GB/T 12668.8-2017 English PDF

Q: How long will the true-PDF of English version of GB/T 12668.8-2017 be delivered?

Upon your order, we will start to translate GB/T 12668.8-2017_English as soon as possible, and keep you informed of the progress. The lead time is typically 2 ~ 4 working days. The lengthier the document the longer the lead time.

Q: Can I share the purchased PDF of GB/T 12668.8-2017_English with my colleagues?

Yes. The purchased PDF of GB/T 12668.8-2017_English will be deemed to be sold to your employer/organization who actually pays for it, including your colleagues and your employer's intranet.

Q: Does the price include tax/VAT?

Yes. Our tax invoice, downloaded/delivered in 9 seconds, includes all tax/VAT and complies with 100+ countries' tax regulations (tax exempted in 100+ countries). Avoidance of Double Taxation Agreements (DTAs) between Singapore and 100+ Countries: https://www.iras.gov.sg/taxes/international-tax

Q: Do you accept my currency other than USD?

Yes. If you need your currency to be printed on the invoice, please write an email to Sales@ChineseStandard.net. In 2 working-hours, we will create a special link for you to pay in any currencies. Otherwise, follow the normal steps: Add to Cart -- Checkout -- Select your currency to pay.

US$944.00 · In stock
Delivery: <= 4 days. True-PDF full-copy in English will be manually translated and delivered via email.
GB/T 12668.8-2017: Adjustable speed electrical power drive systems -- Part 8: Specification of voltage on the power interface
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 12668.8-2017	944	Add to Cart	4 days	Adjustable speed electrical power drive systems -- Part 8: Specification of voltage on the power interface	Valid

Similar standards

GB/T 5959.41 GB/T 37752.1 GB/T 3797 GB/T 12668.7202 GB/T 12668.7302 GB 12668.3

Basic data

Standard ID: GB/T 12668.8-2017 (GB/T12668.8-2017)
Description (Translated English): Adjustable speed electrical power drive systems -- Part 8: Specification of voltage on the power interface
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: K62
Classification of International Standard: 29.160.30; 29.200
Word Count Estimation: 50,558
Date of Issue: 2017-12-29
Date of Implementation: 2018-07-01
Regulation (derived from): National Standards Bulletin 2017 No. 32
Issuing agency(ies): General Administration of Quality Supervision, Inspection and Quarantine of the People's Republic of China, Standardization Administration of the People's Republic of China

GB/T 12668.8-2017: Adjustable speed electrical power drive systems -- Part 8: Specification of voltage on the power interface

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Adjustable speed electrical power drive systems--Part 8. Specification of voltage on the power interface ICS 29.160.30; 29.200 K62 National Standards of People's Republic of China Speed control electric drive system Part 8. Voltage specifications for power interfaces (IEC /T S61800-8.2010, IDT) Released on.2017-12-29 2018-07-01 implementation General Administration of Quality Supervision, Inspection and Quarantine of the People's Republic of China China National Standardization Administration issued

