LY/T 3228-2020 English PDFUS$229.00 · In stock
Delivery: <= 3 days. True-PDF full-copy in English will be manually translated and delivered via email. LY/T 3228-2020: Preservative pressure-treated glulam Status: Valid
Basic dataStandard ID: LY/T 3228-2020 (LY/T3228-2020)Description (Translated English): Preservative pressure-treated glulam Sector / Industry: Forestry Industry Standard (Recommended) Classification of Chinese Standard: B71 Classification of International Standard: 79.020 Word Count Estimation: 10,186 Date of Issue: 2020-12-29 Date of Implementation: 2021-06-01 Regulation (derived from): Announcement No. 25 (2020) of the State Forestry and Grassland Administration Issuing agency(ies): State Forestry and Grassland Administration LY/T 3228-2020: Preservative pressure-treated glulam---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.Preservative pressure-treated glulam People's Republic of China Forestry Industry Standard Pressurized anti-corrosion treatment glulam 2020-12-29 release 2021-06-01 implementation Issued by the State Forestry and Grassland Administration ForewordThis document starts from the provisions of GB/T 1.1-2020 "Guidelines for Standardization Work Part 1.Structure and Drafting Rules of Standardization Documents" grass. This document was proposed and managed by the National Wood-based Panel Standardization Technical Committee (SAC/TC 198). Drafting organizations of this document. Guangdong Academy of Forestry, Research Institute of Wood Industry, Chinese Academy of Forestry, South China Agricultural University, Sichuan Hengxi Wood Industry Co., Ltd., Dongguan Tianyuan Wooden House Manufacturing Co., Ltd., Shanghai Weiqi Industrial Co., Ltd., Fengsheng (Guangzhou) Building Materials Co., Ltd. The main drafters of this document. Cao Yongjian, Duan Xinfang, Li Xingwei, Chen Lifang, Yuan Naxin, Wang Jianjing, Ma Hongxia, He Xuexiang, Wen Qing Hui, Hu Minghui, Wang Zhiwei, Ma Zuorui, Xie Guijun, Wang Song, Li Yixin, Li Wanju. Pressurized anti-corrosion treatment glulam1 ScopeThis document specifies the terms and definitions, classification, requirements, inspection requirements, inspection rules, and labeling and packaging of pressurized anti-corrosion treated glulam. Loading, transportation and storage. This document applies to glulam that has been pressurized with water-borne preservatives or organic solvent-based preservatives.2 Normative referencesThe contents of the following documents constitute the indispensable clauses of this document through normative references in the text. Among them, dated reference documents, Only the version corresponding to that date is applicable to this document; for undated references, the latest version (including all amendments) is applicable to this document file. GB/T 14019-2009 Terminology for Wood Preservation GB/T 17659.2-2018 Sampling and determination method for batch inspection of sawn timber. Part 2.Sampling and determination method for batch inspection of sawn timber GB/T 23229-2009 Water-borne wood preservative analysis method GB/T 26899-2011 Glulam for structural use GB/T 27651 Classification and requirements for the use of anticorrosive wood GB/T 27654 Wood preservative GB/T 33021-2016 Analysis method of organic wood preservatives triazole and benzimidazole GB 50005 Wood Structure Design Standard GB 50206 Construction Quality Acceptance Code for Timber Structure Engineering GB/T 50708-2012 Technical specification for glulam structure LY/T 1925 Anti-corrosion wood product labeling3 Terms and definitionsThe following terms and definitions defined in GB/T 14019-2009 and GB/T 50708-2012 apply to this document. 3.1 Structural laminated timber (Glulam) The wood products are laminated and glued along the grain direction with boards with a thickness of 20 to 45 mm. Also called plywood, or structural Glulam. [Source. GB/T 50708-2012, 2.1.1] 3.2 Laminate laminations Each layer of board that constitutes pressurized anti-corrosion treatment glulam. 3.3 Preservative pressure treatment In a closed container, under certain pressure, the anti-corrosion treatment of laminates or glulam. 