GB/T 26678-2011: Electrical control system of machine tools -- The requirements of processing program for CNC surface grinding machines
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 26678-2011	299	Add to Cart	3 days	Electrical control system of machine tools -- The requirements of processing program for CNC surface grinding machines	Valid

Similar standards

GB/T 28615   GB/T 24343   GB/T 24344   GB/T 26676   GB/T 26677   GB/T 26675

Basic data

Standard ID: GB/T 26678-2011 (GB/T26678-2011)
Description (Translated English): Electrical control system of machine tools -- The requirements of processing program for CNC surface grinding machines
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: J50
Classification of International Standard: 25.040.20
Word Count Estimation: 13,176
Date of Issue: 2011-06-16
Date of Implementation: 2011-12-01
Quoted Standard: GB 5226.1-2008; GB/T 8129-1997; GB 15760-2004; GB/T 19660-2005
Regulation (derived from): Announcement of Newly Approved National Standards No. 9 of 2011
Issuing agency(ies): General Administration of Quality Supervision, Inspection and Quarantine of the People's Republic of China, Standardization Administration of the People's Republic of China
Summary: This standard specifies the CNC surface grinder should possess basic machining program also provides the processing procedures and requirements established in the program name. This standard applies to including CNC horizontal spindle and rectangular table surface grinder, CNC horizontal axis rotary table surface grinder, CNC Spindle Surface Grinding Machine, CNC spindle and round table surface grinder, CNC gantry CNC surface grinding machine including flat grinder.

GB/T 26678-2011: Electrical control system of machine tools -- The requirements of processing program for CNC surface grinding machines

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Electrical control system of machine tools. The requirements of processing program for CNC surface grinding machines ICS 25.040.20 J50 National Standards of People's Republic of China Machine electrical control system CNC surface grinder machining program requirements Issued on. 2011-06-16 2011-12-01 implementation Administration of Quality Supervision, Inspection and Quarantine of People's Republic of China Standardization Administration of China released

Table of Contents

Introduction Ⅲ 1 Scope 1 2 Normative references 1 3 Terms and definitions 4 CNC surface grinder with basic machining program 2 4.1 Overview 2 4.2 CNC horizontal axis moments Taiwan surface grinder machining program 2 4.3 CNC horizontal axis yen Taiwan surface grinder machining program 3 4.4 vertical rectangular table surface grinder CNC machining program 3 4.5 CNC vertical spindle and rotary table surface grinder machining program 4 4.6 CNC Gantry surface grinder due process procedures 4 5 requires the machining program 4 OK 46 machining program name OK 4 6.1 Main program name 6.2 determination subroutine name 4 Appendix A (normative) CNC surface grinder 5 sports legend (Informative) sample machining program name defined in Appendix B CNC surface grinder and a brief description 8

Foreword

This standard was drafted in accordance with GB/T 1.1-2009 given rules. The standard proposed by China Machinery Industry Federation. The standard mechanical and electrical systems by the National Standardization Technical Committee (SAC/TC231) centralized. Drafting of this standard. Hangzhou Machine Tool Group Co., Ltd., Guilin North Machine Co., Ltd, Guangzhou CNC Equipment Co. Division, Beijing KND CNC Technology Co., Ltd., Shanghai CTI products Detection Technology Limited. Drafters of this standard. Chen Jianming, Feng Dehua, Zhang Yujie, Yang Hongli, Chenai Hui, Bo. Machine electrical control system CNC surface grinder machining program requirements

1 Scope

This standard specifies the CNC surface grinding machine should have a basic machining program, also provides the machining program and the program name to determine requirements. This standard applies to including CNC horizontal axis moments Taiwan surface grinder, CNC horizontal axis yen Taiwan surface grinder, CNC vertical rectangular table surface grinder, NC Vertical shaft yen Taiwan surface grinder, CNC surface grinding machine gantry CNC surface grinder, including.

2 Normative references

The following documents for the application of this document is essential. For dated references, only the dated version suitable for use herein Member. For undated references, the latest edition (including any amendments) applies to this document. GB 5226.1-2008 Safety of machinery - Electrical machinery and electrical equipment - Part 1. General requirements (IEC 60204-1.2005, IDT) GB/T 8129-1997 Industrial automation systems - Numerical control of machines vocabulary (idt ISO 2806.1994) GB 15760-2004 Metal-cutting machine tool safety general technology condition GB/T 19660-2005 Industrial automation systems and integration - Numerical control of machines and motion coordinate system named (ISO 841. 2001, IDT)

3 Terms and Definitions

GB/T 8129-1997 and defined the following terms and definitions apply to this document. 3.1 Infeed transversefeed Machine tool relative to the workpiece as the Z-axis direction (horizontal shaft surface grinding machine) or Y-axis direction (vertical surface grinder) feed motion (see attached Record A), also known as out movement. 3.2 Vertical feed longitudinalfeed Machine tool relative to the workpiece along the X-axis direction (see Appendix A) of the feed movement, also known as the left and right movement. 3.3 Vertical feed verticalfeed Machine tool relative to the workpiece as the Y-axis direction (horizontal shaft surface grinding machine) or Z-axis direction (vertical surface grinder) feed motion, also known as the Under motion. 3.4 Way inlet one-wayfeed Machine of lateral direction of movement into and out of the sport for a period of grinding machine (spindle) for vertical motion into the workpiece to a Set feed. Similarly, the longitudinal direction of the machine for movement, left and right movement for a period of grinding machine (spindle) for vertical movement of the workpiece feed ......
