GB/T 19882.33-2007	RFQ	ASK	11 days	Automatic meter reading system -- Part 3-3: Application layer data exchange protocols -- COSEM application layer	Obsolete

Similar standards

GB/T 15284   GB/T 17215.321   GB/T 34067.2   GB/T 19882.223   GB/T 19882.222   GB/T 19882.213

Basic data

Standard ID: GB/T 19882.33-2007 (GB/T19882.33-2007)
Description (Translated English): Automatic meter reading system -- Part 3-3: Application layer data exchange protocols -- COSEM application layer
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: N22
Classification of International Standard: 17.220.20
Word Count Estimation: 105,190
Date of Issue: 2007-10-11
Date of Implementation: 2007-12-01
Quoted Standard: GB/T 16263-1996; GB/T 19882.31-2007; GB/T 19882.32-2007; GB/T 19897.1-2005; GB/T 19897.3-2005; GB/T 19897.4-2005; DL/T 790.41-2002; IEC 60050.300-2001; ISO/IEC/TR2 8650-1-1996; ISO/IEC 8824-1990; ISO/IEC 13239-2000
Adopted Standard: IEC 62056-53-2002, IDT
Regulation (derived from): China Announcement of Newly Approved National Standards No. 11 of 2007 (total 111)
Issuing agency(ies): General Administration of Quality Supervision, Inspection and Quarantine of the People's Republic of China, Standardization Administration of the People's Republic of China
Summary: This standard specifies the use of COSEM interface object, through the logical name (LN) references and short name (SN) cited data communications services. This standard COSEM client and server COSEM application layer provides a structure and protocol aspects of service specifications. COSEM server in a given connection can either use the LN references, you can use SN Quote: This application requires the establishment of a connection negotiation. COSEM client typically use LN connection if the client and server communications using SN references, LN services to be mapped to SN services. Appendix C gives APDU coding examples, Appendix D explains the data model and the data exchange protocol in the instrument 's role.

GB/T 19882.33-2007: Automatic meter reading system -- Part 3-3: Application layer data exchange protocols -- COSEM application layer

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Automatic meter reading system Part 3-3. Application layer data exchange protocols COSEM application layer ICS 17.220.20 N22 National Standards of People's Republic of China GB/T 19882.33-2007/IEC 62056-53.2002 Automatic meter reading system Part 3-3. Application layer data exchange protocol COSEM application layer (IEC 62056-53.2002, Electricitymetering- Dataexchangeformeterreading, tariffandlaodcontrol- Part 53. COSEMapplicationlayer, IDT) Posted 2007-10-11 2007-12-01 implementation Administration of Quality Supervision, Inspection and Quarantine of People's Republic of China Standardization Administration of China released

Table of Contents

Introduction Ⅲ 1 Scope 1 2 Normative references 1 3 Terms, Definitions and Abbreviations 2 3.1 Terms and definitions 2 3.2 Abbreviations 2 3 4 COSEM communication structure 4.1 Client/Server type of operation, the communication before 3 Operation 4.2 Connection-oriented 4 5 Overview. COSEM application layer 5 5.1 Normative 5 5.2 Application Layer Structure 5 Service Specification 5.3 5 5.4 Layer 7 Management Services 5.5 protocol specification 7 6 COSEM application layer service specification 7 SUMMARY 7 6.1 Service 6.2 Application of the connection establishment and release 7 6.3 Special application connections 8 6.4 Data Transfer 9 6.5 client COSEM application layer services 9 COSEM server application layer services 6.6 24 7 COSEM Application layer protocol specification 37 7.1 client-side control status definition 37 7.2 server-side control of the state definition 38 7.3 Create/disconnect the connection protocol application 39 49 7.4 Data Communication Protocol 8 COSEM data type specification 63 8.1 COSEMAPDU 63 8.2 AARQ and AAREAPDU 64 Data types use 66 8.3 8.4 xDLMS-Initiate. request/response/ConfirmedServiceErrorPDUs 72 8.5 conformance block 73 8.6 define data communication APDU 74 Appendix A (normative) connection-oriented HDLC-based three-tier model 80 A. 1 Introduction 80 A. 2 HDLC data link layer --- Based Survey 80 GB/T 19882.33-2007/IEC 62056-53.2002 Appendix B (Normative Appendix) xDLMS application service component 83 B. 1 Introduction 83 B. 2 DLMS consistency 83 B. 3 COSEM Extended DLMS 83 Annex C (informative) Example AARQ and AARE coded 85 C. 1 xDLMS-Initiate. Example requestPDU coded 85 C. 2 AARQ coding example does not use security mechanisms when ACSE 86 C. When using the example of a lower authentication codes 3 AARQ 88 C. 4 Example AARQ encoded using advanced authentication 89 C. 5 AAREAPDU coding examples, succeeds 89 C. 6 xDLMS-Initiate. responsePDU coding examples 90 C. 7.00 does not use security measures or the use of low-level security measures AARE code 91 C. 8 Using advanced security measures AARE coded 93 C. One 9 AARE-pdu coding examples, failures 94 C. Example 10 AAREAPDU encoded failures bis 96 Annex D (informative) data models and protocols 99 References 100 GB/T 19882.33-2007/IEC 62056-53.2002

