GB/T 29168.2-2024 English PDFUS$1319.00 ยท In stock
Delivery: <= 8 days. True-PDF full-copy in English will be manually translated and delivered via email. GB/T 29168.2-2024: Petroleum and natural gas industries - Bends, fittings and flanges for pipeline transportation systems - Part 2: Fittings Status: Valid GB/T 29168.2: Historical versions
Basic dataStandard ID: GB/T 29168.2-2024 (GB/T29168.2-2024)Description (Translated English): Petroleum and natural gas industries - Bends, fittings and flanges for pipeline transportation systems - Part 2: Fittings Sector / Industry: National Standard (Recommended) Classification of Chinese Standard: E16 Classification of International Standard: 75.200 Word Count Estimation: 66,663 Date of Issue: 2024-09-29 Date of Implementation: 2025-01-01 Older Standard (superseded by this standard): GB/T 29168.2-2012 Issuing agency(ies): State Administration for Market Regulation, China National Standardization Administration GB/T 29168.2-2024: Petroleum and natural gas industries - Bends, fittings and flanges for pipeline transportation systems - Part 2: Fittings---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order. ICS 75.200 CCSE16 National Standard of the People's Republic of China Replaces GB/T 29168.2-2012 Bend pipes for oil and gas industry pipeline transportation systems, Pipe fittings and flanges Part 2.Pipe fittings Part 2.Fittings, MOD) Published on September 29, 2024, implemented on January 1, 2025 State Administration for Market Regulation The National Standardization Administration issued Table of ContentsPreface III Introduction V 1 Scope 1 2 Normative references 1 3 Terms and Definitions 2 4 Symbols and abbreviations 3 4.1 Symbols 3 4.2 Abbreviations 3 5 Pipe fitting code 4 6 Pressure rating and design 4 6.1 General 4 6.2 Tee 4 6.3 Eccentric reducer 4 7 Information provided by the purchaser 5 7.1 General Information 5 7.2 Supplementary information 5 8 Manufacturing 5 8.1 Manufacturing process specifications 5 8.2 Raw materials 7 8.3 Pipe fittings production 8 9 Tests, inspections and technical requirements 11 9.1 General requirements 11 9.2 Test and inspection frequency 11 9.3 Re-test requirements 12 9.4 Chemical composition 12 9.5 Mechanical test 14 9.6 Nondestructive Testing 22 9.7 Size 23 9.8 Measurement 25 9.9 Hydrostatic test 25 10 Logo 25 11 Protection 26 12 Packaging and transportation 26 Appendix A (informative) Structural changes of this document compared with ISO 15590-2.202127 Appendix B (Informative) Technical differences between this document and ISO 15590-2.2021 and their causes 29 Appendix C (Normative) Design Calculation 33 C.1 Elbow 33 C.2 Cap 33 C.3 Reducer (eccentric or concentric) 33 C.4 Tee (equal diameter and reducing diameter) 34 C.5 Other design calculations 34 Appendix D (Normative) Design Verification Test 35 D.1 Required tests 35 D.2 Test pipe fittings 35 D.3 Assembly 35 D.4 Test methods and equipment 35 D.5 Verification test strength calculation 36 D.6 Test procedure 36 D.7 Applicability of test results 37 D.8 Test report 37 D.9 Third-party supervision38 D.10 Saving and modifying results 38 Appendix E (Informative) DN1000 and DN1200 Tee Design Verification Test Recommended Wall Thickness 39 Appendix F (Informative) Sleeve connection 41 Appendix G (Normative) Sampling Requirements 42 Appendix H (Informative) Steel Grade Comparison 45 Appendix I (Informative) Pipe Fittings Dimensions 46 Appendix J (Informative) Tee Geometric Dimensions Testing Method 57 References 59ForewordThis document is in accordance with the provisions of GB/T 1.1-2020 "Guidelines for standardization work Part 1.Structure and drafting rules for standardization documents" Drafting. This document is Part 2 of GB/T 29168 "Pipe elbows, fittings and flanges for pipeline transportation systems in the petroleum and natural gas industry". GB/T 29168 has published the following parts. --- Part 1.Induction heating pipe bending; --- Part 2.Pipe fittings; --- Part 3.Flanges; --- Part 4.Cold-bent pipes. This document replaces GB/T 29168.2-2012 "Induction heating elbows, pipe fittings and pipe methods for pipeline transportation systems in the petroleum and natural gas industry" Compared with GB/T 29168.2-2012, in addition to structural adjustments and editorial changes, the main technical changes are as follows. a) Added chemical composition index requirements for pipe fittings for low temperature environments (see 9.4); b) Added protection requirements for pipe