GB/T 29530-2013 English PDF

US$134.00 · In stock
Delivery: <= 3 days. True-PDF full-copy in English will be manually translated and delivered via email.
GB/T 29530-2013: Hinged or pivoted doors -- Determination of the resistance to static torsion
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 29530-2013	134	Add to Cart	3 days	Hinged or pivoted doors -- Determination of the resistance to static torsion	Valid

Similar standards

GB/T 38264   GB/T 38388   GB/T 34555   GB/T 30661.10   GB/T 30661.11   GB/T 30595

Basic data

Standard ID: GB/T 29530-2013 (GB/T29530-2013)
Description (Translated English): Hinged or pivoted doors -- Determination of the resistance to static torsion
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: P32
Classification of International Standard: 91.060.50
Word Count Estimation: 7,747
Adopted Standard: ISO 9381-2005, IDT
Regulation (derived from): National Standards Bulletin 2013 No. 10
Issuing agency(ies): General Administration of Quality Supervision, Inspection and Quarantine of the People's Republic of China, Standardization Administration of the People's Republic of China
Summary: This standard specifies the mounted on the door frame of the open door, under the force of static distortion permanent deformation measurement method. This standard applies to all vertical swing or revolving doors installed anti- static torsional properti

GB/T 29530-2013: Hinged or pivoted doors -- Determination of the resistance to static torsion

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Hinged or pivoted doors. Determination of the resistance to static torsion ICS 91.060.50 P32 National Standards of People's Republic of China Swing and twisting revolving door antistatic performance measurement (ISO 9381.2005, IDT) Issued on. 2013-07-19 2014-03-01 implementation Administration of Quality Supervision, Inspection and Quarantine of People's Republic of China Standardization Administration of China released

Foreword

This standard was drafted in accordance with GB/T 1.1-2009 given rules. This standard uses the translation method identical with ISO 9381.2005 "Swing and a revolving door - anti-static distortion measured performance." The standard proposed by the Ministry of Housing and Urban-Rural Development of the People's Republic of China. This standard by the national building curtain wall windows and doors Standardization Technical Committee (SAC/TC448) centralized. This standard is drafted by. Guangdong Provincial Academy of Building Research. Participated in the drafting of this Standard. China Academy of Building Research, aluminum decoration Engineering Limited Guangzhou, Guangdong Hopewell Construction Hardware Ltd., Zhongshan Shengxing Co., Ltd., the State Building Materials Industry Building Hardware Plumbing Product Quality Supervision and Testing Center, Shanghai Jianke Inspection Limited Shenzhen Johor Bahru Curtain Technical Advisory Co., Ltd., Guangdong Kin Long Hardware Products Co., Ltd., Guangdong record high curtain Wall doors and windows Engineering Limited, Beijing Jiayu Fenestration Co., Ltd., Wuhan Hong Kong and Technology Co., Ltd.. The main drafters. Zhang Zuoping, Ho Xuan, Shi Man Cheung, Wang Hongtao, Chen Weiming, Liu Xuelin, Jiang Qinghai, Deng Guizhi, Xu Qin, Yi package, Li Baojun, Chia, Hu Hui, Li Jinggang.

Introduction

This standard specifies the doors of anti-static distortion performance test methods to test the door manufacturer's product meets the relevant requirements. even if Through a door in line with the requirements of this test does not necessarily mean that the whole assembly of the door jamb of the door meets these requirements. Swing and twisting revolving door antistatic performance measurement

1 Scope

This standard specifies mounted on the door frame opening the door, resulting in determination of permanent deformation under static twisting force. This standard applies to the determination of the performance of all anti-static vertically mounted swing or revolving doors distorted. NOTE. For example, in the case where neither damage nor injury door performance, when trying to open a jammed door, it is likely that there will be distortion forces. Test installed in a door frame on some specific purposes may also refer to when using this method.

2 test device

2.1 Test frame Test frame mount specimen should have sufficient rigidity to withstand the test load, no deformation that may affect the test results. 2.2 loading device Suitable heavy loading device or pressure pump device, accuracy of 2% and the pressure pump should be calibrated. 2.3 measuring device Analog or digital displacement meter accuracy of 0.01mm.

3 test sample

The test sample should be at a temperature of 15 ℃ ~ 30 ℃, relative humidity of sound environment of 25% to 75% in storage and testing. Designed to contain a door glass specimen shall be tested in accordance with the manufacturer's instructions to install the glass before.

4 Test Procedure

Open the door to the opposite door frame plane (90 ± 5) ° position, vertical without any constraints, the upper corner of the door locking side, away from the door each Mm points on the fixed side of (50 ± 5). Maintaining a hinge or hinge does not move in the door locking side bottom corner, away from the door (50 ± 5) mm on each side of the point, perpendicular to the plane of the door leaf Applying (200 ± 4) the level of N pre-load, holding (60 ± 5) s retreat to the load. Then after (60 ± 5) s, measured next door diagonal loading point Initial displacement at an accuracy of 0.1mm (see Figure 1). Static test load F is applied on the same mount point and held (300 ± 5) s. The maximum loading of the deformation measurement, accurate to 0.1mm. The load is removed and after (180 ± 5) s in the corner of the door at the loading point was measured again. All loads should increase each level of maximum 100N apply and release a smooth, precision of 2% per level load times should not be less than 1s; If you continue to load should be maintained at the same rate, to avoid the dynamic effects. ......