Foreword

"Automatic Meter Reading System application layer data exchange protocol" is divided into three parts. --- Part 3-1. Object identification system; (IEC 62056-61.2002, IDT) --- Part 3-2. interface class; (IEC 62056-62.2002, IDT) --- Part 3-3. COSEM application layer; (IEC 62056-53.2002, IDT) This section "Automatic Meter Reading System application layer data exchange protocol" in Part 3-3. This section is identical with IEC 62056-53.2002. "Automatic Meter Reading System application layer data exchange protocol" is an important part of the national standards system of "automatic meter reading system." under Listed below "Automatic meter reading system" and is expected to promulgate national standards with international standards and the corresponding structure. a) GB/T 19882.1-2005 "General automatic meter reading system." b) "automatic meter reading system meter reading system" --- Part 2-1. Low Voltage Power Line Carrier Record System --- Part 2-2. Wireless communication meter reading system --- Part 2-3. IP-based network meter reading system c) "automatic meter reading system application layer data exchange protocol." --- Part 3-1. Object identification system; (IEC 62056-61.2002, IDT) --- Part 3-2. interface class; (IEC 62056-62.2002, IDT) --- Part 3-3. COSEM application layer; (IEC 62056-53.2002, IDT) d) GB/T 19897-2005 "Automatic Meter Reading System Lower Layer Communication Protocol" --- Part 1. Direct local data exchange (IEC 62056-21.2002, IDT) --- Part 2. LAN-based carrier signal using twisted pair (IEC 62056-31.1999, IDT) --- Part 3. physical layer connection-oriented service processes asynchronous data exchange (IEC 62056-42.2002, IDT) --- Part 4. Based on the HDLC link layer protocol (IEC 62056-46.2002, IDT) This section Appendices A, B are normative appendix, Appendix C, Appendix D is an informative annex. This part is proposed by China Machinery Industry Federation. This part of the National Electrical Instrument Standardization Technical Committee. This part of the drafting unit. Harbin Electrical Instrument Research Institute, Northwest Electric Power Research Institute, Xi'an Huitong Control Technology Co., Canton State of South China Information Industry Group Co., Ltd., Beijing Watchdata Intelligent Technology Co., Ltd. Hangzhou Zhiyuan Electronics Co., Ltd., Beijing Power Supply Bureau, Holley Group Corporation, Zhejiang Chint Instrument Co., Ltd., Changsha Weisheng Instrument Co., Ltd., Shenzhen Science and Technology Co., Nanjing Auto Power Of the Institute. The main drafters of this standard. Yang West, Huangguo Bing, cold Ming-quan, Chen Hongjun, Zhang Xiaoping, FAN Guo-ping, left flat, Linbing Hai, Xu Renheng, Guan Wenju. GB/T 19882.33-2007/IEC 62056-53.2002 Automatic meter reading system Part 3-3. Application layer data exchange protocol COSEM application layer

1 Scope

This section COSEM client and server COSEM application layer specification defines the structure, services and other aspects of the agreement. This section provides the use of COSEM interface object, by logical name (LN) references and short name (SN) cited data communication services. COSEM server in a given connection may be used LN references, you can also use SN Quote. This application requires the establishment of connection OK consultations. COSEM client typically use LN connection, if the client and server use to communicate with the reference SN, LN service to Mapped to SN service. Appendix C gives an example APDU encoding Appendix D explains the role of data models and protocols in the meter data exchange.

2 Normative references

The following documents contain provisions which, through reference in this text, constitute provisions of this part. For dated references, subsequent Amendments (not including errata content) or revisions do not apply to this section, however, encourage the parties to this part of the research agreement Whether the latest versions of these documents. For undated reference documents, the latest versions apply to this section. GB/T 16263-1996 Information processing systems - Open Systems Interconnection - Abstract Syntax Notation --- (ASN.1) Basic Encoding Rules Specification (idt ISO /IEC 8825.1990) Part 3-1 GB/T 19882.31-2007 Automatic Meter Reading System. Application layer data exchange protocol object identification system (IEC 62056-61.2002, IDT) GB/T 19882.32-2007 automatic meter reading system - Part 3-2. Application layer data exchange protocol interface class (IEC 62056- 62.2002, IDT) GB/T 19897.1-2005 Automatic Meter Reading System Lower Layer Communication Protocol Part 1. Direct local data exchange (IEC 62056- 21.2002, IDT) GB/T 19897.3-2005 Automatic Meter Reading System Lower Layer Communication Protocol Part 3. Physical connection-oriented asynchronous data exchange Layer service process (IEC 62056-42.2002, IDT) GB/T 19897.4-2005 Automatic Meter Reading System Lower Layer Communication Protocol Part 4. Based on the HDLC protocol link layer (IEC 62056-46.2002, IDT) DL/T 790.41-2002 using distribution line carrier distribution automation - Part 4. Data communication protocols - Section 1. Communications Department System Reference Model (IEC 61334-4-41.1996, IDT) IEC 60050.300-2001 International Electrotechnical Vocabulary - Electrical and electronic measurements and measuring instruments The basic terms related to measurement. Part 311 Basic terms relating to electrical measurements. Part 312 Types of electrical measuring instruments. Section 313 Part 314. Specific terms according to the classification of the instrument IEC 61334-6.2000 using distribution line carrier distribution automation system - Part 6. A-XDR encoding rule IEC /T R262051.1999 Electrical Instrument Glossary ISO /IEC 8649.1996 Information technology - Open Systems Interconnection - Service definition connection control service components GB/T 19882.33-2007/IEC 62056-53.2002 ......