Content

Foreword III 1 Scope 1 2 Normative references 1 3 Overview, terminology and definitions 1 3.1 System Overview 1 3.2 Terms and Definitions 2 4 System Method 6 4.1 Overview 6 4.2 High Frequency Grounding Performance and Topology 6 4.3 Dual Port Method 7 4.4 Differential Mode and Common Mode System 7 5 grid part 10 5.1 Overview 10 5.2 TN power supply system 10 5.3 IT power supply system 11 5.4 Magnification of the differential mode model of the grid section 11 5.5 Relevant conclusions of the common mode model of the grid part 11 6 input converter part 11 6.1 Voltage Analysis 11 6.2 Single-Phase Diode Rectifier as a Voltage Source Indirect Converter for Grid-Side Converters 12 6.3 Three-phase diode rectifier as a voltage source type indirect converter for the grid-side converter 14 6.4 Voltage source type indirect converter with three-phase active grid-side converter 16 6.5 Input voltage reference potential of the converter section 18 6.6 Grounding 18 6.7 Multi-pulse application 18 6.8 Magnification factor of the differential mode model of the rectifier section 18 6.9 Magnification factor of the common mode model of the rectifier section 19 7 Output converter section (inverter section) 19 7.1 Overview 19 7.2 Input value of the inverter part 19 7.3 Introduction to different inverter topologies 19 7.4 Output Voltage Waveforms of Different Topologies 23 7.5 Output voltage rise time 23 7.6 du/dt compatible value 24 7.7 repetition rate 26 7.8 Grounding 26 7.9 Amplification effect in the differential mode model of the inverter section 26 7.10 Adding effects in the common mode model of the inverter section 26 7.11 Related dynamic parameters of pulse common mode model and differential mode model 27 8 filter section 27 8.1 General purpose of the filter 27 8.2 Differential Mode and Common Mode Voltage System 27 8.3 Filter Topology 28 8.4 Amplification effect in the differential mode model of the filter 30 8.5 Adding effects in the common mode model of the filter 30 9 Cable portion 31 between the converter output terminal and the motor terminal 9.1 Overview 31 9.2 Cable 31 9.3 Cable section parameters 32 10 Guidelines for calculating the power interface voltage according to each part of the model 32 11 Equipment and Examples 34 11.1 Overview 34 11.2 Example 34 Appendix A (informative) Different types of power supply systems 37 Appendix B (informative) Inverter voltage 41 Appendix C (informative) Output filter performance 42 Reference 43

Foreword

GB/T 12668 "Speed Control Electric Drive System" is divided into the following parts. ---Part 1. General requirements for the rated value of the low-voltage DC-regulated electric drive system; ---Part 2. General requirements for the rated value of low-voltage AC variable frequency electric drive system; --- Part 3. Electromagnetic compatibility requirements and their specific test methods; ---Part 4. General requirements for AC speed control electric drive systems with AC voltages above 1000V but not exceeding 35kV Provision of value; --- Part 5. Safety requirements; --- Part 6. Guidelines for determining the type of load duty and the corresponding current rating; --- Part 7. General interface and specification for electric drive systems; --- Part 8. Voltage specifications for power interfaces; --- Part 9. Energy efficiency of electric drive systems, motor starters, power electronics and their drives. This part is the eighth part of GB/T 12668. This part is drafted in accordance with the rules given in GB/T 1.1-2009. This part uses the translation method equivalent to IEC /T S61800-8.2010 "Speed Control Electric Drive System Part 8. Power Interface Power Pressure specification. The documents of our country that have a consistent correspondence with the international documents referenced in this part are as follows. ---GB/T 18039.4-2003 Compatibility level of low frequency conducted disturbance in electromagnetic compatibility environment factory (IEC 61000-2-4. 1994, IDT) This section has made the following editorial changes. --- Considering the consistency with the various parts of GB/T 12668, the word "U" is used to indicate the voltage, and the text symbol "V" is used. Potential. This part was proposed by China Electrical Equipment Industry Association. This part is under the jurisdiction of the National Power Electronics System and Equipment Standardization Technical Committee (SAC/TC60). This section drafted by. Tianjin Electric Science Research Institute Co., Ltd., Shenzhen Baoan Renda Electric Industrial Co., Ltd., Zhoushan City quality Technical Supervision and Testing Institute, State Grid Electric Power Research Institute Wuhan Nanrui Co., Ltd., Shanghai Sigriner New Time Motor Co., Ltd. Division, Tianshui Electric Transmission Research Institute Co., Ltd., Beijing ABB Electric Transmission System Co., Ltd., Hope Senlan Technology Co., Ltd. Division, State Grid Fujian Electric Power Co., Ltd. Electric Power Research Institute, Xi'an Power Electronics Technology Research Institute, China Metallurgical South (Wuhan) Automation Co., Ltd. Company, Tianjin Tianchuan Electronic Control Power Distribution Co., Ltd., China Electrotechnical Society Electronic Control System and Equipment Committee, Shandong University. The main drafters of this section. Chai Qing, Yan Shiqing, Li Cunjun, Wang Jianfeng, Mo Qing, Jin Xinhai, Wang Youyun, Wen Xiangning, Du Junming, Li Chuandong, Wei Hongqi, Zhang Wei, Chu Zilin, Han Dongming, Luo Julong, Zhang Chenghui. Speed control electric drive system Part 8. Voltage specifications for power interfaces

