GB/T 28864.2-2012: Terms and nomenclature for cores made of magnetically soft ferrites -- Part 2: Reference of dimensions
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 28864.2-2012	134	Add to Cart	3 days	Terms and nomenclature for cores made of magnetically soft ferrites -- Part 2: Reference of dimensions	Valid

Similar standards

GB/Z 40842   GB/T 36103.1   SJ/T 10410   GB/T 28869.3   GB/T 28869.2   GB/T 28868

Basic data

Standard ID: GB/T 28864.2-2012 (GB/T28864.2-2012)
Description (Translated English): Terms and nomenclature for cores made of magnetically soft ferrites -- Part 2: Reference of dimensions
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: L19
Classification of International Standard: 29.100.10
Word Count Estimation: 7,794
Adopted Standard: IEC 60401-2-2003, IDT
Regulation (derived from): National Standards Bulletin 2012 No. 28
Issuing agency(ies): General Administration of Quality Supervision, Inspection and Quarantine of the People's Republic of China, Standardization Administration of the People's Republic of China
Summary: This standard specifies the ferrite (magnetic oxide) core size of the main features of the shape identification code defined method. This section is intended to enable manufacturers, standards writers and users on the design, form and dimension unified ca

GB/T 28864.2-2012: Terms and nomenclature for cores made of magnetically soft ferrites -- Part 2: Reference of dimensions

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Terms and nomenclature for cores made of magnetically soft ferrites Part 2. Reference of dimensions ICS 29.100.10 L19 National Standards of People's Republic of China Ferrite core Definition Part 2. Dimensions Part 2. Referenceofdimensions (IEC 60401-2.2003, IDT) Issued on. 2012-11-05 2013-02-15 implementation Administration of Quality Supervision, Inspection and Quarantine of People's Republic of China Standardization Administration of China released

Foreword

GB/T 28864 "ferrite core definitions of the terms" is divided into three parts. --- Part 1. terms of physical defects; --- Part 2. Dimensions; --- Part 3. Transformers and inductors factory core catalog guidance concerning ferrite material information. This section GB/T 28864 Part 2. This section drafted in accordance with GB/T 1.1-2009 given rules. This section uses the translation method is equivalent to using IEC 60401-2.2003 "ferrite core Definition - Part 2. Dimensions." For ease of use, this part of IEC 60401-2.2003 made the following editorial changes. a) "this International Standard" be replaced by "this section"; b) Remove the preface to international standards. This part is proposed by the Ministry of Industry and Information Technology of the People's Republic of China. This part of the National Magnetic components and ferrite materials Standardization Technical Committee (SAC/TC89) centralized. This section drafted by. China Electronics Technology Group Corporation ninth Institute. The main drafters of this section. Hu Bin. Ferrite core Definition Part 2. Dimensions

1 Scope

This section GB/T 28864 given on ferrite (magnetic oxide) form the main core feature size identification code set Righteous way. The purpose of this section is to enable manufacturers, standards writers and users uniform size in the design, form and catalog Callout.

2 Basic Principles

Dimensions are indicated in uppercase letters of the alphabet. Each shape of the ferrite core size only by a letter. Paired core 2B and 2D represent letters, such as EP-shaped, PQ-shaped pot-shaped cores and RM. Method 3 Dimensions Main dimensions ferrite core shapes alphabetically with uppercase English letters, are shown in Table 1 and Table 2. Remaining secondary core Size standard writers should own label. Table 1 toroidal core Dimension Meaning letter size A ring-shaped core outside diameter B ring core inner diameter C ring core height Table 2 ferrite core dimension Meaning letter size A total length of the rear wall or the core diameter B core outer leg length or height C core width D inner core leg length or depth E bobbin core width or pitch F center column thickness or diameter G line aperture or groove width H aperture center column J RM core width parallel sides ......
