JJG 307-2006: Verification Regulation of Electromechanical Meters for Measuring Alternating-current Electrical Energy
Status: Valid

JJG 307: Historical versions

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
JJG 307-2006	1229	Add to Cart	7 days	Verification Regulation of Electromechanical Meters for Measuring Alternating-current Electrical Energy	Valid
JJG 307-1988	879	Add to Cart	6 days	Verification Regulation of Alternating Current Watthour Meters	Obsolete
JJG 307-1982	RFQ	ASK	3 days	(Chinese Industry Standard)	Obsolete

Similar standards

JJF 1234   JJG 229   JJG 376   JJG 843   JJG 314   JJG 313

Basic data

Standard ID: JJG 307-2006 (JJG307-2006)
Description (Translated English): Verification Regulation of Electromechanical Meters for Measuring Alternating-current Electrical Energy
Sector / Industry: Metrology & Measurement Industry Standard
Classification of Chinese Standard: A55
Classification of International Standard: 17.220
Word Count Estimation: 49,498
Date of Issue: 2006-03-08
Date of Implementation: 2006-09-08
Older Standard (superseded by this standard): JJG 307-1988
Issuing agency(ies): General Administration of Quality Supervision, Inspection and Quarantine
Summary: This standard applies to the reference frequency of 50Hz or 60Hz electromechanical (induction system) AC power meter (or meter short subjects meter) of the initial verification, not for energy meter on-site inspection. In accordance with the procedures in Appendix A, for electromechanical AC active energy meter for type evaluation test.

JJG 307-2006: Verification Regulation of Electromechanical Meters for Measuring Alternating-current Electrical Energy

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Verification Regulation of Electromechanical Meters for Measuring Alternating-current Electrical Energy National Metrology Verification Regulations of the People's Republic Electromechanical AC energy meter Released on.2006-03-08 2006-09-08 implementation The General Administration of Quality Supervision, Inspection and Quarantine issued Electromechanical AC electric energy meter verification procedures ElectricalEner Gy Replacing JJG 307-1988 This regulation was approved by the General Administration of Quality Supervision, Inspection and Quarantine on March 8,.2006, and since.2006. It will take effect on September 8th. Focal Point. National Electromagnetic Measurement Technical Committee Drafted by. Northeast Electric Power Research Institute Liaoning Institute of Metrology Shenyang Power Supply Company This procedure entrusts the National Electromagnetic Measurement Technical Committee to explain The main drafters of this procedure. Lan Yonglin (Northeast Electric Power Research Institute) Tang Hong (Liaoning Institute of Metrology) Sun Changhe (Northeast Electric Power Research Institute) Qi Zhong (Shenyang Power Supply Company) Participate in the drafters. Cui Jihong (Liaoning Institute of Metrology) Sun Shaowen (Northeast Electric Power Research Institute) Zhu Shuyuan (Northeast Electric Power Research Institute) Shanmeiyan (Shenyang Power Supply Company)

table of Contents

1 Scope (1) 2 Overview (1) 3 Metrological performance requirements (2) 3.1 Basic error (2) 3.2 Potential (2) 3.3 Start (2) 3.4 Constants (2) 4 General technical requirements (5) 4.1 signs (5) 4.2 AC withstand voltage (5) 5 measuring instrument control (5) 5.1 Type Evaluation (5) 5.2 First verification (5) 6 verification result processing (16) 6.1 Measurement data repair (16) 6.2 Verification (16) 7 rotation cycle (16) Appendix A Electromechanical AC Active Energy Meter Type Evaluation Test Outline (17) Appendix B Method for Evaluating Power Stability (35) Appendix C Verification of wiring diagram and calculation formula of wiring coefficient and power representation value (36) Appendix D Measurement Data Reduction Method (41) Electromechanical AC electric energy meter verification procedures

1 Scope

This procedure is applicable to electromechanical (induction system) AC energy meter with reference frequency of 50Hz or 60Hz (referred to as electric energy) The first test of the meter or the meter being tested does not apply to the on-site inspection of the meter. According to Appendix A of this regulation, the type evaluation test of electromechanical AC active energy meter is carried out.

2 Overview

The energy meter is used to measure AC active and reactive energy. Figure 1 is a simplified diagram of a single-phase electric energy meter measuring mechanism, the main group The components are described in the legend. Voltage and current cores stacked from silicon steel sheets, respectively wound with voltage coils and current lines ring. Phase voltage U of single-phase circuit Adding to the voltage coil, there is current I U flows through the coil and creates an aluminum turntable Alternating voltage working magnetic flux ΦU; load current flowing through current coil I , generating alternating current through the aluminum turntable Working magnetic flux ΦI. Voltage and current working magnetic flux with phase difference, passing through the turntable from different positions and inducing in the turntable Eddy current, each magnetic flux interacts with the eddy current to form a driving torque (average value) for driving the turntable to rotate. M=k1ΦUΦIsinΨ Fig.1 Schematic diagram of measuring mechanism of single-phase electric energy meter 1-brake magnet; 2-voltage coil; 3-current core; 4-current coil; 5-turntable; 6-turn shaft; 7-voltage core; 8-lower bearing; 9-upper bearing; 10-worm wheel; 11-worm; 12-return pole ......