1 Scope

This part of GB/T 12668 gives a method for determining the voltage of the electrical drive system (PDS) power interface. Note. In the GB/T 12668 series of standards, the power interface is defined as a power connection for transmitting electrical power between the converter and the motor of the PDS. This section applies to determining the relative phase voltage (line voltage) and relative ground voltage (phase voltage) of the converter and the motor terminals. In the first edition of this section, these guidelines are limited to the following topologies for three-phase outputs. --- Voltage source type indirect converter, the grid side converter is a single phase diode rectifier; --- Voltage source type indirect converter, the grid side converter is a three-phase diode rectifier; --- Voltage source type indirect converter, the grid side converter is a three-phase active rectifier. The inverters referred to in this section are pulse width modulation type, and the width of each output voltage pulse is voltage change according to actual demand. Chemical. This section does not include voltage specifications for other topologies. The safety requirements are given in Section 5 of GB/T 12668 and are not included in this section. Electromagnetic compatibility requirements are It is given in Part 3 of GB/T 12668 and is not included in this section.

2 Normative references

The following documents are indispensable for the application of this document. For dated references, only dated versions apply to this article. Pieces. For undated references, the latest edition (including all amendments) applies to this document. IEC 61000-2-4 Electromagnetic compatibility - Part 2-4. Compatible levels of low-frequency conducted disturbances in environmental plants [Electromagnetic Compatibility(EMC)-Part 2-4.Environment-Compatibilitylevelsinindustrialplantsforlow-fre- Quencyconducteddisturbances] 3 Overview, terminology and definitions 3.1 System Overview The electric drive system (PDS) consists of an electric motor and a complete set of drive modules (CDM), excluding equipment driven by electric motors. The CDM includes a Basic Drive Module (BDM) and its periphery, such as an input section or some auxiliary equipment (such as a ventilator). BDM includes Power converter with control and self-protection. The boundaries between the PDS and other parts of the equipment and/or production process are shown in Figure 1. Such as The PDS uses a dedicated transformer that is included in the CDM. In this section, the following conventions are used for all symbols. --- Use the "^" symbol to indicate the peak value; --- Use the "*" symbol to indicate the amount of bipolarity. For a defined driver topology, the pattern of voltage waveforms between the various parts defined later is substantially identical in shape (including peaks) Values), and their magnitude depends on the appropriate operating voltage, which is the reference value in each section. Whether the reference voltage between the parts uses the DC average or the AC fundamental RMS, depending on the interface and the detection voltage of the considered part The actual situation (differential mode or common mode). In the differential mode and the common mode model, the actual voltage value between the various parts is considered as the peak value. the relevant given value can be multiplied by some The appropriate coefficient is obtained, and the coefficient includes the influence of the overvoltage phenomenon. Figure 1 Definition of equipment and some equipment 3.2 Terms and definitions The following terms and definitions apply to this document. 3.2.1 Power interface powerinterface The connections required for PDS internal power distribution. [GB/T 12668.3-2012, definition 3.3.11] 3.2.2 Dual port network two-portnetwork A two-port network (or four-terminal network, or quadrupole network) is a circuit or device with two pairs of terminals. 