3.4 Exposed sapwood The sapwood along the length or cross section of glulam has at least two adjacent surfaces exposed to the air at the same time (Figure 1). Figure 1 Schematic diagram of exposed sapwood and non-exposed sapwood 3.5 Penetration The degree of penetration of the preservative (active ingredient) into the wood, including the depth of penetration of the preservative into the wood and the penetration rate of the preservative in the sapwood. [Source. GB/T 14019-2009, 3.5.21]4 categoriesAccording to the final use environment and exposure conditions of pressurized anti-corrosion treatment of glulam, as well as the biodegradation factor under different environmental conditions, the effect of pressurization The hazard degree of rot-treated glulam wood is classified into five categories. C1, C2, C3.1, C3.2, and C4.1.(See Table 1).5 requirements5.1 Raw material requirements 5.1.1 Shelves The same tree species or different tree species with similar wood properties, good permeability and easy to do anti-corrosion treatment should be used as the laminate. All laminates The difference in moisture content should be < 5%. The quality of the laminate should meet the requirements of GB/T 26899-2011. 5.1.2 Adhesive Should meet the requirements of GB/T 50708-2012. 5.1.3 Preservatives Should meet the requirements of GB/T 27654. 5.1.4 Physical and mechanical properties It shall meet the requirements of GB/T 26899-2011, GB 50005, and GB 50206. 5.2 Product quality requirements 5.2.1 Appearance quality The surface of pressurized anti-corrosion treatment glulam should have no visible deposits of antiseptic, and no obvious defects such as cracks, twists, and bends. 5.2.2 Moisture content The moisture content of pressurized anti-corrosion treatment glulam should be between 8% and 15% in the north and between 8% and 18% in the south. It can also be agreed by both parties. 5.2.3 Physical and mechanical properties The physical and mechanical properties of pressurized anti-corrosion treatment glulam shall meet the requirements of GB/T 26899. 5.2.4 Drug loading The loading capacity of commonly used preservatives for pressurized preservative treatment of glulam should meet the requirements of Table 2.The loading capacity of other preservatives should comply with GB/T 27651 Requirements. Note. NR means it is not recommended. 5.2.5 Penetration 5.2.5.1 Category C1 The penetration rate of the preservative in the exposed sapwood should be ≥85%, and there is no requirement for the heartwood. 5.2.5.2 Category C2 5.2.5.3 C3.1, C3.2 category The penetration rate of the preservative in the exposed sapwood should be ≥90% and meet one of the following conditions. 1) Glulam thickness ≤35 mm, preservative penetration on the exposed surface or end of the heartwood ≥5 mm; Glulam thickness >35 mm, preservative Penetrate ≥ 8 mm on the exposed surface or end of the heartwood. 2) When preservatives are allowed to not penetrate the heartwood, it should be satisfied at the same time. In each laminate, the area of the heartwood (S1) is smaller than the area of the end face of the laminate (S1 S2) The depth (L1) does not exceed 50% of the end surface distance (L2), and the width (L3) does not exceed 50% of the distance between the two sides of the end surface (L4) (Figure 3). Figure 3 Schematic diagram of cross section of glulam laminate 5.2.5.4 Category C4.1 The penetration rate of the preservative in the sapwood should be ≥90% and meet one of the following conditions. 1) The preservative penetrates ≥10 mm on the exposed surface or end of the core material of each laminate; 2) When allowing preservatives not to penetrate into the heartwood, it should be satisfied at the same time. In each laminate, the area of the heartwood (S1) is smaller than the area of the end face of the laminate (S1 S2) The depth (L1) does not exceed 50% of the end surface distance (L2), and the width (L3) does not exceed 50% of the distance between the two sides of the end surface (L4) (Figure 3).6 Inspection methodHeartwood Unexposed sapwood Heartwood Heartwood Sapwood 6.1 Sampling method and quantity 6.1.1 Appearance quality According to GB/T 17659.2-2018 regulations. 6.1.2 Water content Cut two specimens of appropriate size from 10 mm to 50 mm in the length direction of the pressurized anticorrosive glulam. 6.1.3 Physical and mechanical properties The sampling method and quantity shall be carried out in accordance with 5.6 of GB/T 26899-2011. 6.1.4 Drug loading and penetration 1) For glulam that has been pressurized and preserved before gluing, if the processing volume of each batch of glulam is less than 5 m3, 5 samples should be taken. Each batch of glulam When the processing volume is greater than or equal to 5 m3, 10 samples are taken. One sample is drilled from the side of the plate where the inner layer of each sample is extended. 