GB/T 28278.1-2012 English PDFUS$574.00 ยท In stock
Delivery: <= 3 days. True-PDF full-copy in English will be manually translated and delivered via email. GB/T 28278.1-2012: Plain bearings -- Hydrostatic plain journal bearings without drainage grooves under steady-state conditions -- Part 1: Calculation of oil-lubricated plain journal bearings without drainage grooves Status: Valid
Basic dataStandard ID: GB/T 28278.1-2012 (GB/T28278.1-2012)Description (Translated English): Plain bearings -- Hydrostatic plain journal bearings without drainage grooves under steady-state conditions -- Part 1: Calculation of oil-lubricated plain journal bearings without drainage grooves Sector / Industry: National Standard (Recommended) Classification of Chinese Standard: J12 Classification of International Standard: 21.100.10 Word Count Estimation: 29,252 Quoted Standard: GB/T 28278.2-2012; ISO 3448-1992 Adopted Standard: ISO 12168-1-2001, IDT Regulation (derived from): National Standards Bulletin No. 9 of 2012 Issuing agency(ies): General Administration of Quality Supervision, Inspection and Quarantine of the People's Republic of China, Standardization Administration of the People's Republic of China Summary: This standard applies to steady state conditions hydrostatic radial sliding bearings. GB/T 28278 This part is not only for the oil chamber between the back sump lubrication. GB/T 28278.1-2012: Plain bearings -- Hydrostatic plain journal bearings without drainage grooves under steady-state conditions -- Part 1: Calculation of oil-lubricated plain journal bearings without drainage grooves---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order. Plain bearings.Hydrostatic plain journal bearings without exploitation grooves under steady-state conditions.Part 1. Calculation of oil-lubricated plain journal bearings without delete grooves ICS 21.100.10 J12 National Standards of People's Republic of China Sliding bearings do not return to the tank under steady state conditions Pressure radial plain bearings - Part 1. Without return sumps Calculation of oil lubricated radial plain bearings understeady-stateconditions-Part 1. Calculationofoil-lubricatedplain (ISO 12168-1..2001, IDT) 2012-05-11 release 2012-12-01 implementation General Administration of Quality Supervision, Inspection and Quarantine of the People's Republic of China China National Standardization Management Committee released ForewordGB/T 28278 "Sliding bearings without steady-state under the conditions of non-return sump fluid hydrostatic radial bearing" consists of the following two parts. - Part 1. Calculation of lubricating radial plain bearings without oil return; - Part 2. Characteristic values calculated by lubricating radial plain bearings without oil return. This part is part 1 of GB/T 28278. This part is drafted in accordance with the rules given in GB/T 1.1-2009. This part uses the translation method equivalent to ISO 12168-1..2001 "Sliding bearings without steady-state conditions without return tank Hydrostatic radial Plain bearings - Part 1. Calculation of lubricating radial plain bearings without oil return. And the normative reference in this part of the international standards are consistent with the relationship between China's standards are as follows. Industrial fluid lubricants ISO viscosity classification (egvISO 3448..1992) GB/T 3141-1994. This part is made by the China Machinery Industry Federation. This part is headed by the National Standardization Technical Committee for Plain Bearings (SAC/TC236). This part is responsible for drafting units. China Machine Productivity Promotion Center. This part participates in the drafting unit. Xi'an Jiaotong University, Zhejiang Zhuji Shenfa Bearing Co., Ltd., Shenke sliding bearing Co., Ltd., Zhejiang Dongfang Sliding Bearing Co., Ltd., Dongfang Steam Turbine Co., Ltd., Dongfang Motor Co., Ltd., Lin'an Orient Bearing Co., Ltd.IntroductionThe working principle of the hydrostatic bearing is that the supporting force of the lubrication is caused by the external lubricating oil pressure. The characteristic of static pressure lubrication is wear Small size, low noise, wide working speed range and high stiffness and high impedance. These properties determine the hydrostatic plain bearings in many cases, such as The special importance of the application in machine tools. The basic principle of this part of GB/T 28278 is applicable to the different number of oil chambers, similar to the geometric shape of the oil cavity, Pressure bearing. This part of GB/T 28278 is only for hydrostatic radial plain bearings without oil return between oil chambers. With a return oil Slot bearings compared to this type of bearing in the same stiffness characteristics required under the required power is smaller. The lubricating oil is pressurized by a constant linear pressure pump (system