GB/T 27797.5-2011 English PDF

US$214.00 · In stock
Delivery: <= 3 days. True-PDF full-copy in English will be manually translated and delivered via email.
GB/T 27797.5-2011: Fibre-reinforced plastics -- Methods of producing test plates -- Part 5: Filament winding
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 27797.5-2011	214	Add to Cart	3 days	Fibre-reinforced plastics -- Methods of producing test plates -- Part 5: Filament winding	Valid

Similar standards

GB/T 40388   GB/T 39491   GB/T 36262   GB/T 27797.4   GB/T 27797.11   GB/T 27797.1

Basic data

Standard ID: GB/T 27797.5-2011 (GB/T27797.5-2011)
Description (Translated English): Fibre-reinforced plastics -- Methods of producing test plates -- Part 5: Filament winding
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: Q23
Classification of International Standard: 83.120
Word Count Estimation: 11,195
Date of Issue: 2011-12-30
Date of Implementation: 2012-08-01
Quoted Standard: ISO 1268-1
Adopted Standard: ISO 1268-5-2001, IDT
Regulation (derived from): National Standard Approval Announcement 2011 No.23
Issuing agency(ies): General Administration of Quality Supervision, Inspection and Quarantine of the People's Republic of China, Standardization Administration of the People's Republic of China
Summary: This standard specifies the use of fiber reinforced plastic wrapped prepared plate method. In this method the glass fiber rovings and the thermosetting resin material (excluding the pre-impregnated fibers). This section provides under way to enhance the optimal conditions for the preparation of industrialization board, the board in these tests can be used to cut a variety of mechanical properties of the test specimen. This section GB/T 27797 suitable for the preparation of glass fiber reinforced polyester plastic or epoxy resin, but may be extended to other types of resins and reinforcing material. GB/T 27797 of this part and GB/T 27797. 1 be used.

GB/T 27797.5-2011: Fibre-reinforced plastics -- Methods of producing test plates -- Part 5: Filament winding

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Fibre-reinforced plastics. Methods of producing test plates. Part 5. Filament winding ICS 83.120 Q23 National Standards of People's Republic of China Preparation method of fiber reinforced plastic test board Part 5. winding forming Part 5. Filamentwinding (ISO 1268-5..2001, IDT) 2011-12-30 release 2012-08-01 implementation General Administration of Quality Supervision, Inspection and Quarantine of the People's Republic of China China National Standardization Management Committee released

Foreword

GB/T 27797 "fiber reinforced plastic test plate preparation method" is divided into 11 parts. - Part 1. General; - Part 2. Contact and spray molding; - Part 3. wet molding; - Part 4. Prepreg molding; - Part 5. winding forming; - Part 6. Pultrusion; - Part 7. Resin transfer molding; - Part 8. SMC and BMC molding; - Part 9. GMT/STC molding; - Part 10. BMC and other long fiber molding compounds Injection molding general principles and general purpose molding; Part 11. BMC and other long fiber molding compounds injection molding small square. This part is part 5 of GB/T 27797. This part is drafted in accordance with the rules given in GB/T 1.1-2009. This part uses the translation method equivalent to ISO 1268-5..2001 (E) "Fiber Reinforced Plastics Test Plate Preparation Method Part 5. Winding forming ". In this part of the normative reference to the international documents have a consistent correspondence between the following documents. Fiber reinforced plastics test boards - Part 1. General principles (ISO 1268-1..2001, IDT) GB/T This section makes the following editorial changes. --- to some of the statements applied to international standards to apply to the formulation of our standards; --- Add the bar in 8.5 and 9. This section is proposed by the China Building Materials Federation. This part of the National Fiber Reinforced Plastics Standardization Technical Committee (SAC/TC39) centralized. This part of the drafting unit. Beijing glass steel composite materials Co., Ltd., China Ordnance Industry Group, five three research institutes, Changzhou Tianma Group Limited company. The main drafters of this part. Ning Zhenlian, Zhang Liping, Chen Hailing, Xuan Weidong, Ma Yujing. Preparation method of fiber reinforced plastic test board Part 5. winding forming

1 Scope

This part of GB/T 27797 specifies a method of preparing a fiber-reinforced plastic sheet by a winding method using a glass fiber roving and Thermosetting resin as raw material (excluding pre-impregnated fibers). This section specifies the preparation of unidirectional reinforcing plates under optimal industrial conditions, which can be cut on these test panels for testing various mechanical properties Can sample. This part of GB/T 27797 is mainly applicable to glass fiber reinforced plastics made of polyester resin or epoxy resin, but can also be expanded To other types of resins and reinforcing materials. This part of GB/T 27797 is used in conjunction with GB/T 27797.1. Note. For ease of understanding of this method, the term "roving" is used throughout the text and includes yarn unless otherwise specified.

2 normative reference documents

The following documents are indispensable for the application of this document. For dated references, only the dated edition applies to this article Pieces. For undated references, the latest edition (including all modifications) applies to this document. ISO 1268-1 fiber reinforced plastic test plate preparation method Part 1. General (Fibre-reinforcedplastics- Methodsofproducingtestplates-Part 1. Generalconditions)

3 healthy and safe

See ISO 1268-1.

4 principle

A roving (or number of roving beams) is impregnated with resin, wrapped in several layers. Install the outer template on the mandrel to obtain the test plate Find the final thickness. The curing may be carried out in a press with a heating plate or in an oven. The method can simultaneously prepare two identical test boards.

5 material

5.1 roving This method is suitable for all yarns with a linear density of.200 to 4800tex. The yarns with lower linear density can be combined to make their threads The density is.200 to 4800tex (for example, 10 bundles 22tex is 220tex). 5.2 resin system The recommended resin system (polyester or epoxy curing system) should meet the following properties. ......
