JJG 2054-2015 English PDF

US$259.00 · In stock
Delivery: <= 3 days. True-PDF full-copy in English will be manually translated and delivered via email.
JJG 2054-2015: Verification scheme of measuring instruments for vibration
Status: Valid

JJG 2054: Historical versions

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
JJG 2054-2015	259	Add to Cart	3 days	Verification scheme of measuring instruments for vibration	Valid
JJG 2054-1990	199	Add to Cart	2 days	Verification Scheme of Measuring Instruments for Vibration	Obsolete

Similar standards

JJF 1943   GB/T 36126   GB/T 1885   JJF 2044   JJF 2045   JJF 2054

Basic data

Standard ID: JJG 2054-2015 (JJG2054-2015)
Description (Translated English): Verification scheme of measuring instruments for vibration
Sector / Industry: Metrology & Measurement Industry Standard
Classification of Chinese Standard: A53
Classification of International Standard: 17.160
Word Count Estimation: 11,157
Date of Issue: 2015-04-10
Date of Implementation: 2015-10-10
Older Standard (superseded by this standard): JJG 2054-1990 (Partial)
Regulation (derived from): State Quality Inspection Administration Announcement 2015 No. 47
Issuing agency(ies): General Administration of Quality Supervision, Inspection and Quarantine
Summary: This Standard applies to the magnitude of the transmission of vibration measuring instruments, the provisions of the vibration of the composition and use of national benchmarks by the State through the reference standards of measurement values ??to the transmission of vibration measuring instruments work program, and the corresponding expanded uncertainty and The basic test methods. In carrying out the calibration, this standard can also be used as a basis for traceability. This Standard vibration frequency? (Hz), vibration acceleration �� (m/s2), the speed u (m/s), the displacement d (m) of the amplitude and phase �� (o) as described vibrational movement of the main physical quantities.

JJG 2054-2015: Verification scheme of measuring instruments for vibration

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Verification scheme of measuring instruments for vibration People's Republic of China National Metrological Verification System tables Vibration measuring instruments Issued on. 2015-04-10 2015-10-10 implementation The State Administration of Quality Supervision, Inspection and Quarantine released Vibration measuring instruments Verification System Replacing JJG 2054-1990 Focal point. the National Technical Committee of shock and vibration measurement speed Drafting units. China Institute of Metrology China Testing Technology Research Institute The national commission Verification System Shock vibration speed measurement technology committee responsible for the interpretation The main drafters Verification System. Love Left Bin (China Institute of Metrology) Yu Mei (China Institute of Metrology) Drafters participate. Zhu Sha (China Testing Technology Research Institute)

table of Contents

Introduction (Ⅲ) 1 Scope (1) 2 baseline measurement (1) 2.1 Vibration national benchmarks/slave reference means (1) 2.2 Vibration national secondary standard (1) 3 measurement standards (3) 3.1 Method absolute standard vibration means (3) 3.2 Vibration Standard comparison means (3) 3.3 shaker test device (4) 4 working measuring instruments (4) 4.1 the vibration sensor (5) 4.2 vibration measuring instrument (5) 4.3 laser vibrometer (5) 4.4 shaker (5) 5 Vibration Measuring Instruments System Tables Diagram (5)

Introduction

The verification system in substitution JJG 2054-1990 "vibration measuring instruments verification system." Compared with JJG 2054-1990, this verification system is a major technological change. 1) extended reference vibration frequency range extended from (0.1 ~ 50000) Hz to (~ 0.005 50000) Hz, displacement, velocity, acceleration corresponding extended range; 2) Remove the baseline measurement appliance for a description of the alignment; 3) Remove the measurement standard presentation standard vibration measuring instrument and standard vibration sensor; 4) the measurement standards, increasing the representation of shaking table test device; 5) working measuring instruments, increasing the laser vibrometer statements; 6) the expanded uncertainty by the coverage factor k = 3, to k = 2. Vibration measuring instruments Verification System

1 Scope

The verification system applicable to the magnitude of the transmission of vibration measuring instruments, the provisions of the national baseline vibration composition and use Way, passed by the national benchmarks to measure vibration measuring instruments work by standards of measurement procedures and the corresponding Uncertainty and basic test methods and other extensions. In carrying out calibration of the verification system can also be used as the traceability in accordance with. The Verification System to vibration frequency f (Hz), vibration acceleration a (m/s2), velocity v (m/s), displacement d (m) of the amplitude and phase φ (°) as described in vibrating motion main physical quantities.

2 baseline measurement

Vibration vibration measurement benchmarks include national benchmarks and national secondary standard vibration. 2.1 Vibration national benchmarks/Vice reference means 2.1.1 Vibration national benchmarks include ultra-low frequency vibration reference means, reference means low frequency vibration, frequency vibration reference means Means and dither reference means (hereinafter referred to as the base unit). 2.1.2 The device consists of a reference vibration generating system (including source, power amplifier, vibration table, etc.), laser altimetry Vibration System composition (including laser interferometer, data acquisition systems, etc.) and the necessary basis for isolation and so on. 2.1.3 reference means reproducible acceleration by sine law of motion, velocity, displacement amplitude and phase. its Laser measurement of absolute value, directly traceable to the International System of Units fundamental unit of length (m) and a single time Bit (s). 2.2 Vibration national secondary standard 2.2.1 Vibration national secondary standard reference means comprises a low-frequency vibration deputy, Vice reference means intermediate frequency vibration (hereinafter referred to as Deputy reference means). 2.2.2 secondary standard device consists of vibration generating system (including source, power amplifier, vibration table, etc.), laser Composition vibration system (including laser interferometer, data acquisition systems, etc.) and the necessary basis for isolation and so on. 2.2.3 Deputy reference means the magnitude of the reproduction method and reference means the same, the values should be regularly via standard laser vibrometer Instrument (including standard vibration measuring instrument) with a reference value means comparison. Vibration standard gauge by the vibration sensor standard , A suitable transfer instrument and display components. 2.2.4 Vibration measurement range and national benchmarks/secondary standard uncertainty are shown in Table 1. ......
