GB/T 19903.121-2008: Industrial automation systems and integration -- Physical device control -- Data model for computerized numerical controllers -- Part 121: Tools for turning machines
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 19903.121-2008	494	Add to Cart	4 days	Industrial automation systems and integration -- Physical device control -- Data model for computerized numerical controllers -- Part 121: Tools for turning machines	Valid

Similar standards

GB/T 39331 GB/T 16977 GB/T 36415 GB/T 19903.13 GB/T 19903.14 GB/T 19903.111

Basic data

Standard ID: GB/T 19903.121-2008 (GB/T19903.121-2008)
Description (Translated English): Industrial automation systems and integration -- Physical device control -- Data model for computerized numerical controllers -- Part 121: Tools for turning machines
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: J07
Classification of International Standard: 25.040.20
Word Count Estimation: 25,277
Date of Issue: 2008-10-07
Date of Implementation: 2009-04-01
Adopted Standard: ISO 14649-121-2005, IDT
Regulation (derived from): National Standard Approval Announcement 2008 No.17 (Total No.130)
Issuing agency(ies): General Administration of Quality Supervision, Inspection and Quarantine of the People's Republic of China, Standardization Administration of the People's Republic of China
Summary: This standard specifies the data elements described lathes and turning centers with the tool. This section often and GB/T 19903. 12 (lathes and turning centers with process data) together using. These data elements can be used to select a particular processing operation, but they do not have complete information about the description of a specific tool. Thus, leaving some properties to the controller to choose a greater degree of freedom to select the tool. Note 1: Assuming NC system can get a complete description of the specified tool from the database. Turing_machine_tool_schema defined in this section as a basic tool model, which includes CNC system to select the desired information from the tool turret lathe.

GB/T 19903.121-2008: Industrial automation systems and integration -- Physical device control -- Data model for computerized numerical controllers -- Part 121: Tools for turning machines

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Industrial automation systems and integration Physical device control Data model for computerized numerical controllers Part 121.. Tools for turning machines ICS 25.040.20 J07 National Standards of People's Republic of China GB/T 19903.121-2008/ISO 14649-121.2005 Industrial automation systems and integration - Physical device control Data model for computerized numerical controllers of Part 121. lathe tool (ISO 14649-121.2005, IDT) Posted 2008-10-07 2009-04-01 implementation Administration of Quality Supervision, Inspection and Quarantine of People's Republic of China Standardization Administration of China released

Introduction Ⅲ Introduction Ⅳ 1 Scope 1 2 Normative references 1 3 Terms and definitions 2 3.1 cutting reference point 2 3.2 Tool reference point 2 Location 3.2.1 diamond cutter elements 2 3.2.2 Location circular cutter element 2 4 Lathe Tool 3 4.1 Title and reference 3 4.2 lathe tool 3 4.2.1 cutting edge features 5 4.2.2 Tool lateral type 7 4.3 8 turning tool types 4.3.1 Common Tool 8 4.3.2 Threading tool 8 4.3.3 grooving 9 4.3.4 knurled knife 10 4.3.5 User-defined tools 11 Appendix A (normative appendix) EXPRESS Expansion Table 12 Appendix B (Informative Appendix) EXPRESS-G 16 English Vocabulary of 20 GB/T 19903.121-2008/ISO 14649-121.2005

Foreword

GB/T 19903 "Industrial automation systems and integration - Physical device control data model for computerized numerical controllers of" equivalent mining With ISO 14649. GB/T 19903 plans to develop the following sections. --- Part 1. Overview and basic principles (ISO 14649-1); --- Part 10. General process data (ISO 14649-10); --- Part 11. Process data for milling (ISO 14649-11); --- Part 12. Process data for turning (ISO 14649-12); --- Part 111. Milling Tool (ISO 14649-111); --- Part 121. lathe tool (ISO 14649-121). Further added enactment of Part gap between standard reserved. This section GB/T 19903 Part 121. This part identical with ISO 14649-121.2005 "Industrial automation systems and integration - Physical device control computer numerically controlled Used data model - Part 121. Lathe Tool "(in English). For ease of use, this section made the following editorial changes. --- Remove the ISO 14649-121.2005 Foreword and Introduction; --- Remove the ISO 14649-121.2005 Chapter 2 normative references in the guide language, with GB/T 1.1-2000 in 6.2.3 The introductory phrase in place; --- No part of ISO 14649 to number GB/T 19903; --- No part of ISO 10303 to number GB/T 16656; --- In order to facilitate the inspection, the original English Index to the English Vocabulary. In ISO 14649-121.2005 and other international standards cited for not tantamount to the adoption of our standards in this section are Directly referenced. As a graphical user interface. With the growing popularity of open architecture controllers, this approach will be more easily achieved. GB/T 19903 Excluding traditional programming statements. GB/T 19903.121-2008/ISO 14649-121.2005 Industrial automation systems and integration - Physical device control Data model for computerized numerical controllers of Part 121. lathe tool

1 Scope

This section provides a description of the data elements lathes and turning centers with the tool. This is often part and GB/T 19903.12 (lathes and vehicles Cut data center technology used) together use. These data elements can be used to select a particular machining operation, but they do not describe a For complete information specific tool. Thus, leaving some choice of properties to the controller for greater freedom of tool selection. Note 1. Assuming NC system can be specified to give a complete description of the tool from the database. turing_machine_tool_schema as defined in this section The basic tool mode, which includes CNC system Select the desired tool from the turret lathe. Note 2. In ISO 6983, the tool is defined by its identifier (eg T8), no more information about the tool types and geometric aspects. these messages It is part of the tool set table, provided by the NC program to the machine. The tool set table gives the tool orientation (such as an eighth slot magazine) And tool type (such as 4mm drill) relationship. This section includes information in the tool set table contains. --- Tool identifier; --- Tool type; --- Tool geometry; --- Status and application-related tool life expectancy. turing_machine_tool_schema tool does not include the database information. Tool database and machine and tool itself but related Independent of the NC program. The following tool data outside the scope of this section. --- Normative tool life; --- Positioning tool in the tool change institutions; --- Shank tool system and related projects; --- Other processes with tools, such as. milling, grinding, EDM tool. Note 3. It is important to inform all length measurement type is not a type of length measurement tolerances used in this section, as they are used to describe the machining of workpieces required To tool dimensions, while the actual size is not available on the machine tool. Actual tool tolerances must be adopted based on the actual tool dimensions and characteristics of the knife It has managed to choose. Note 4. This section should be used as a tool to describe the whole tool. It does not describe the individual components of the tool (cutter body, blades or clamping unit). Note 5. Other technology used in other parts of the tool will be described in GB/T 19903 in.
