TB/T 2211-2010: Steel helical spring of suspension mechanism for rolling stock Delivery: 9 seconds. True-PDF full-copy in English & invoice will be downloaded + auto-delivered via email. See step-by-step procedure Status: Obsolete TB/T 2211: Historical versions
Similar standardsTB/T 2211-2010: Steel helical spring of suspension mechanism for rolling stock---This is an excerpt. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.), auto-downloaded/delivered in 9 seconds, can be purchased online: https://www.ChineseStandard.net/PDF.aspx/TBT2211-2010TB RAILWAY INDUSTRY STANDARD ICS 45.060 S 40 Partially replacing TB/T 1025-2000, replacing TB/T 2211-1991 Steel helical spring of suspension mechanism for rolling stock Issued on: DECEMBER 02, 2010 Implemented on: JUNE 01, 2011 Issued by. Ministry of Railways of People’s Republic of China 3.No action is required - Full-copy of this standard will be automatically & immediately delivered to your EMAIL address in 0~60 minutes. Table of ContentsForeword... 4 1 Scope... 6 2 Normative references... 6 3 Terms and definitions, symbols, units, descriptions and geometric characteristics... 7 3.1 Terms and definitions... 7 3.2 Symbols, units, description... 8 3.3 Geometric characteristics... 10 4 Product classification... 10 5 General application requirements... 11 5.1 Conditions of use... 11 5.2 Performance requirements... 11 5.3 Basic requirements... 17 6 Product technical specification... 19 6.1 Technical characteristics of products... 19 6.2 Design features... 20 6.3 Materials... 21 6.4 Mechanical properties of springs... 22 6.5 Surface protection... 23 7 Test method... 23 7.1 Summary... 23 7.2 Axial force-deformation test... 24 7.3 Transverse stiffness test... 25 7.4 Horizontal free offset or bowing... 27 7.5 Geometric characteristic test... 27 7.6 Product requirements... 28 7.7 Mechanical performance requirements... 30 7.8 Surface protection... 30 7.9 Fatigue test... 31 8 Product quality... 31 8.1 Product certification procedures and samples... 31 8.2 Product sampling... 32 8.3 Type inspection and exit-factory inspection... 33 8.4 Product nonconformity... 33 9 Marking... 34 10 Packaging... 34 Appendix A (Normative) Equal pitch and end closed & ground cylindrical helical compression spring made from circular steel bar... 35 A.1 Summary... 35 A.2 Inner and outer diameters... 35 A.3 End coil of spring... 36 A.4 Contact line... 36 A.5 Geometric tolerances... 37 A.6 Spacing between coils... 38 Appendix B (Normative) Magnetic flaw detection of helical spring surface defects made by circular steel bar... 41 B.1 Summary... 41 B.2 Method... 41 B.3 Special precautions... 42 Appendix C (Normative) Fatigue test of steel helical spring for suspension.. 43 C.1 Test requirements... 43 C.2 Vertical fatigue test... 43 C.3 Transverse fatigue test... 44 C.4 Inspection after fatigue test... 45 References... 46ForewordThis standard was drafted in accordance with the rules given in GB/T 1.1-2009. This standard partially replaces the suspension spring part of the TB/T 1025-2000 “Technical conditions for the supply of hot coil helical compression springs for rolling stock”, AND the part which is not replaced is the spring used for buffer and traction device. As compared with TB/T 1025-2000 “Technical conditions for the supply of hot coil helical compression springs for rolling stock”, the main technical changes of this standard are as follows. - ADD the spring material dedicated for railway AND some spring materials of European standards (SEE 6.3.3 and Table 5 of 6.4.1); - ADD the information of spring transverse movement (SEE item 15 of Table 1), transverse stiffness (SEE 5.2.3.2), transverse free offset or bending (SEE 5.2.3.3), transverse stiffness test (SEE 7.3), and transverse fatigue test (SEE Appendix C); DETAIL the spring transverse characteristics, calculation, and test methods; - MAKE reference to the determination of non-metallic inclusions in steel – Standard rating chart microscopy method in GB/T 10561-2005. This standard replaces TB/T 2211-1991 “Fatigue test of cylindrical helical spring for rolling stock”. As compared with TB/T 2211-1991, the main technical changes are as follows. - DELETE the Appendix C “Repeatability of shot peening pre-stressing effect” of EN 13298.2002 (SEE Appendix C of 2003 version); - ADD the TB/T 1758 “Technical conditions for shot peening of rolling stock springs”, which is directly quoted in the standard (SEE 5.3.2.4); - ADD the “Fatigue test” requirements (SEE 7.9); - ADD the transverse fatigue test methods; ADJUST the spring vertical and transverse fatigue test specifications (SEE Appendix C); - MAKE adjustment against the contents of the reference (SEE references). This standard, through the re-drafting method, modifies and adopts EN 13298.2002 “Railway applications - Suspension components – Helical suspension springs, steel”. Steel helical spring of suspension mechanism for rolling stock1 ScopeThis standard specifies the geometric characteristics, application requirements, technical specification, test methods, product quality, marking and packaging of the steel helical spring of suspension mechanism for the newly designed rolling stock (hereinafter referred to as spring). This standard applies to. - Steel helical spring of suspension mechanism for railway rolling stock; - Equal pitch cylindrical compression springs made of circular cross-section equal-diameter steel bar; - Other different shaped helical springs (such as conical helical springs, unequal pitch springs, or the springs made of steel bar having other shaped cross-sections).2 Normative referencesThe following documents are essential to the application of t... ......Source: Above contents are excerpted from the full-copy PDF -- translated/reviewed by: www.ChineseStandard.net / Wayne Zheng et al. |
