GB/T 37692-2019: Running mode specific fuel consumption limits and measurement methods for small spark ignition engines of non-road mobile machinery Delivery: 9 seconds. True-PDF full-copy in English & invoice will be downloaded + auto-delivered via email. See step-by-step procedure Status: Valid
Similar standardsGB/T 37692-2019: Running mode specific fuel consumption limits and measurement methods for small spark ignition engines of non-road mobile machinery---This is an excerpt. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.), auto-downloaded/delivered in 9 seconds, can be purchased online: https://www.ChineseStandard.net/PDF.aspx/GBT37692-2019 GB NATIONAL STANDARD OF THE PEOPLE’S REPUBLIC OF CHINA ICS 27.020 J 91 Running mode specific fuel consumption limits and measurement methods for small spark ignition engines of non-road mobile machinery ISSUED ON: JUNE 04, 2019 IMPLEMENTED ON: JANUARY 01, 2020 Issued by: State Administration for Market Regulation; Standardization Administration of the PRC. Table of ContentsForeword ... 3 1 Scope ... 4 2 Normative references ... 5 3 Terms and definitions ... 5 4 Technical requirements ... 6 5 Running mode specific fuel consumption measurement ... 7 Appendix A (Normative) Devices and accessories installed to determine engine power ... 8 Appendix B (Normative) Standard reference condition power correction and test procedure ... 12 Appendix C (Normative) Calculation of running mode specific fuel consumption ... 18 Appendix D (Normative) Measurement results ... 19 Table 1 -- Engine category in cm3 ... 7 Table 2 -- Running mode specific fuel consumption limits for engines ... 7 Table A.1 -- Devices and accessories installed to determine engine power ... 8 Table B.1 -- Test conditions and weight coefficients ... 15 Table D.1 -- Power absorbed by the accessories at the indicated engine speed ... 20 Table D.2 -- Engine power in kW ... 20 Table D.3 -- Dynamometer setting value in kW ... 21 Running mode specific fuel consumption limits and measurement methods for small spark ignition engines of non-road mobile machinery1 ScopeThis Standard specifies the running mode specific fuel consumption limits and measurement methods for small spark ignition engines of non-road mobile machinery (hereinafter referred to as "engines"), which use gasoline, etc. as fuel. This Standard applies to (but not limited to) the following non-road mobile machinery engines with a net power of not more than 19 kW: - Lawn mower ; - Chain saw; - Generator; - Water pump; - Brush cutter; - Mini-tiller; - Rice transplanter; - Hedgerow machine; - Hair dryer; - Snowplow; - High-pressure washer; - Vibratory plate compactor; - Troweling machine. This Standard does not apply to engines for the following purposes: - Engines used to drive ships; 3.1 Fuel consumption The amount of fuel consumed by an engine per unit time under specified environmental conditions and specified power. [GB/T 21404-2008, definition 3.4.1] 3.2 Specific fuel consumption The amount of fuel consumed by an engine per unit power and unit time. [GB/T 21404-2008, definition 3.4.1.1] 3.3 Running mode specific fuel consumption The weighted mean of the specific fuel consumption of an engine under multiple working conditions. 3.4 Net power The power measured from the crankshaft end or its equivalent parts, at the corresponding engine speed, when the engine is installed with engine installation and accessories in accordance with the requirements of Table A.1 in Appendix A on the test bench. 3.5 Intermediate speed 85% of the rated speed when the engine is tested in the G1 cycle.4 Technical requirements4.1 Engine classification The engine category code and corresponding working volume are shown in Table 1. Hand-held engines are represented by "SH". Non-hand-held engines are represented by "FSH".Appendix B(Normative) Standard reference condition power correction and test procedure B.1 Reference condition power correction B.1.1 Standard reference condition In order to determine the power and fuel consumption of the engine, the following standard reference condition shall be used: Total air pressure: Pr=100 kPa; Air temperature: Tr=298 K (tr=25 °C); Relative humidity: ϕr=30%. B.1.2 Power correction calculation method The power correction method shall be in accordance with the requirements in Clause 7 of GB/T 21404-2008. B.2 Test procedure B.2.1 Test conditions B.2.1.1 Engine's intake system The test engine shall be equipped with an intake system that is representative of the actual use. When the engine uses a clean air filter and operates according to the maximum intake air flow condition of the corresponding purpose, its intake resistance shall be within 110% of the upper limit specified by the manufacturing