the bearing nominal inner diameter d≤1250mm, nominal outer diameter D ≤2000mm; --- Bearing radial clearance conforms to the N group specified in GB/T 9161-2001 and GB/T 9163-2001; ---The matching shaft is a solid shaft or a thick-walled hollow shaft; ---The operating temperature does not exceed 100°C:

2 Normative references

The contents of the following documents constitute the essential provisions of this document through normative references in the text: Among them, dated references For documents, only the version corresponding to the date is applicable to this document; for undated reference documents, the latest version (including all amendments) is applicable to this document: GB/T 197 Common thread tolerances GB/T 1800:1 Geometric Product Specifications (GPS) Linear Dimensional Tolerances ISO Code System Part 1: Tolerances, Deviations and basis of cooperation GB/T 3944 Glossary of spherical plain bearings

3 Terms and Definitions

The terms and definitions defined in GB/T 1800:1 and GB/T 3944 apply to this document:

4 symbols

The following symbols apply to this document: D: Nominal outer diameter of the bearing Da: the nominal diameter of the housing hole that fits the bearing d: Nominal inner diameter of the bearing da: the nominal diameter of the shaft mated with the bearing t: cylindricity tolerance of the journal/housing surface mated with the bearing t1: Axial circular runout tolerance of the shaft shoulder/housing shoulder mated with the bearing t2: Parallelism tolerance of both ends of the gasket ΔDmp: Average outer diameter deviation of a single radial plane of the bearing Δdmp: Average inner diameter deviation of a single radial plane of the bearing ......
