GB/T 15092.102-2020 English PDFUS$359.00 · In stock
Delivery: <= 4 days. True-PDF full-copy in English will be manually translated and delivered via email. GB/T 15092.102-2020: Switches for appliances - Part 1-2: Requirements for electronic switches Status: Valid
Basic dataStandard ID: GB/T 15092.102-2020 (GB/T15092.102-2020)Description (Translated English): Switches for appliances - Part 1-2: Requirements for electronic switches Sector / Industry: National Standard (Recommended) Classification of Chinese Standard: K64 Classification of International Standard: 29.120.40 Word Count Estimation: 19,152 Date of Issue: 2020-12-14 Date of Implementation: 2021-07-01 Quoted Standard: GB/T 15092.1-2020 Adopted Standard: IEC 61058-1-2-2016, MOD Regulation (derived from): National Standard Announcement No. 28 of 2020 Issuing agency(ies): State Administration for Market Regulation, China National Standardization Administration Summary: This standard specifies the technical requirements for the classification, marking and documentation, protection against electric shock, structure, electrical performance, and mechanical performance of electronic switches in appliance switches. This standard applies to electronic switches (hereinafter referred to as switches) used to actuate or control household or similar electrical appliances and other equipment with a rated voltage of not more than 480V and a rated current of not more than 63A. This chapter of GB/T 15092.1-2020 is applicable. Add at the end of this chapter in GB/T 15092.1-2020: This standard of GB/T 15092 applies to electronic switching appliances and is used in conjunction with GB/T 15092.1-2020. GB/T 15092.102-2020: Switches for appliances - Part 1-2: Requirements for electronic switches---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.(Switches for appliances Part 1-2: Requirements for electronic switches) ICS 29:120:40 K64 National Standards of People's Republic of China Switches for appliances Part 1-2: Requirements for electronic switches (IEC 61058-1-2:2016, MOD) 2020-12-14 release 2021-07-01 implementation State Administration for Market Regulation Issued by the National Standardization Management Committee Table of contentsForeword Ⅰ 1 Scope 1 2 Normative references 1 3 Terms and definitions 1 4 General requirements 1 5 General precautions for the test 1 6 Rating 3 7 Category 3 8 Signs and documents 3 9 Protection against electric shock 3 10 Grounding device 4 11 Terminals and ends 4 12 Structure 4 13 Organization 4 14 Protection against solid foreign objects, water and moisture 4 15 Insulation resistance and dielectric strength 4 16 Fever 4 17 Durability 5 18 Mechanical strength 12 19 Screws, current-carrying parts and couplings 12 20 Electrical clearance, creepage distance, solid insulation and coating of hard printed circuit board components 12 21 Fire hazard 12 22 Rust prevention 12 23 Abnormal operation and fault conditions of the switch 12 24 Switching components 14 25 Electromagnetic compatibility (EMC) requirements 14 Reference 15 Table 101 Test sample 2 Table 102 Switch data and classification description 3 Table 103 Electrical durability test 6 of electronic switches Table 104 AC electrical durability test load 8 Table 105 DC electrical endurance test load 9 Table 106 Switch operating conditions 9ForewordGB/T 15092 "Appliance Switch" is divided into the following parts: ---Part 1: General requirements; ---Part 1-1: Mechanical switch requirements; ---Part 1-2: Requirements for electronic switches; ---Part 2: Special requirements; ● Special requirements for soft cord switches; ● Special requirements for conversion selector; ● Special requirements for independent installation switches; ● Special requirements for hand-held and portable power tools and garden machinery switches: This part is Part 1-2 of GB/T 15092: This section was drafted in accordance with the rules given in GB/T 1:1-2009: This part uses the redrafting law to amend and adopt IEC 61058-1-2:2016 ``Appliance Switch Part 1-2: Requirements for Electronic Switches'', and The technical differences of IEC 61058-1-2:2016 and their reasons are as follows: ---IEC 61058-1-2:2016 marked m in Table 101 stipulates: "This test is part of a sequence test, unless 5:1:2 Allowed, otherwise a new set of 3 samples shall not be used", and 5:1:2 is: "In all tests, measuring instruments or measuring devices It should not significantly affect the measured value", which is obviously wrong, so the mark m in Table 101 of this part stipulates: "This test is a sequence As part of the test, unless permitted by 5:1, a new set of 3 samples shall not be used:” This provision is also consistent with IEC 61058-1- 1:2016 The marked m in Table 101 is consistent: ---IEC 61058-1-2:2016's 14:3 stipulates: "The humidity treatment is carried out in a humid chamber, and the relative humidity of the air in the chamber is 91%~ Between 95%: In all places where the sample is placed, the air temperature is maintained at any suitable temperature (t) between 20°C and 30°C", Considering that some areas of our country have a humid tropical climate, and all electrical and electronic products in our country use (40±2)℃ for moisture-proof test, According to the provisions of this part in conjunction with GB/T 15092:1: "The humidity treatment is carried out in a humid chamber, and the relative humidity of the air in the chamber is Between 91% and 95%: Keep the air temperature at any suitable temperature between 30℃~40℃ in all places where the sample is placed Value (t)”, this provision is consistent with the severity level adopted by GB/T 2423:4, which is equivalent to IEC 60068-2-30: ---IEC 61058-1-2:2016 Chapter 16 stipulates: "GB/T 15092:1-2020 is applicable to this chapter", considering that the switch is in progress 16:4 During the heating test, the heating temperature when the switch contacts are closed is not necessarily the highest temperature of the switch, and the switch electronic components are ignored The heat is generated at the maximum operating point of the component, so this section adds supplementary test conditions for electronic switches and test voltage selection in 16:4: This chapter of GB/T 15092:1-2020 is only applicable after the application requirements, load conditions for heat test, and electronic switch setting points are specified: This section has made the following editorial changes: --- In Chapter 1 "Scope", "This part of GB/T 15092 specifies the classification, marking and Technical requirements for documents, protection against electric shock, structure, electrical performance, and mechanical performance: "" This section applies to actuation or control of household or The electronic switch (hereinafter referred to as the switch) in the appliance switch of similar electrical appliances and other equipment has a rated voltage not higher than 480V, rated current is not more than 63A": This part was proposed by China Electrical Equipment Industry Association: This part is under the jurisdiction of the National Electrical Accessories Standardization Technical Committee (SAC/TC67): Drafting organizations of this section: Shanghai Electric Tool Research Institute (Group) Co:, Ltd:, Zhongzheng Shangdong (Shanghai) Testing Technology Co:, Ltd:, Suzhou Huazhijie Telecommunications Co:, Ltd:, Zhejiang Jiaben Electronics Co:, Ltd:, Zhejiang Zhongxun Electronics Co:, Ltd:, Changzhou Yunjie Electric Co:, Ltd:, Le Qingshi Huiyang Electromechanical Co:, Ltd:, Zhejiang Guanbao Electronics Co:, Ltd:, Zhejiang Changlong Electric Co:, Ltd:, Fa-De Electric Co:, Ltd:, Suzhou Nuo Fu Electric Co:, Ltd:, Southeast Electronics Co:, Ltd:, Zhongshan Yonglian Electrical Products Co:, Ltd:, Weikai Testing Technology Co:, Ltd:, Zhejiang Heling Electric Co:, Ltd: The main drafters of this section: Zhang Weichang, Chen Ping, Wang Yi, Ni Shenglong, Zheng Jianzhong, Chu Yunyue, Wu Shiqing, Dai Taiguan, Xue Daode, Zhou Jinlong, Yang Xiaolong, Qiu Wenkui, Liang Songwen, Du Juan, Shen Dingli, Zhu Tongshuai, Qu Hailiang, Xu Yunan, Li Shangchun: Switches for appliances Part 1-2: Requirements for electronic switches1 ScopeThis part of GB/T 15092 specifies the classification, marking and documentation, protection against electric shock, structure, and electrical properties of electronic switches in appliance switches: Technical requirements such as energy and mechanical properties: This section applies to electronic switches in appliance switches that actuate or control household or similar electrical appliances and other equipment (hereinafter referred to as Switch), the rated voltage is not higher than 480V, and the rated current is not higher than 63A: This chapter of GB/T 15092:1-2020 is applicable: Add at the end of this chapter in GB/T 15092:1-2020: This part of GB/T 15092 applies to electronic switching appliances and is used in conjunction with GB/T 15092:1-2020: Note: Additional requirements for special switches can refer to GB/T 15092:2, GB/T 15092:3 and GB/T 15092:4:2 Normative referencesThe following documents are indispensable for the application of this document: For dated reference documents, only the dated version applies to this article Pieces: For undated references, the latest version (including all amendments) applies to this document: This chapter of GB/T 15092:1-2020 is applicable:3 Terms and definitionsThe terms and definitions defined in GB/T 15092:1-2020 apply to this document:4 General requirementsThis chapter of GB/T 15092:1-2020 is applicable:5 General considerations for the testAfter adding the following requirements, GB/T 15092:1-2020 this chapter applies: Added at the end of 5:4: Table 101 provides the following considerations: ---The minimum number of samples required for each test; --- When adding appropriate tests, the minimum number of total samples required for each evaluation; ---Additional samples required due to increased electrical ratings, specific structures, or damage or rupture during the test: ......Tips & Frequently Asked Questions:Question 1: How long will the true-PDF of GB/T 15092.102-2020_English be delivered?Answer: Upon your order, we will start to translate GB/T 15092.102-2020_English as soon as possible, and keep you informed of the progress. The lead time is typically 2 ~ 4 working days. The lengthier the document the longer the lead time.Question 2: Can I share the purchased PDF of GB/T 15092.102-2020_English with my colleagues?Answer: Yes. The purchased PDF of GB/T 15092.102-2020_English will be deemed to be sold to your employer/organization who actually pays for it, including your colleagues and your employer's intranet.Question 3: Does the price include tax/VAT?Answer: Yes. Our tax invoice, downloaded/delivered in 9 seconds, includes all tax/VAT and complies with 100+ countries' tax regulations (tax exempted in 100+ countries) -- See Avoidance of Double Taxation Agreements (DTAs): List of DTAs signed between Singapore and 100+ countriesQuestion 4: Do you accept my currency other than USD?Answer: Yes. If you need your currency to be printed on the invoice, please write an email to Sales@ChineseStandard.net. In 2 working-hours, we will create a special link for you to pay in any currencies. Otherwise, follow the normal steps: Add to Cart -- Checkout -- Select your currency to pay. |
