YS/T 1124-2016 English PDFUS$149.00 · In stock
Delivery: <= 3 days. True-PDF full-copy in English will be manually translated and delivered via email. YS/T 1124-2016: Testing method on pass through flux of magnetic sputtering target Status: Valid
Basic dataStandard ID: YS/T 1124-2016 (YS/T1124-2016)Description (Translated English): Testing method on pass through flux of magnetic sputtering target Sector / Industry: Nonferrous Metallurgy Industry Standard (Recommended) Classification of Chinese Standard: H21 Word Count Estimation: 5,543 Date of Issue: 2016-07-11 Date of Implementation: 2017-01-01 Regulation (derived from): Notice of the Ministry of Industry and Information Technology (2016 No. 37) Issuing agency(ies): Ministry of Industry and Information Technology Summary: This standard specifies the terms and definitions of magnetic permeability of magnetic targets for magnetron sputtering, testing equipment, inspection procedures and calculation of results. YS/T 1124-2016: Testing method on pass through flux of magnetic sputtering target---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.Testing method on pass through flux of magnetic sputtering target ICS 77.120.99 H21 People's Republic of China Nonferrous Metals Industry Standard Measurement method of magnetic permeability of magnetic sputtering target 2016-07-11 released 2017-01-01 Implementation Issued by the Ministry of Industry and Information Technology of the People's Republic of China ForewordThis standard is drafted in accordance with the rules given in GB/T 1.1-2009. This standard is proposed by the National Committee for Standardization of Nonferrous Metals (SAC/TC243). The drafting of the standard units. the new research and development of new materials Co., Ltd., non-ferrous metals technology and economic research institute. The main drafters of this standard. Luo Junfeng, Wan Xiaoyong, Xiang Lei, Ding Zhaoocong, Li Yongjun, He Jinjiang, Xu Guojin, Xia Qiankun, Liu Xiao, Wang Yue. Measurement method of magnetic permeability of magnetic sputtering target1 ScopeThis standard specifies the terms and definitions of the permeability of magnetic targets for magnetron sputtering, the testing equipment, the inspection process and the calculation of the results. This standard applies to the sputtering film with a variety of magnetic target permeability test.2 terms and definitionsThe following terms and definitions apply to this standard. 2.1 Permeability passthroughflux PTF DC magnetic field from the magnetic target side through the other side of the ratio, also known as magnetic permeability. 2.2 Source magnetic field The magnetic field near the surface of the stage, measured by the Hall probe Gauss meter, is the DC magnetic field in units of Gs. 2.3 Reference field The magnitude of the magnetic field at the top surface of the stage preset target depends on the distance of the Hall probe to the source magnet. 2.4 Measuring the magnetic field The magnetic field at which the sputtering target is placed on the upper surface of the target after the stage.3 detection equipmentThe magnetic permeability testing equipment mainly comprises a source magnet, a stage, a Gauss meter and a Hall probe, etc. The device is placed on a non-ferromagnetic material or external Strong magnetic field interference in the environment. Schematic diagram shown in Figure 1. 3.1 source magnet The source magnet is a horseshoe shaped permanent magnet, fixed to the bottom of the stage and remains stable. The source magnet is polarized parallel to the stage of the stage. Adjustment The position of the source magnet from the stage is such that the source magnetic field measured by the Hall probe Gauss meter is 825Gs ± 50Gs. 3.2 Gauss meter The Gauss meter is the core device for PTF detection, with a horizontal field Hall probe. The Gauss meter DC magnetic field measurement range is 0 ~ 3500Gs, accuracy of ± 2%. Hall probe in the source magnet positive pole position, as shown in Figure 1a). Hall probe is located above the sample, Can only be moved up and down by the adjustment bracket and relatively fixed with the magnet at the horizontal position. 3.3 stage The carrier platform as a target bearing platform exists in the permeability testing equipment, located between the source magnet and the Hall probe, the stage is equipped with ......Tips & Frequently Asked Questions:Question 1: How long will the true-PDF of YS/T 1124-2016_English be delivered?Answer: Upon your order, we will start to translate YS/T 1124-2016_English as soon as possible, and keep you informed of the progress. The lead time is typically 1 ~ 3 working days. The lengthier the document the longer the lead time.Question 2: Can I share the purchased PDF of YS/T 1124-2016_English with my colleagues?Answer: Yes. The purchased PDF of YS/T 1124-2016_English will be deemed to be sold to your employer/organization who actually pays for it, including your colleagues and your employer's intranet.Question 3: Does the price include tax/VAT?Answer: Yes. Our tax invoice, downloaded/delivered in 9 seconds, includes all tax/VAT and complies with 100+ countries' tax regulations (tax exempted in 100+ countries) -- See Avoidance of Double Taxation Agreements (DTAs): List of DTAs signed between Singapore and 100+ countriesQuestion 4: Do you accept my currency other than USD?Answer: Yes. If you need your currency to be printed on the invoice, please write an email to Sales@ChineseStandard.net. In 2 working-hours, we will create a special link for you to pay in any currencies. Otherwise, follow the normal steps: Add to Cart -- Checkout -- Select your currency to pay. |
