US$589.00 · In stock
Delivery: <= 5 days. True-PDF full-copy in English will be manually translated and delivered via email.
GB/T 11313.16-2015: Radio-frequency connectors -- Part 16: Sectional specification for RF coaxial connectors with inner diameter of outer conductor 7 mm (0.276 in) with screw coupling -- Characteristics impedance 50Ω (75 Ω) (type N)
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 11313.16-2015	589	Add to Cart	5 days	Radio-frequency connectors -- Part 16: Sectional specification for RF coaxial connectors with inner diameter of outer conductor 7 mm (0.276 in) with screw coupling -- Characteristics impedance 50Ω (75 Ω) (type N)	Valid

Similar standards

GB/T 17737.100 GB/T 21711.1 GB/T 11313.13 GB/T 11313.15 GB/T 11313.11

Basic data

Standard ID: GB/T 11313.16-2015 (GB/T11313.16-2015)
Description (Translated English): Radio-frequency connectors -- Part 16: Sectional specification for RF coaxial connectors with inner diameter of outer conductor 7 mm (0.276 in) with screw coupling -- Characteristics impedance 50�� (75 ��) (type N)
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: L23
Classification of International Standard: 33.120.30
Word Count Estimation: 28,241
Date of Issue: 2015-06-02
Date of Implementation: 2016-02-01
Quoted Standard: GB/T 11313.1-2013
Adopted Standard: IEC 61169-16-2006, NEQ
Regulation (derived from): National Standard Announcement 2015 No.19
Issuing agency(ies): General Administration of Quality Supervision, Inspection and Quarantine of the People's Republic of China, Standardization Administration of the People's Republic of China
Summary: This Standard specifies the characteristic impedance of the N-type RF coaxial connectors 50�� size of the mating interface, standard gauge testing requirements, product ratings and characteristics, as well as the N-type connector from GB /T 11313.1-2013 selected application the list of all the detailed specification of test and inspection requirements. Characteristic impedance of 50�� N-type connector has three levels of products between each level products to each other mating. Universal RF connector (2) preferentially SYV-50-7 and other radio frequency cable connection frequencies up to 11GHz. High Performance RF connector (1) is particularly suitable when the demand is lower than the reflection coefficient of the reflection coefficient universal connector microwave applications, it can also be used for microwave components. Its interface dimensional tolerances between 0 and 2, can be obtained by selecting the performance requirements. Some conforming to this standard a connector highest frequency up to 18GHz. Standard Test Connectors (0) with precision control interface for measurement with the above two kinds of interface connectors, cable assemblies, components, and equipment to provide a reference. When asked highest frequency of 18GHz most sophisticated interface, it can also be used as a microwave connectors use. This Standard also specifies the characteristic impedance of 75�� N type RF coaxial connector interface (see Appendix A), but because of the accident will 75�� and 50�� connector cross connection may damage the connector 75��, therefore, does not recommend the use of characteristic impedance of the type N connector 75��. This Standard applies to the N-type RF coaxial connectors. N-type RF coaxial connectors with threaded coupling mechanism, in low-power applications in use.

GB/T 11313.16-2015: Radio-frequency connectors -- Part 16: Sectional specification for RF coaxial connectors with inner diameter of outer conductor 7 mm (0.276 in) with screw coupling -- Characteristics impedance 50Ω (75 Ω) (type N)

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Radio-frequency connectors Part 16. Sectional specification for RF coaxial connectors with inner diameter of outer conductor 7 mm (0.276 in) with screw coupling Characteristics impedance 50Ω (75 Ω) (type N). ICS 33.120.30 L23 National Standards of People's Republic of China RF connectors - Part 16. inner diameter of the outer conductor 7mm (0.276in), characteristic impedance is 50Ω (75Ω), Threaded RF coaxial connectors (N-type) specification Radio-frequencyconnectors-Part 16. SectionalspecificationforRF coaxialconnectorswithinnerdiameterofouterconductor7mm (0.276in) withscrewcoupling-Characteristicsimpedance50Ω (75Ω) (typeN) (IEC 61169-16.2006, Radio-frequencyconnectors- Part 16. Sectionalspecification-RFcoaxialconnectorswith innerdiameterofouterconductor7mm (0.276in) withscrewcoupling- Characteristicsimpedance50Ω (75Ω) (typeN), NEQ) Issued on. 2016-02-01 2015-06-02 implementation Administration of Quality Supervision, Inspection and Quarantine of People's Republic of China Standardization Administration of China released

