GB/T 17213.15-2017: Industrial-process control valves -- Part 8-3: Noise considerations -- Control valve aerodynamic noise prediction method

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Industrial-process control valves - Part 8-3. Noise considerations - Control valve aerodynamic noise prediction method ICS 17.140.20; 23.060.40; 25.040.40 N16 National Standards of People's Republic of China Replacing GB/T 17213.15-2005 Industrial process control valve Part 8-3. Noise Considerations Aerodynamic Flow The noise prediction method that flows through the control valve Part 8-3.Noiseconsiderations- (IEC 60534-8-3.2010, IDT) 2017-12-29 published.2018-07-01 implementation General Administration of Quality Supervision, Inspection and Quarantine of People's Republic of China China National Standardization Administration released Directory Foreword Ⅲ 1 Scope 1 2 Normative references 1 3 Terms and definitions 2 4 symbol 2 5 Valve with standard trim 5 5.1 pressure and pressure ratio 5 5.2 Definition of each state 6 5.3 Preliminary Calculation 7 5.4 Internal Noise Calculation 8 5.5 Pipeline propagation loss calculation 11 5.6 Calculation of external sound pressure level 12 5.7 Calculation Process 13

6 Valve with specially designed trim

6.1 General 13 6.2 single-stage multi-flow valve trim 13 6.3 single-stage multi-stage pressure relief valve trim (2 or more throttling) 14 6.4 Multi-Flow Multi-Stage Trim (2 or more flow paths, 2 or more stages) 15 7 Outlet Mach 17 with higher valve 7.1 General 17 7.2 Calculation Procedure 17 8 experiment can determine the coefficient of sound valve 18 9 Noise Suppression When Installing Two or More Step-Down Pressure Vessels Downstream 18 Appendix A (informative) Calculation Example 19 References 47

