JJG 755-2015: Ultraviolet Irradiance Working Standard Apparatus
Status: Valid

JJG 755: Historical versions

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
JJG 755-2015	509	Add to Cart	4 days	Ultraviolet Irradiance Working Standard Apparatus	Valid
JJG 755-1991	199	Add to Cart	2 days	Verification Reguiation of Working Standard Equipment for UV Irradiance	Obsolete

Similar standards

JJG 879 JJF 1106 JJG 810 JJG 452 JJG 211 JJG 745

Basic data

Standard ID: JJG 755-2015 (JJG755-2015)
Description (Translated English): Ultraviolet Irradiance Working Standard Apparatus
Sector / Industry: Metrology & Measurement Industry Standard
Classification of Chinese Standard: A60
Classification of International Standard: 17.180
Word Count Estimation: 22,258
Date of Issue: 2015-12-07
Date of Implementation: 2016-06-07
Older Standard (superseded by this standard): JJG 755-1991
Quoted Standard: JJG 384
Regulation (derived from): ?AQSIQ 2015 Nian (No.148)
Issuing agency(ies): General Administration of Quality Supervision, Inspection and Quarantine
Summary: This standard is applicable to the first verification, follow-up verification and inspection during operation of the UV-irradiance reference device.

JJG 755-2015: Ultraviolet Irradiance Working Standard Apparatus

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Ultraviolet Irradiance Working Standard Apparatus National Metrological Verification Regulation of the People's Republic of China UV radiation illumination work reference device 2015-12-07 released 2016-06-07 implementation State Administration of Quality Supervision, Inspection and Quarantine issued UV radiation illumination work reference device Verification procedures WorkingStandard Appliances Replacing JJG 755-1991 Coordinate unit. National Committee for Optical Metrology The main drafting unit. China Institute of Metrology Beijing Normal University Participated in the drafting unit. Beijing Institute of Metrology and Testing This procedure entrusts the National Committee for Optical Metrology to explain The main drafters of this procedure. Generation color red (China Institute of Metrology) Wu Zhifeng (China Institute of Metrology) Zhang Baozhou (Beijing Normal University) Participate in the drafters. Wang Yanfei (China Institute of Metrology) Zhang qingxian (Beijing Institute of Metrology and Testing Science)

Introduction (II) 1 Scope (1) 2 References (1) 3 Overview (1) 4 Measurement performance requirements (1) 4.1 Spectral response and band division of the device (1) 4.2 Annual change rate of the device (2) 4.3 Operating Baseline Ultraviolet Radiation Illuminance Zero Error (Full Scale FS) (2) 4.4 working reference UV radiation illuminator long wave response error (2) 4.5 Working Baseline Ultraviolet radiation Illuminance meter cosine characteristics (directional response) (2) 4.6 Working standard Non-linearity error of ultraviolet radiation illuminometer (2) 4.7 Work reference UV radiation illuminometer shift error (2) 4.8 working reference UV radiation illuminance fatigue error (2) 4.9 working reference UV radiation illuminator maximum allowable relative error (2) 5 General technical requirements (2) 6 Metering device control (3) 6.1 Test conditions (3) 6.2 Test items (4) 6.3 Test method (5) 6.4 Processing of test results (10) 6.5 Test cycle (10) Appendix A Certificate of Verification and Verification Results Page Format (11) Appendix B Verification of the original record (12) Appendix C Working Basics UV Radiation Illuminance Meter Measurement Uncertainty Evaluation Example (UV-A Band) (14)

Introduction

JJF1001 "General Metrology Terms and Definitions", JJF1032 "Terminology and Definitions of Optical Radiometry" JJF1059.1 "Measurement Uncertainty Assessment and Representation" and JJF1002 "National Metrological Verification Rules" Constitute the basic norms that support the revision of this Code. Compared with JJG 755-1991, in addition to editorial changes, the main technical changes are as follows. --- Remove the "SUV-1" in the new procedure, change the UV radiation illuminometer to "working reference UV radiation illuminometer" (See 3); - on the basis of preserving the four bands of the original procedure (the UVB band of the original procedure is named in this procedure UV-310, UVA2 band named UV-365, UVC band named UV-254), the new International Lighting Commission The three bands proposed by CIE are. UV-A, UV-B and UV-C (see 4.1); --- Modification of the composition of the UV spectrum radiation illumination comparison device structure diagram (see 6.1.1.3 image 3); --- change the UV radiation intensity of the work of the reference device annual change rate, the working standard UV radiation illuminator zero Value error, long wave response error, cosine characteristic (directional response) error, nonlinear error, shift error, fatigue Error, relative indication error and other technical indicators (see 4.2 ~ 4.9) and the test method (see 6.3.3 ~ 6.3.10); - An example of measurement uncertainty assessment has been modified (see Appendix C). The previous release of this order is. --- JJG 755-1991. Verification procedure for the reference device of ultraviolet radiation

1 Scope

This procedure applies to the first test of the UV radiation exposure reference device, subsequent verification and inspection.

2 reference file

This procedure refers to the following documents. JJG 384 Spectral Radiance Illumination Standard Lamp For dated references, only the dated edition applies to this specification; references that are not dated , The latest version (including all modifications) applies to this specification.

3 Overview

International Council on Illumination CIE will be ultraviolet radiation is divided into UV-A (315nm ~ 400nm), UV-B (280nm ~ 315nm) and UV-C (100nm ~ 280nm) three bands. Due to 100nm ~.200nm UV radiation is strongly absorbed in the air, so for the UV-C band, this procedure only consider.200nm ~ 280nm Wavelength range. UV Radiation Illumination Work Benchmark Each band consists of three working reference UV radiation illuminometers. jobs The standard UV radiation illuminance meter is the transmission of UV-A, UV-B, UV-C, UV-A1, UV-365, UV- UV-254 and other wavelengths of ultraviolet radiation standard value of the standard instruments, mainly by the detector, amplifier circuit and display instruments composition. Where the detector is typically composed of a photodetector, a filter (band-pass glass or interference filter), and a diffuser group to make. Figure 1 is a schematic diagram of the general composition of the operating reference UV radiation illuminometer detector, whose magnitude is measured by spectral Radiometric comparison of alternative methods Trace to spectral radiance Illumination national benchmarks. Figure 1 Schematic diagram of the general composition of the working reference ultraviolet radiation illuminance detector

4 Measurement performance requirements

4.1 Spectral response and band division of the device UV-A band. 315nm ~ 400nm, peak wavelength λp = 365nm ± 5nm UV-B band. 280nm ~ 315nm, peak wavelength λp = 297nm ± 5nm UV-C band..200nm ~ 280nm, peak wavelength λp = 254nm ± 5nm UV-A1 band. 320nm ~ 390nm, peak wavelength λp = 365nm ± 5nm UV-365 band. peak wavelength λp = 365nm ± 2nm, peak half height width Δλ ≤ 10nm ......