enterprise. B.2.1.2 Engine's exhaust system The test engine shall be equipped with an exhaust system that is representative of the actual use. When the engine is running at the maximum rated power condition for the corresponding purpose, its exhaust back pressure shall be within 110% of the upper limit specified by the manufacturing enterprise. B.2.1.3 Cooling system The engine cooling system used shall have sufficient capacity to maintain the engine at the normal operating temperature specified by the manufacturing enterprise. B.2.1.4 Lubricating oil The lubricating oil, specified by the engine manufacturing enterprise for the engine and its intended use, shall be selected. The specification of lubricating oil used for engine test shall be recorded in D.1.2. And it shall be shown together with the test result. B.2.1.5 Test fuel It shall use gasoline that meets GB 17930 or benchmark gasoline that meets the technical requirements of GB 18352.5; or use ethanol gasoline that meets the technical requirements of GB 18351. The fuel/lubricating oil mixture ratio of the two-stroke engine shall meet the recommended value of the manufacturing enterprise and be recorded in D.1.1. B.2.1.6 Dynamometer setting It shall remove the accessories only needed to operate non-road mobile machinery. Where the accessories cannot be removed, the absorbed power of these accessories shall be determined, to calculate the dynamometer setting; unless the accessories are an integral part of the engine (such as the cooling fan of an air-cooled engine). Engine intake resistance and exhaust back pressure shall be adjusted according to B.2.1.1 and B.2.1.2. In order to calculate the torque value of the specified test conditions, through the test, the maximum torque value at the specified test speed shall be determined. For engines that are not designed to work within the speed range of the full-load torque curve, the manufacturing enterprise shall specify the maximum torque value at the test speed. The setting value of the dynamometer under each test condition shall be calculated according to formula (B.1): Where: S - The setting value of dynamometer, in kilowatts (kW); PM - The maximum power measured under the test conditions and test speed in Appendix A or declared by the manufacturing enterprise, in kilowatts (kW); PAE - The power absorbed by the accessories declared in addition to Appendix ......Source: Above contents are excerpted from the full-copy PDF -- translated/reviewed by: www.ChineseStandard.net / Wayne Zheng et al. Tips & Frequently Asked Questions:Question 1: How long will the true-PDF of English version of GB/T 37692-2019 be delivered?Answer: The full copy PDF of English version of GB/T 37692-2019 can be downloaded in 9 seconds, and it will also be emailed to you in 9 seconds (double mechanisms to ensure the delivery reliably), with PDF-invoice.Question 2: Can I share the purchased PDF of GB/T 37692-2019_English with my colleagues?Answer: Yes. The purchased PDF of GB/T 37692-2019_English will be deemed to be sold to your employer/organization who actually paid for it, including your colleagues and your employer's intranet.Question 3: Does the price include tax/VAT?Answer: Yes. Our tax invoice, downloaded/delivered in 9 seconds, includes all tax/VAT and complies with 100+ countries' tax regulations (tax exempted in 100+ countries) -- See Avoidance of Double Taxation Agreements (DTAs): List of DTAs signed between Singapore and 100+ countriesQuestion 4: Do you accept my currency other than USD?Answer: Yes. www.ChineseStandard.us -- GB/T 37692-2019 -- Click this link and select your country/currency to pay, the exact amount in your currency will be printed on the invoice. Full PDF will also be downloaded/emailed in 9 seconds.How to buy and download a true PDF of English version of GB/T 37692-2019?A step-by-step guide to download PDF of GB/T 37692-2019_EnglishStep 1: Visit website https://www.ChineseStandard.net (Pay in USD), or https://www.ChineseStandard.us (Pay in any currencies such as Euro, KRW, JPY, AUD).Step 2: Search keyword "GB/T 37692-2019". Step 3: Click "Add to Cart". If multiple PDFs are required, repeat steps 2 and 3 to add up to 12 PDFs to cart. Step 4: Select payment option (Via payment agents Stripe or PayPal). Step 5: Customize Tax Invoice -- Fill up your email etc. Step 6: Click "Checkout". Step 7: Make payment by credit card, PayPal, Google Pay etc. After the payment is completed and in 9 seconds, you will receive 2 emails attached with the purchased PDFs and PDF-invoice, respectively. Step 8: Optional -- Go to download PDF. Step 9: Optional -- Click Open/Download PDF to download PDFs and invoice. See screenshots for above steps: Steps 1~3 Steps 4~6 Step 7 Step 8 Step 9 |
