FZ/T 90060.5-2005: Textile machinery. Product drawing and design document. Part 5: Format
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
FZ/T 90060.5-2005	999	Add to Cart	6 days	Textile machinery. Product drawing and design document. Part 5: Format	Valid

Similar standards

FZ/T 93048.1 FZ/T 93019 FZ/T 90074 FZ/T 90060.10 FZ/T 90055

Basic data

Standard ID: FZ/T 90060.5-2005 (FZ/T90060.5-2005)
Description (Translated English): Textile machinery. Product drawing and design document. Part 5: Format
Sector / Industry: Spinning & Textile Industry Standard (Recommended)
Classification of Chinese Standard: W90
Classification of International Standard: 59.120
Word Count Estimation: 40,437
Date of Issue: 2005-05-18
Date of Implementation: 2006-01-01
Older Standard (superseded by this standard): FZ/T 90063-1995; FZ/T 90064-1995
Quoted Standard: GB/T 1.1; GB/T 4457.4; GB/T 14691; GB/T 17825.2
Regulation (derived from): NDRC Notice No. 24 of 2005
Issuing agency(ies): National Development and Reform Commission, People Republic of China
Summary: This standard specifies the textile machinery drawings and design documents, including CAD drawings and design documents (hereinafter referred to as CAD files) format and fill in the rules. This section applies to the textile machinery industry, product design and design file format. Other product drawing and design document format is also available for implementation.

FZ/T 90060.5-2005: Textile machinery. Product drawing and design document. Part 5: Format

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Textile machinery.Product drawing and design document.Part 5. Format ICS 59.120 W90 People's Republic of China Textile Industry Standard Replace FZ/T 90063-1995, FZ/T 90064-1995 Textile machinery product drawings and design documents Part 5. Format Released on.2005-05-18 2006-01-01 implementation National Development and Reform Commission of the People's Republic of China

Content

Foreword III 1 Scope 1 2 Normative references 1 3 Product pattern format and method 1 4 Format and drawing method of machine sketch 4 5 Design file format 6 Appendix A (informative appendix) Appendix B (informative appendix) summary table filling example 28 Appendix C (informative) Example of spare parts table filling 31 Appendix D (informative appendix) Chart catalogue example 32 Appendix E (informative appendix) File Directory Filling Example 36

Foreword

FZ/T 90060 includes the following nine parts under the general title of "Textile Machinery Product Drawings and Design Documents". --- Part 1. General; --- Part 2. Numbering; --- Part 3. Requirements for drawings; --- Part 4. Requirements for design documents; --- Part 5. Format; --- Part 6. Integrity; --- Part 7. Change; --- Part 8. Standardization review; --- Part 9. Management. This part is the fifth part of FZ/T 90060. This part is based on the needs of enterprises to implement computer-aided design (CAD) and enterprise quality management system and product market competition. According to relevant national standards and industry standards, the characteristics of the textile machinery industry have been fully considered. In the original FZ/T 90063-1995 "Textile machinery design On the basis of the requirements, format and method of the document and FZ/T 90064-1995 "Format and method of textile machinery product drawings" Revised. This part replaces FZ/T 90064-1995 "Format and Filling of Textile Machinery Product Drawings", and at the same time partially replaces FZ/T 90063-1995 "Requirements, Formats and Replacement of Textile Machinery Design Documents". The main differences from the original standard are as follows. ---The standard name is changed from "requirements, format and method of product drawings and design documents" to "Textile machinery product drawings and designs" Document Part 5. Format"; --- The title bar of the drawing and the signature column of the design file have been added to the "Approval" column; ---Electrical drawings, detailed list, summary table and mechanical products have been unified; --- In order to facilitate computer input, the corner note in the original standard was cancelled; --- Mix the chart with the text for easy access. Appendix A, Appendix B, Appendix C, Appendix D, and Appendix E of this part are informative annexes. This part was proposed by the China Textile Industry Association. This part is under the jurisdiction of the National Textile Machinery and Accessories Standardization Technical Committee. This section is mainly drafted by. China Textile Machinery Research Institute, Zhengzhou Textile Machinery Co., Ltd., Shaoyang Textile Machinery Co., Ltd., Jingwei Textile Machinery Co., Ltd., China Textile Machinery (Group) Co., Ltd., Best Machinery Manufacturing Co., Ltd. The main drafters of this section. Huang Hongkang, Yan Guohong, Lin Jian, Shen Yingquan, Zhao Guanhong, Xu Jinglu. Textile machinery product drawings and design documents Part 5. Format

1 Scope

This part of FZ/T 90060 specifies the textile machinery product drawings and design documents, including CAD drawings and design documents (hereinafter referred to as CAD file) format and fill in the rules. This section applies to the format of product drawings and design documents for the textile machinery industry. Other product drawings and design file formats can also be referred to carried out.

2 Normative references

The provisions in the following documents become the provisions of this part by reference to this part of FZ/T 90060. Quotations with dated , all subsequent amendments (not including errata content) or revisions do not apply to this section, however, encouragement is achieved under this section The parties to the agreement study whether the latest versions of these documents can be used. For undated references, the latest edition applies to this section. GB/T 1.1 Standardization Work Guidelines Part 1. Standard Structure and Writing Rules GB/T 4457.4 mechanical drawing pattern drawing line GB/T 14691 technical drawing font GB/T 17825.2 CAD file management basic format

3 Product pattern format and filling method

3.1 General requirements 3.1.1 The product drawings should generally have a frame, a title bar, a change record column, a code column, and a custody record bar. There should also be a detail column on the assembly drawing, circuit diagram, and electrical assembly drawing, as shown in Figure 1. Figure 1 3.1.2 The fonts and line types of each column shall comply with the provisions of GB/T 14691 and GB/T 4457.4, respectively, except for signature. 3.1.3 Date signing should be standardized, such as.2003-04-30 or.2003.04.30. 3.1.4 The various symbols of the frame configuration of the CAD drawing shall be in accordance with the provisions of GB/T 17825.2. ......