3.2.3 Converter reference point converterreferencepoint; NP The point in the converter where the potential is equal to (Vd Vd-)/2. The converter reference point can be used in different topologies. Electricity from NP to ground The voltage is usually the common mode voltage. 3.2.4 DC link DClink A DC power circuit connecting an input converter and an output converter in an indirect converter, including a capacitor and/or a reactor to reduce DC Voltage and/or DC current ripple. 3.2.5 DC link voltage DClinkvoltage Ud;Vd ;Vd- DC link voltage of the converter section. Vd refers to a positive potential and Vd- refers to a negative potential. 3.2.6 F0 Filter resonance frequency. 3.2.7 F1 The fundamental frequency of the inverter output voltage. 3.2.8 Fp Phase pulse frequency. 3.2.9 fS The fundamental frequency of the power supply voltage system. 3.2.10 Fsw The switching frequency of each semiconductor active device. 3.2.11 Ideally idealground The reference ground point of the equipment. 3.2.12 kCμ Magnification (peak) of the relevant part of the common mode model. 3.2.13 kDv Magnification (peak) of the relevant part of the differential model. 3.2.14 Number numberoflevels The number of levels N is equal to the number of possible voltage steps between the output phase and the NP point. 3.2.15 Ndcmult The number of DC links per phase in a multi-DC link inverter topology. 3.2.16 System star point systemstarpoint; SP The reference point for the inverter output. Different points in the system can be used as system star points. Used to define the total between the three-phase system and the ideal ground Mode voltage. 3.2.17 Rise time risetime Tr The time between 10% and 90% of the instantaneous peak voltage is equivalent to t90-t10 (see Figure 2). Figure 2 Two-level inverter voltage pulse waveform parameters. Among them, the rise time tr=t90-t10 3.2.18 Transient overvoltage UB The voltage value exceeding the steady state value of the step voltage "Ustep" (see Figure 2). 3.2.19 Ground potential potential VGi The reference potential of the i-th part to ground. Sometimes use "ground potential" or "ground". 3.2.20 UPP The voltage between the phase and the phase (line voltage). 3.2.21 UPNP The voltage between the output phase of the inverter and the NP. 3.2.22 UPSP The voltage between the inverter output phase and the star point. 3.2.23 UPG, motor The voltage between phase and ground at the motor terminals. 3.2.24 UPP, motor The voltage between the phase and phase at the motor terminals. 3.2.25 U^PP The peak value of the voltage (line voltage) between the phase and phase. For the two-level case, there is U^PP=Ustep UB. 3.2.26 U^PP* The peak value of the voltage between the two bipolar voltage peaks. Figure 3 Typical voltage curve at the motor terminals and the relationship between parameters and time (line voltage) when the two-level inverter is powered 3.2.27 U^PP_fp* The peak of the voltage between the phase and phase containing twice the overvoltage spike. 3.2.28 US The voltage between the phase and phase of the converter power supply (feeder). In this section, this voltage is used to peak voltage and DC link The voltage is normalized to the standard value and contains all tolerances according to IEC 61000-2-4. 3.2.29 USN The nominal voltage between the phase and phase of the converter power supply (feeder supply), ie the secondary voltage of the input transformer when the tolerance is not taken into account. 3.2.30 Ustep The difference between the steady-state voltage values before and after switching (see Figure 2). Figure 4 Typical voltage curve at the motor terminals and the relationship between time and time (line voltage) when the three-level inverter is powered 3.2.31 Ustep_PP Voltage step between phase and phase voltage (line voltage) UPP. 3.2.32 Ustep_PNP The voltage step of the voltage UPNP between phase and NP. 3.2.33 Ustep_PSP The voltage step of the voltage UPSP between the phase and the star point. 3.2.34 Ustep_Gi The voltage step of the common mode voltage UGi.