Introduction Ⅲ 1 Scope 1 2 Normative references 1 3 mating interface and standard gauge 1 Universal Connector size 3.1 - Level 1 3.1.1 Pin Connector 1 3.1.2 jack connector 3 3.2 standard gauge 5 3.2.1 external contacts pin connector with standard gauge 5 3.2.2 jack connector center contact using a standard gauge 6 3.3 standard test interface connector size -0 stage 7 3.3.1 Standard Test connector pins 7 3.3.2 Standard Test jack connector 9 4 Quality assessment procedures 10 4.1 General 10 4.2 ratings and characteristics (see GB/T 11313.1-2013 Chapter 6) 10 4.3 List of test and inspection requirements 13 4.3.1 Settlement Test 13 4.3.2 Test cycle 13 4.3.3 Program 14 5 to develop a detailed specification of the guide 15 5.1 Overview 15 5.2 Detailed specification of identification 15 5.3 Identification of components 15 5.4 Performance 15 5.5 logo, ordering information and related matters 15 5.6 test, the test conditions and the severity of the select 16 N-type connectors 5.7 Blank detail specification format 16 Appendix A (normative) characteristic impedance of 75Ω universal connector interface class size 20 Appendix B (Informative Appendix) IEC type designation 22

Foreword

In GB/T 11313 "RF Connectors" have or plan to release the following sections. --- Part 1. Generic specification - General requirements and test methods (GB/T 11313.1-2013); --- Part 2. RF coaxial connectors 9.52 specification (GB/T 11313.2-2007); --- Part 3. balanced antenna feeder with two-pin connector; --- Part 4. inner diameter of outer conductor 16mm (0.63in), a characteristic impedance of 50Ω, threaded RF coaxial connectors (7-16 Type) (GB/T 11313.4-2007); Part --- Article 5. 96IEC 50-17 and larger cable specification for radio frequency coaxial connector; --- Part 6. 96IEC 75-17 and greater RF coaxial cable connector specification; Part --- Article 7. C Series RF coaxial connector specification; --- Part 8. inner diameter of the outer conductor 6.5mm (0.256in), a characteristic impedance of 50Ω (75Ω), RF coaxial connector bayonet connection Connector (BNC type) specification (GB/T 11313.8-2015); --- Part 9. SMC Series RF coaxial connector specification (GB/T 11313.9-2013); Part --- Article 10. SMB series RF coaxial connector specification (GB/T 11313.10-2012); --- Part 11. 4.1/9.5 series RF coaxial connector specification; Part --- Article 12. UHF series RF coaxial connectors specification; --- Part 13. inner diameter of the outer conductor 5.6mm (0.22in), mating with the same size of a characteristic impedance of 75Ω (1.6/5.6 Type) and a characteristic impedance of 50Ω (1.8/5.6 type) RF coaxial connector specification; --- Part 14. inner diameter of outer conductor 12mm (0.472in), a characteristic impedance of 75Ω, RF coaxial connectors with screw connection (3.5/12 type) specification; Part --- Article 15. SMA Series RF coaxial connector specification; --- Part 16. inner diameter of the outer conductor 7mm (0.276in), a characteristic impedance of 50Ω (75Ω), RF coaxial threaded connection --- Part 17. inner diameter of the outer conductor 6.5mm (0.256in), a characteristic impedance of 50Ω, RF coaxial connectors with screw connection (TNC type) specification; Part --- Article 18. SSMA series RF coaxial connector specification (GB/T 11313.18-2013); Part --- Article 19. SSMB series RF coaxial connector specification (GB/T 11313.19-2013); --- Part 20. SSMC series RF coaxial connectors specification; Part --- Article 21. SC-A and SC-B Series Series RF coaxial connector specification; --- Part 22. BNO Series RF coaxial connector specification; --- Part 23. 3.5mm with rigid precision coaxial lines with the outer conductor inner diameter of 3.5mm (0.1378in) RF coaxial Connector specification; --- Part 24. 75Ω cable distribution systems connected by a threaded RF coaxial connector (F-type) (GB/T 11313.24-2013); --- Part 25. Connect the inner conductor double shielded symmetrical cable outer conductor inner diameter of 13.56mm (0.534in) of holes threaded connection Sectional specification; --- Part 26. TNCA series RF coaxial connectors specification; --- Part 27. 