pressure pen = constant) through a preloaded linear restrictor, such as a capillary restrictor. The calculation procedure listed in this part of GB/T 28278 can be used to calculate and evaluate hydrostatic bearings with a given design parameter, or For the design of some parameters of variable hydrostatic bearings. In addition, this part of GB/T 28278 also contains the design of the required lubrication system, Including the calculation of throttle parameters. Sliding bearings do not return to the tank under steady state conditions Pressure radial plain bearings - Part 1. Without return sumps Calculation of oil lubricated radial plain bearings1 ScopeThis part of GB/T 28278 is suitable for static pressure radial plain bearings under steady state conditions. This part of GB/T 28278 is only for lubrication between the oil chambers without the oil return.2 normative reference documentsThe following documents are indispensable for the application of this document. For dated references, only the dated version is used in this article Pieces. For undated references, the latest edition (including all modifications) applies to this document. GB/T 28278.2-2012 Plain bearings without return sumps under steady state conditions Hydrostatic radial bearings - Part 2. No (ISO 12168-2..2001, IDT) for lubricating radial plain bearings ISO 3448..1992 Industrial liquid lubricants ISO viscosity classification (Industrialliquidlubricants-ISO viscosity) classification3 Calculate the basic principles and boundary conditionsThe purpose of this part of the calculation is to determine the bearing operating conditions, geometry and lubricating oil and other related hydrostatic bearing operating parameters, That is to determine the bearing eccentricity, carrying capacity, oil film stiffness, oil pressure, oil flow, friction power, pump power and temperature rise. except Considering the static pressure of the bearing, the hydrodynamic effect of the bearing is also approximated. The Reynolds equation provides a theoretical basis for the calculation of hydrostatic bearings. However, in most practical applications, it can be reached by approximate calculation To the desired precision. The approximation used in this section is to use two integral equations to describe the state of the oil flowing through the bearing and journal surface gaps. These two integral equations can be derived from the Reynolds equation using specific boundary conditions. The Haagen-Burtonian law describes the parallel surface gap The pressure flow, the Kurt formula describes the shear flow generated by the journal rotation in the bearing clearance. The theoretical basis of the computational process is given in Appendix A. A detailed description of the. The following important assumptions are used in the calculation process given in this section. a) The flow of the lubricating oil is laminar flow. b) The lubricating oil is completely adhered to the lubricated surface. c) Lubricants are incompressible Newtonian fluids. d) The lubricating oil in the entire lubrication gap and in the front restrictor is of equal viscosity. e) The lubrication gap is completely filled with lubricating oil. f) The pressure gradient in the film thickness direction is zero. g) The journal and bearing surfaces that make up the lubrication gap are rigid. h) The radius of curvature of the relative moving surface is much greater than the thickness of the lubricating film. i) The thickness of the lubricating film is set in the axial direction (z-axis direction). ......Tips & Frequently Asked Questions:Question 1: How long will the true-PDF of GB/T 28278.1-2012_English be delivered?Answer: Upon your order, we will start to translate GB/T 28278.1-2012_English as soon as possible, and keep you informed of the progress. The lead time is typically 1 ~ 3 working days. The lengthier the document the longer the lead time.Question 2: Can I share the purchased PDF of GB/T 28278.1-2012_English with my colleagues?Answer: Yes. The purchased PDF of GB/T 28278.1-2012_English will be deemed to be sold to your employer/organization who actually pays for it, including your colleagues and your employer's intranet.Question 3: Does the price include tax/VAT?Answer: Yes. Our tax invoice, downloaded/delivered in 9 seconds, includes all tax/VAT and complies with 100+ countries' tax regulations (tax exempted in 100+ countries) -- See Avoidance of Double Taxation Agreements (DTAs): List of DTAs signed between Singapore and 100+ countriesQuestion 4: Do you accept my currency other than USD?Answer: Yes. If you need your currency to be printed on the invoice, please write an email to Sales@ChineseStandard.net. In 2 working-hours, we will create a special link for you to pay in any currencies. Otherwise, follow the normal steps: Add to Cart -- Checkout -- Select your currency to pay. |