fittings (see Chapter 11); c) Added packaging and transportation requirements for pipe fittings (see Chapter 12). This document is modified to adopt ISO 15590-2.2021 "Factory elbows, fittings and flanges for pipeline transportation systems in the petroleum and natural gas industry" Part 2.Pipe fittings. Compared with ISO 15590-2.2021, this document has many structural adjustments. The structural number changes between the two documents are listed below. See Appendix A for the table. This document has many technical differences compared to ISO 15590-2.2021. A list of these technical differences and their reasons is given in Appendix B. The following editorial changes were made to this document. --- In order to coordinate with the existing standards, the name of the standard is changed to "Bends, pipe fittings and pipes for pipeline transportation systems in the petroleum and natural gas industry Part 2.Pipe fittings; --- Deleted the note of 7.1; --- Changed the original Figures 1, 2 and 3 to Figures 1a), b) and c); --- Deleted the note of 9.6.3.1; --- Added the note to C.1; --- Added Appendix E (informative) "Recommended wall thickness for DN1000 and DN1200 tee design verification test"; --- Added Appendix F (informative) "Sleeve connection"; --- Added Appendix H (informative) "Steel Grade Comparison"; --- Added Appendix I (informative) "Pipe fittings dimensions"; --- Added Appendix J (informative) "Test method for geometric dimensions of tee joints". Please note that some of the contents of this document may involve patents. The issuing organization of this document does not assume the responsibility for identifying patents. This document was proposed and coordinated by the National Petroleum and Natural Gas Standardization Technical Committee (SAC/TC355). This document was drafted by. China National Petroleum Corporation Engineering Materials Research Institute Co., Ltd., Special Equipment Bureau of the State Administration for Market Regulation, China Special Equipment Testing and Research Institute, China Petroleum and Natural Gas Pipeline Engineering Co., Ltd., Julong Steel Pipe Co., Ltd., Hebei Yanshan County Electric Power Pipe Fittings Co., Ltd., Hebei Hengtong Pipe Fittings Group Co., Ltd., Zhengzhou Wanda Heavy Industry Co., Ltd., Hebei Xintai Pipe Technology Co., Ltd., China Petroleum Pipeline Machinery Manufacturing Co., Ltd., Hebei Huizhong Pipeline Equipment Co., Ltd., and Xi'an Sanhuan Oil Pipe Technology Co., Ltd. The main drafters of this document are. Wang Peng, Liu Yingying, Qin Xianyong, Liu Changzheng, Chi Qiang, Li Weiwei, Fang Wei, Xu Ting, Wang Cheng, Zhao Zhiwei, Liu Fulin, Yanqing Ji, Fufeng Zhang, Fengshuo Hu, Yunlan Yang, Lijun Yan, and Jiantao Meng. This document was first published in.2012 and this is the first revision.IntroductionBends, pipe fittings and flanges are important and indispensable structural parts for the construction of long-distance pipelines and valve chambers at stations. The procurement and application of pipes for industrial pipeline transportation systems have been formulated for induction heating bends, pipe fittings, This document is based on ISO 15590-2, and refers to relevant domestic and foreign standards. The research results and practical experience of basic research and technical standards for pipe fittings used in oil and gas pipeline construction. GB/T 29168 is planned to consist of four parts, including production process, geometric dimensions and inspection requirements. --- Part 1.Induction heating pipe bending. The purpose is to specify the application of carbon steel or low alloy steel seamless steel pipe, high frequency welded pipe and straight seam buried pipe Technical requirements for the design, manufacture and inspection of induction heating bends made from arc-welded steel pipe as parent pipe. --- Part 2.Pipe fittings. The purpose is to specify the pipe fittings applicable to the use of carbon steel or low alloy steel plates, seamless steel pipes and welded steel pipes. Technical requirements for the manufacture and inspection of welded pipe fittings. --- Part 3.Flanges. The purpose is to specify neck welding flanges and blind flanges suitable for carbon steel or low alloy steel forgings, as well as anchoring Technical requirements for the manufacture and inspection of flanges, slip-on flanges and orifice flanges. --- Part 4.Cold-bent pipes. The purpose is to specify the radius of application of low-carbon low-alloy seamless and