75Ω cable distribution systems with a threaded connection RF coaxial connectors (E-type) specification; --- Part 28. characteristic impedance of 75Ω, card lock connection, the outer conductor inner diameter of 5.60mm (0.220in) RF coaxial connector Specification; --- Part 29. characteristic impedance of 50Ω, a threaded, push-pull, quick lock or slide rack or panel connected RF Coaxial Device (1.0/2.3 type) specification; --- Part 31. inner diameter of the outer conductor 1.0mm (0.039in), the characteristic impedance of 50Ω, RF coaxial connector threaded connection (1.0 type) specification; --- Part 32. inner diameter of the outer conductor is 1.85mm (0.072in), the characteristic impedance of 50Ω, RF coaxial connector threaded connection (1.85 type) specification; Part --- Article 33. BMA RF coaxial connector specification (GB/T 11313.33-2001); --- Part 35. 2.92 Series RF coaxial connector specification; --- Part 36. characteristic impedance of 50Ω of the snap connection miniature RF coaxial connectors (MCX type) (GB/T 11313.36- 2006); Part --- Article 37. STWX8 Series RF coaxial connector specification (GB/T 11313.37-2015); --- Part 38. 50Ω back and slide-in module panel RF coaxial connector (TMA type) specification; --- Part 39. CQM series quick lock RF coaxial connectors specification; --- Part 40. RF coaxial connectors series 2.4 specification; --- Part 41. CQA series quick lock RF coaxial connectors specification; --- Part 42. CQN series quick lock RF coaxial connectors specification; Part --- Article 43. RBMA series blind mating RF coaxial connectors specification; Part --- Article 44. SMP series RF coaxial connectors specification; Part --- Article 45. SQMA series quick lock RF coaxial connectors specification; --- Part 47. Fquick series 75Ω cable distribution systems specification for plug-in radio frequency coaxial connector; Part --- Article 48. BMP series blind mating RF coaxial connectors specification; Part --- Article 49. SMAA series RF coaxial connectors specification; --- Section 101. MMCX Series RF coaxial connector specification (GB/T 11313.101-2015). This section GB/T 11313 Part 16. This section drafted in accordance with GB/T 1.1-2009 given rules. This section uses redrafted law Reference IEC 61169-16.2006 "radio frequency connectors - Part 16. Sectional specification for the inner diameter of the outer conductor 7mm (0.276in), a characteristic impedance of 50Ω (75Ω), threaded connection RF coaxial connectors (N-type) "prepared with IEC 61169-16.2006 The non-equivalent. This part of IEC 61169-16.2006 The main technical differences are as follows. --- The "IEC type designation" in Appendix B as an informative annex (see Appendix B, IEC 61169-16.2006 Chapter 3); --- The Figs. 2 and FIG. 1 is a combined (see Figure 1, IEC 61169-16.2006 in Figures 1 and 2); --- Table 1, the minimum size from 0.0 g to "0.08" (see Table 1, IEC 61169-16.2006 Table 1); --- Figures 3 and 4 will be combined into Figure 2 (see Fig. 2, IEC 61169-16.2006 Figure 3 and Figure 4); Fig --- hole 5a and 5b, respectively, to FIG. 3a) and Figure 3b), and FIG. 3a), an increase of line segments; Fig. 3b), increased Chamfer size requirements (1.27mm × 45 °) (see Figure 3a) and Figure 3b), IEC 61169-16.2006 in Figures 5a and 5b); --- By deleting "Recommended Quality Standards Regulation.200g in a vertical downward should be able to hold the standard gauge." (See 3.2.1.2, IEC 61169-16.2006 In 5.1.1.2); --- Figures 7 and 8 will be merged into the FIG. 5 (see Fig. 5, IEC 61169-16.2006 in Figures 7 and 8); --- Figures 9 and 10 will be combined in FIG. 6, the structure and the socket contact is optimized (see Fig. 6, IEC 61169-16.2006 of FIG. 9 and 10); --- Remove the "Dimensions" (see IEC 61169-16.2006 Chapter 6); --- Added "preferred climatic categories Table 7" (Table 7); --- The IEC cable model instead of the corresponding cable type (see Table 8, IEC 61169-16.2006 Table 6); --- Remove Class 1 connector reflectance right angle connector (see Table 7, IEC 61169-16.2006 Table 6). Please note that some of the content of this section may involve patents. This part of the release mechanism does not assume the responsibility to identify these patents. This part is proposed by the Ministry of Industry and Information Technology of the People's Republic of China. This section is under the jurisdiction of the National electronic equipment with a high-frequency cables and connectors Standardization Technical Committee (SAC/TC190). This section drafted by. China Electronics Standardization Institute, China Electronics Technology Group Corporation fortieth Institute, Jiangsu and Jiangsu all News Limited. The main drafters of this section. Wu Zhengping, Qiao Changhai, Chen Guohua, Guo Yan, Wuxiang Wen. RF connectors - Part 16. inner diameter of the outer conductor 7mm (0.276in), characteristic impedance is 50Ω (75Ω), Threaded RF coaxial connectors (N-type) specification

