GB/T 15784-2009: Programming method for converted timber machine

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Programming method for converted timber machine ICS 65.060.80 B90 National Standards of People's Republic of China Replacing GB/T 15784-1995 Lumber machinery Model methodology Posted 2009-11-30 2010-01-01 implementation Administration of Quality Supervision, Inspection and Quarantine of People's Republic of China Standardization Administration of China released

Foreword

This standard replaces GB/T 15784-1995 "sawing machine model designation." The main difference compared with the standard GB/T 15784-1995 as follows. --- To increase conversion coefficient of the second main parameter; --- Increase group name mechanical system. This standard was proposed by the State Forestry Administration. This standard by the National Standardization Technical Committee panel machinery. This standard was drafted. Xinyang Woodworking Machinery Co., Ltd. The main drafters of this standard. Hu Dedi, Shen Wen, Li Xinmin, Wang Xihong, Han Hui. This standard replaces the standards previously issued as follows. --- GB/T 15784-1995. Lumber machinery Model methodology

1 Scope

This standard specifies the method for the preparation of lumber mechanical models. This standard applies to the preparation of various types of lumber saws, lumber cars, lumber auxiliary equipment, grinding equipment, lumber mechanical model in.

2 lumber machinery models

2.1 Model Representation Lumber mechanical models are structured as follows.  lumber machine code  classification code ()  general characteristics and structural characteristics of the code  group code  Department Code  main parameters (/ △)  second main argument (□)   significant improvements sequence number Note 1. "□" symbol, serving capital phonetic alphabet. Note 2. "△" symbol, serving Arabic numerals. Note 3. "()" symbol who, when no content is not expressed, if the content should not be bracketed. 2.2 sawing machinery classification code Lumber machinery is divided into four categories according to the functions, classification code Pinyin letters (see Table 1), located behind lumber machine code. Table 1 lumber machinery classification code Category lumber sawn timber car mechanism lumber auxiliary grinding equipment Code J C F M 2.3 lumber mechanical characteristics of the code 2.3.1 lumber mechanical properties of common code Lumber mechanical properties of common code Pinyin letters (see Table 2), located after the classification code. In the model represents only the most The main one common feature. Table 2 lumber mechanical properties of common code General features semi-automatic digital program-controlled universal Code Z B K W Structural characteristics 2.3.2 lumber machine code Mechanical properties of structural lumber code in the general characteristics of the code after, left the users "(Z)" represents the right to not express. ...