welded steel pipes not less than 5OD, Technical requirements for the design, manufacture and inspection of cold-bent pipe produced by cold bending in factories and on site. During the construction of pipeline engineering, in order to meet the needs of medium diversion, diversion and relief, and improve the main steel pipe in the pipeline system under harsh loads, Due to the abnormal external loads, a large number of pipeline structures are often required in the construction of pipeline laying, valve rooms, stations and booster stations. Pipeline structural parts can be divided into elbows, pipe fittings and flanges according to their geometric shapes and application environments. Different, pipe bending can be divided into induction heating pipe bending and cold bending, tees can be divided into welding tees, hot extrusion tees, cold pressing tees, etc. GB/T 29168 is divided into four parts based on factors such as type, geometry, production and processing technology, and inspection requirements. According to the different requirements of pipe processing technology, the pipe bending is divided into the first part, induction heating pipe bending and the fourth part, cold bending; the second part is made of carbon steel or Technical requirements for pipe fittings made of low alloy steel seamless pipes and welded steel pipes, such as elbows, caps, tees, reducers, etc.; Part 3 is Technical requirements for carbon steel and low alloy steel forged flanges. Bend pipes for oil and gas industry pipeline transportation systems, Pipe fittings and flanges Part 2.Pipe fittings1 ScopeThis document specifies the manufacture, testing and inspection of pipe fittings for pipeline transportation systems designed in accordance with GB 50251, GB 50253 and GB/T 24259. Inspection, technical requirements, marking, protection, packaging and transportation, etc. This document applies to butt-welded pipe fittings (such as elbows, pipe caps, The manufacture and inspection of pipe fittings for piping systems designed in accordance with other specifications shall refer to use. This document does not apply to the selection of shop welding materials or accessories.2 Normative referencesThe contents of the following documents constitute essential clauses of this document through normative references in this document. For referenced documents without a date, only the version corresponding to that date applies to this document; for referenced documents without a date, the latest version (including all amendments) applies to This document. GB 150.3 Pressure Vessels Part 3.Design GB/T 228.1 Tensile tests on metallic materials - Part 1.Test methods at room temperature (GB/T 228.1-2021, ISO 6892-1. 2019,MOD) GB/T 228.2 Tensile tests on metallic materials Part 2.High temperature test methods (GB/T 228.2-2015, ISO 6892-2. 2011,MOD) GB/T 229 Charpy pendulum impact test method for metallic materials (GB/T 229-2020, ISO 148-1.2016, MOD) GB/T 232 Metallic materials bending test method (GB/T 232-2010, ISO 7438.2005, MOD) GB/T 713.2 Steel plates and strips for pressure equipment Part 2.Non-alloy steels and alloy steels with specified temperature properties GB/T 2970 Ultrasonic testing method for thick steel plates GB/T 2975 Sampling location and specimen preparation for mechanical properties tests of steel and steel products (GB/T 2975-2018, ISO 377. 2017,MOD) GB/T 4157 Laboratory test method for resistance of metals to sulfide stress cracking and stress corrosion cracking in hydrogen sulfide environments GB/T 4340.1 Metallic materials Vickers hardness test Part 1.Test method (GB/T 4340.1-2024, ISO 6507- 1.2023,MOD) GB/T 6394-2017 Determination of average grain size of metals GB/T 8650 Evaluation method for resistance of pipeline steel and pressure vessel steel to hydrogen induced cracking GB/T 9445 Qualification and certification of nondestructive testing personnel (GB/T 9445-2024, ISO 9712.2021, IDT) GB/T 9711 Steel pipes for pipeline transportation systems in the petroleum and natural gas industries (GB/T 9711-2023, ISO 3183.2019, MOD) GB/T 11345 Ultrasonic testing technology, testing levels and assessment for non-destructive testing of welding (GB/T 11345-2013, ISO 17640-11.2010,MOD) GB/T 12467.2 Quality requirements for fusion welding of metallic materials Part 2.Complete quality requirements (GB/T 12467.2-2009, ISO 3834-2.2005,IDT) GB/T 17600.1 Elongation conversion of steel Part 1.Carbon steel and low alloy steel (GB/T 17600.1-1998, ...... |