1 Scope

GB/T 11313 provisions of this part of the characteristic impedance of the N-type RF coaxial connectors 50Ω size of the mating interface, standard gauge inspection Test requirements, rating and characteristics of the product, as well as GB/T 11313.1-2013 selected from all the detailed regulations applicable to N-type connector Fan test schedule and inspection requirements. A characteristic impedance of 50Ω N-type connector has three levels of products between each level products to each other Mating. Universal RF connector (Level 2) preferentially with SYV-50-7 and other radio frequency cable connection frequencies up to 11GHz. High Performance RF connector (1) is particularly suitable when the demand is lower than the reflection coefficient of the reflection coefficient of the universal connector microwave applications, It can also be used for microwave components. Its interface dimensional tolerances between 0 and 2, can be obtained by selecting the performance requirements. Some comply with this Level 1 standard connector highest frequency up to 18GHz. Standard Test Connectors (0) with precise control of the interface, having the above-described two kinds of measurement interface connectors, cable assemblies, components And apparatus for providing a reference. When asked highest frequency of 18GHz most sophisticated interface, it can also be used as a microwave connectors use. This section also defines the characteristic impedance of 75Ω N type RF coaxial connector interface (see Appendix A), but because of the accident and the 75Ω 50Ω connector cross connection may damage the connector 75Ω, therefore, does not recommend the use of a characteristic impedance of 75Ω N-type connector. This section presents the development of the N-type RF coaxial connectors detailed specification and content rules, and blank detail specification format. This section shows the recommended performance characteristics when preparing a detailed specification should be considered, including the M-Class and H-level assessment level List of test and inspection requirements. This section applies to the N-type RF coaxial connectors. N-type RF coaxial connectors with threaded coupling mechanism, in low to medium power applications Occasions. This part of the original size in inches, not all note sizes graphical structure for reference only.

2 Normative references

The following documents for the application of this document is essential. For dated references, only the dated version suitable for use herein Member. For undated references, the latest edition (including any amendments) applies to this document. GB/T 11313.1-2013 RF connectors - Part 1. Generic specification - General requirements and test methods (IEC 61169-1.1998, IDT)

3 mating interface and standard gauge

Universal Connector size 3.1 - Level 2 3.1.1 pin connector Pin connector interface shown in Figure 1, the size of Table 1. ......