Foreword

GB/T 17213 "industrial process control valve" is divided into the following sections. --- Part 1. Control valve terms and general principles (GB/T 17213.1); --- Part 2-1. Flow capacity Calculation formula for fluid flow rate under installation conditions (GB/T 17213.2); Part 2-3 - Test Procedures for Flow Capability (GB/T 17213.9); --- Part 2-4. Circulation capacity inherent flow characteristics and adjustable ratio (GB/T 17213.10); --- Part 2-5. Circulation capacity Fluid through the interstage recovery multi-stage control valve formula (GB/T 17213.17); --- Part 3-1. Dimensions Two-way ball-type through-flow control valve Flange end distance and two-way ball angle control valve Flange center to flange End surface spacing (GB/T 17213.3); --- Part 3-2. Dimensionally Stroke control valve (excluding butterfly valves) End face distance (GB/T 17213.11); --- Part 3-3. Dimension Butt welded two-way ball-type through control valve end (GB/T 17213.12); --- Part 4. Tests and routine tests (GB/T 17213.4); --- Part 5. Signs (GB/T 17213.5); --- Part 6-1. Installation details of the positioner and control valve actuator connections. Mounting of the positioner on the linear actuator (GB/T 17213.6); --- Part 6-2. Installation details of the positioner and control valve actuator connections. Mounting of the positioner on the angular travel actuator (GB/T 17213.13); --- Part 7. Control valve data sheets (GB/T 17213.7); --- Part 8-1. Noise considerations Noise generated by the flow of aerodynamic flow through control valves in the laboratory (GB/T 17213.8); --- Part 8-2. Noise considerations Measurement of the noise generated by the flow of hydraulic fluid through control valves in the laboratory (GB/T 17213.14); --- Part 8-3. Noise considerations Noise prediction methods for aerodynamic flow through control valves (GB/T 17213.15); --- Part 8-4. Noise Considerations Noise Prediction Method for Flow of Liquid Flow Through Control Valves (GB/T 17213.16); --- Part 9. Test procedures for step input response measurement (GB/T 17213.18). This section GB/T 17213 Part 8-3. This section drafted in accordance with GB/T 1.1-2009 given rules. This Part replaces GB/T 17213.15-2005 "Industrial Process Control Valves Part 8-3. Consideration of noise Aerodynamic flow through Control valve noise prediction method ", and GB/T 17213.15-2005 compared to the main technical changes are as follows. --- Updated some symbols and their definitions (see Chapter 4,.2005 edition Chapter 4); --- Increasing the pressure difference ratio formula [see formula (1)]; --- Modify the method of calculating the pressure under the contraction section instead of calculating the pressure difference [see (3),.2005 edition (2)]; --- Modify the reduced flow section critical pressure calculation method, instead of calculating the pressure ratio [see formula (4),.2005 layout (3)]; --- Modify the correction coefficient α expression, instead of using the pressure ratio to represent [see formula (5),.2005 layout (4)]; --- Modify the calculation method of the downstream pressure at the breakpoint instead of calculating the pressure difference ratio [see formula (6),.2005 format (5)]; --- Modify the calculation of the downstream pressure at the beginning of the Ⅴ state instead of calculating the pressure difference [see (7),.2005 edition (6)]; --- Modified to determine the criteria for each state, instead of judged by the pressure ratio (see 5.2,.2005 version 5.2); --- Increase the inlet fluid density ρ1 calculation (see 5.3.3); --- Remove the sound power ratio rw calculation (see.2005 version 5.3.3); --- Remove the sound power ratio rw (see.2005 version of Table 3); --- Remove the state Ⅰ to state Ⅴ calculation, it is integrated into Table 3 (see.2005 edition 5.4,5.5); --- Increased by the frequency of the internal sound pressure level calculation, and gives the frequency range (see 5.4.4); --- Modify the propagation loss through the pipe wall calculation formula [see 5.5, formula (20a),.2005 edition 5.6]; --- Modify the frequency coefficient Gx and Gy formula (see Table 6,.2005 edition of Table 4); --- Modify the formula of weighted A-weighted sound pressure level at 1m outside the pipe wall [see 5.6, formula (25),.2005 edition 5.6]; --- Modify the calculation process (see 5.7,.2005 version 5.7); --- Modify the multi-flow multi-stage valve Machining Jet Mach number formula [see 6.4, equation (32),.2005 edition 6.4]; --- Modify the multi-flow multi-stage valve trim under the conditions of peak frequency formula [see 6.4, equation (33),.2005 edition 6.4]; --- Removed the "valve not included in this section" clause (see 6.5 of.2005); --- Modify the 7.1 statement, made clear that the seventh chapter applies to the "expansion pipe mounted on the valve downstream of the transition point does not exceed the total angle of 30 °" Requirements (see 7.1,.2005 edition 7.1); --- Increasing the expansion tube after the conversion of the flow power calculation formula [see 7.2, equation (36)]; --- Modify the calculation formula of the peak frequency in the Chapter 7 case [see 7.2, equation (37),.2005 edition 7.2]; --- Modify the calculation formula of the sound effect coefficient in the seventh chapter [see 7.2, (38),.2005 edition 7.2]; --- Modify the calculation formula for the internal sound pressure level in chapter 7 (see 7.2, equation (41),.2005 edition 7.2]; --- Added the "experiment can determine the coefficient of sound valve" chapter (see Chapter 8); --- Added the "downstream installation of two or more fixed-area step-down parts of the noise generated when calculating" Chapter (see Chapter 9); --- Give a new calculation example (see Appendix A). This section uses the translation method is equivalent to using IEC 60534-8-3.2010 "industrial process control valves Part 8-3. Consideration of noise Aerodynamic flow through the control valve noise prediction method. " The documents of our country that are consistent with the corresponding international documents that are normative references in this section are as follows. --- GB/T 17213 (all parts) Industrial Process Control Valves [IEC 60534 (all parts)] --- GB/T 17213.1-2015 industrial process control valves - Part 1. Control valve terms and general principles (IEC 60534-1.2005, IDT) This part is proposed by China Machinery Industry Federation. This part of the National Industrial Process Measurement Control and Automation Standardization Technical Committee (SAC/TC124) centralized. This section is drafted unit. Shanghai Industrial Automation Instrumentation Research Institute, Zhejiang Insein Technology Co., Ltd., Hangzhou Liang Valve Co., Ltd. Division, Hangzhou Fuyang South Valve Co., Ltd., Shanghai Valve Valve Co., Ltd. special valve, Zhejiang Paowei Automation Instrumentation Co., Ltd., Wuxi Chi Control Engineering Co., Ltd. can be controlled, Chongqing Chuan-Yi Valve Co., Ltd., Zhejiang German-controlled Technology Co., Ltd., Shanghai Automation Instrument Table Co., Ltd. Automation Instrumentation Plant, Tianjin Proficient Control Instrumentation Technology Co., Ltd. Zhejiang Tripartite Control Valve Co., Ltd. Wu Zhongyi Table Co., Ltd., Chongqing Shunchong Instruments Co., Ltd., Emerson Process Management (Tianjin) Valve Co., Ltd. The main drafters of this section. Wang Jiong, Li Minghua, Wang Jianing, Shen Wei, Liao Jianmin, Shen Jianbiao, Zhang Shishu, Hao Jiao Shan, Zhang Dexian, Fan Ping, Cai Jiachao, Yang Jianwen, Song Wenjun, Lin Feng, Zuo Bing, Wang Hank, Li Zhanqi, Zhang Yongliang, Barry Ming, Chen A Yun, Jiang Tangjin, Su Fei, Zhang Jianwei. This part replaces the standards previously issued as. --- GB/T 17213.15-2005. Industrial process control valve Part 8-3. Noise Considerations Aerodynamic Flow The noise prediction method that flows through the control valve