4 system approach

4.1 Overview The voltage source drive system (see Figure 5) consists of the following sections. grid section, grid side filter (if required), grid side rectifier, DC reactance (if required), DC capacitor bank in DC link, self-commutated motor-side converter output filter (if required), converter and power The cable system between the motives and the motor. Figure 5 Transmission system consisting of a voltage source inverter (VSI) and an electric motor 4.2 High frequency grounding performance and topology Connecting a PE using a cable is a so-called low frequency grounding. In order to describe the dynamic voltage characteristics using the system method, we are more concerned about high Frequency grounding performance and topology. In the actual equipment, the ground potentials VG0~VG4 of different parts are shown in Fig. 5. As long as the grounding impedance is different, the ground potential is different, and The ground potential should be based on high frequency (if the ground line performance is not good), although the ground potential based on low frequency may have the same value. --- The high-frequency grounding performance of the single-point grounding topology is not good. High frequency based ground potentials VG0~VG4 may contain additional parasitics Voltage component. --- High-frequency grounding performance of multi-point or mesh grounding topology is very good. The high frequency based ground potential VG0~VG4 does not contain additional Parasitic voltage component. 4.3 Dual Port Method The two-port method is suitable for describing the voltage waveform between the motor terminals. There are two main types of dual port components, which divide the system into two overlapping parts. --- Amplifying components in the differential mode; --- Additive components in the common mode model. 4.3.1 Amplifying components The amplifying elements are shown in Figure 6. In this case, the output voltage of the dual port component is calculated as follows. Uout=k×Uin (1) Figure 6 Dual port amplification component 4.3.2 Adding components The case of the two-port adder is shown in Figure 7. The output voltage is calculated as follows. Uout=Uadd Uin (2) Figure 7 Dual port adder Consider the relationship between the output voltage Uout of the dual-port component and the input voltage Uin, taking into account the main parameters (such as peaks) in Chapter 4. Voltage, rise time), will be the characteristics of the entire power supply network, converter input, converter output, output filter, cable and motor input Research provides a method. Grounding conditions can affect or change the voltage relationship, and these effects will be discussed in conjunction with different ground potential conditions. 4.4 Differential mode and common mode system 4.4.1 Overview In signal theory, it is a common method to divide a known system into a common mode and a differential mode system. In the differential mode system, including the conductor All signals appearing between. The common mode system includes all signals present in all conductors and all signals to ground. In the PDS, an example in which the inverter output portion is divided by this method is shown in FIG. The output voltage of the inverter (UU, UV, UW) can be divided into differential mode (also known as symmetrical) voltage system (UUD, UVD, UWD) and common mode (also Called the asymmetric voltage system (UG2). The differential mode voltage represents the voltage between the three output phases. For each phase, the difference between the inverter output voltage and the common mode voltage can be calculated. Come. For example U phase. UUD=UU-VG2 (3) PDS is usually a symmetrical system, that is to say the amplitude of all AC differential mode voltages in all phases (eg supply voltage, inverter) The output voltages are the same and the voltage vectors have a phase shift of 120° from each other (see Figure 9). Figure 8 Differential mode and common mode voltage system a) DC link voltage b) Rotary inverter output voltage Figure 9 Voltage in a differential mode system The reference point of the DC differential mode voltage is the neutral point of the DC link, and the voltage (Udc D, Udc-D) appears as an angle of 180°. therefore, The magnitude of the DC differential mode voltage is always 50% of the total voltage of the DC link from the positive supply terminal to the negative supply terminal. The common mode voltage represents the voltage from the ideal star point of the three output phases to the ideal ground potential. Calculated as follows. UG2=(UU UV UW)/3 (4) For differential mode and common mode systems, an equivalent circuit diagram can be drawn using the dual port components described above. 4.4.2 Differential mode system The differential mode block diagram is shown in Figure 10. Figure 10 Block diagram depicting the motor terminal voltage using a differential mode model consisting of two-port components The highest line voltage at the motor input is calculated as follows. U^PP, motor=US×∏ i=1 kDi (5) Figure 11 shows an example of actual equipment. Figure 11 is an equivalent circuit block diagram for......