2) For glulam treated with anticorrosive treatment after gluing, when the batch glulam processing volume is less than 5 m3, 5 samples should be taken. Processing capacity of each batch of glulam When ≥5 m3, take 10 samples. Randomly drill a sample from each sample, and drill one test piece from each block. 3) After the sample is drilled, the non-testing wood core of the same tree species, the same treatment level or higher treatment level should be used to fill the hole back to the borehole. 6.2 Inspection 6.2.1 Appearance quality According to GB/T 17659.2-2018 regulations. 6.2.2 Water content Carry out in accordance with the provisions of 5.2 in GB/T 26899-2011. 6.2.3 Physical and mechanical properties According to GB/T 26899-2011 in 5.3, 5.4 regulations. 6.2.4 Drug loading and penetration The drug loading and penetration of water-borne preservatives in the pressurized preservative treatment of glulam shall be carried out in accordance with the provisions of GB/T 23229-2009, organic solvents The drug loading and penetration of type preservatives in pressurized preservative treated glulam shall be carried out in accordance with GB/T 33021-2016.7 Inspection rules7.1 Inspection classification 7.1.1 Factory inspection The factory inspection items include. appearance quality, moisture content, drug loading and penetration. 7.1.2 Type inspection Type inspection items include all indicators in this document. During normal production, the type inspection shall not be less than once every six months; when one of the following situations occurs, the type inspection shall be carried out. 1) When the raw and auxiliary materials and production process undergo major changes; 2) When production has been suspended for more than three months and production is resumed; 3) When the quality supervision department proposes type inspection requirements. 7.2 Judgment rules 7.2.1 Appearance quality According to GB/T 17659.2-2018 regulations. 7.2.2 Moisture content In the northern region, the test result is in the range of 8% to 15%; in the southern region, the test result is in the range of 8% to 18%. 7.2.3 Physical and mechanical properties Determined in accordance with the provisions of GB/T 26899, GB 50005, and GB 50206. 7.2.4 Drug loading and penetration 1) Determined in accordance with the provisions of GB/T 27651. 2) The pass rate of the test results should not be less than 80%. 3) If it is unqualified, it can be re-inspected, but sampling should be doubled, and the pass rate should not be less than 80%. 7.3 Comprehensive judgment When the raw materials and product quality of the samples are in accordance with the requirements of 5.1 and 5.2 of this document, the batch of products shall be judged to be qualified, otherwise The batch of products shall be judged as unqualified. 8 Identification, packaging, transportation and storage 8.1 Identification It should meet the requirements of LY/T 1925. 8.2 Packaging Products should be packaged separately according to product category and specifications when leaving the factory. It can also be determined based on negotiation between the supplier and the demander. 8.3 Transportation and storage Products should be stacked flat during transportation and storage to prevent rain and sun exposure. ......Tips & Frequently Asked Questions:Question 1: How long will the true-PDF of LY/T 3228-2020_English be delivered?Answer: Upon your order, we will start to translate LY/T 3228-2020_English as soon as possible, and keep you informed of the progress. The lead time is typically 1 ~ 3 working days. The lengthier the document the longer the lead time.Question 2: Can I share the purchased PDF of LY/T 3228-2020_English with my colleagues?Answer: Yes. The purchased PDF of LY/T 3228-2020_English will be deemed to be sold to your employer/organization who actually pays for it, including your colleagues and your employer's intranet.Question 3: Does the price include tax/VAT?Answer: Yes. Our tax invoice, downloaded/delivered in 9 seconds, includes all tax/VAT and complies with 100+ countries' tax regulations (tax exempted in 100+ countries) -- See Avoidance of Double Taxation Agreements (DTAs): List of DTAs signed between Singapore and 100+ countriesQuestion 4: Do you accept my currency other than USD?Answer: Yes. If you need your currency to be printed on the invoice, please write an email to Sales@ChineseStandard.net. In 2 working-hours, we will create a special link for you to pay in any currencies. Otherwise, follow the normal steps: Add to Cart -- Checkout -- Select your currency to pay. |