1 Scope

GB/T 17213 provisions of this section provides a predictable flow of compressible fluid through the control valve and the expansion pipe is connected with the external Sound pressure level theory method. The gas considered in this method is a single phase dry gas or steam based on the ideal gas law. This section considers only the noise generated by the gas-powered flow through the control valve and associated piping. This section does not consider the outer surface and interior Reflection between pipe components, mechanical vibrations, unstable fluid conditions and other unforeseeable factors. This section assumes that at least 2m downstream of the noise measurement straight pipe. This method is only applicable to pipes made of steel or steel alloy [see 5.5 (21) and (23)]. This method is suitable for the following single-stage valve. Ball valve (through valve, angle valve), butterfly valve, plug valve (eccentric plug valve, spherical plug), the ball Valve, sleeve valve. But does not include full-bore ball valves that have a product of a specific FPC that exceeds 50% of the rated flow coefficient. This section also does not involve special low noise trim, see Chapter 8. When the standard trim valve exit Mach number exceeds 0.3 or low Noise Machining valve outlet valve Mach number exceeds 0.2, the need to use Chapter 7 of the calculation program. The Mach number in this section is limited as shown in the following table. Mach limit Mach number of the location Mach limit Chapter 5 Standard Trim Chapter 6 Noise Reduction Trim Chapter 7 High Mach Number Applications Free expansion jet Mj No restrictions No restrictions No restrictions Valve outlet Mo 0.3 0.2 1.0 Downstream reducer inlet Mr not applicable not applicable 1.0 Downstream pipe M2 0.3 0.2 0.8

2 Normative references

The following documents for the application of this document is essential. For dated references, only the dated version applies to this article Pieces. For undated references, the latest edition (including all amendments) applies to this document. IEC 60534 (all parts) Industrial Process Control Valves [Industrialprocesscontrolvalves (alparts)] IEC 60534-1 Industrial process control valves - Part 1. Control valve terms and general principles (Industrial-processcontrol valves-Part 1.Controlvalveterology and generalconsiderations) ......
