JJG 1153-2018 English PDF

US$329.00 · In stock
Delivery: <= 3 days. True-PDF full-copy in English will be manually translated and delivered via email.
JJG 1153-2018: Gauges for Measuring Distance between Inside Rim Faces of Wheels of Railway Locomotives and Vehicles
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
JJG 1153-2018	329	Add to Cart	3 days	Gauges for Measuring Distance between Inside Rim Faces of Wheels of Railway Locomotives and Vehicles	Valid

Similar standards

JJG 1114   JJF 1280   JJF 1126   JJG 1152   JJG 1155   JJG 1150

Basic data

Standard ID: JJG 1153-2018 (JJG1153-2018)
Description (Translated English): Gauges for Measuring Distance between Inside Rim Faces of Wheels of Railway Locomotives and Vehicles
Sector / Industry: Metrology & Measurement Industry Standard
Classification of Chinese Standard: A52
Classification of International Standard: 17.040
Word Count Estimation: 14,133
Date of Issue: 2018-06-25
Date of Implementation: 2018-09-25
Regulation (derived from): State Administration of Markets, Announcement No. 13 of 2018
Issuing agency(ies): State Administration for Market Regulation
Summary: This standard is applicable to the first verification, subsequent verification and in-use inspection of the wheel alignment of the railway locomotive (hereinafter referred to as the internal distance ruler).

JJG 1153-2018: Gauges for Measuring Distance between Inside Rim Faces of Wheels of Railway Locomotives and Vehicles

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Gauges for Measuring Distance between Inside Rim Faces of Wheels of Railway Locomotives and Vehicles National Metrology Verification Regulations of the People's Republic Railway locomotive wheel alignment Published on.2018-06-25 2018-09-25 implementation State Administration of Markets issued Railway locomotive wheelset Internal distance rule verification procedure Focal point. National railway special measuring instrument measurement technical committee for railway use Length subcommittee Main drafting unit. Harbin Railway Bureau Quality and Technical Supervision Office Xi'an Railway Bureau Quality and Technical Supervision Office Institute of Standard Metrology, China Academy of Railway Sciences Participated in the drafting unit. Liuzhou Kelu Measuring Instrument Co., Ltd. Tianjin Measuring Tool & Cutting Tools Co., Ltd. This regulation entrusts the national railway special measuring instrument measurement technical committee railway special length technology The committee is responsible for explaining The main drafters of this procedure. Dong Wei (Quality and Technical Supervision Institute of Harbin Railway Bureau) Ma Yong (Quality and Technical Supervision Institute of Xi'an Railway Bureau) Wang Yanchun (Standard Metrology Institute, China Academy of Railway Sciences) Participate in the drafters. Zhou Menglin (Standard Metrology Institute, China Academy of Railway Sciences) Xu Xiuren (Liuzhou Kelu Measuring Instrument Co., Ltd.) Zhang Xiaojian (Tianjin Measuring Tool & Cutting Co., Ltd.)

table of Contents

Introduction (II) 1 Scope (1) 2 Overview (1) 3 Metrological performance requirements (2) 3.1 Surface roughness (2) 3.2 The distance from the edge of the cursor marking surface to the marking surface of the main ruler (2) 3.3 Marker Width and Width Difference (2) 3.4 The coincidence of the cursor mark and the main rule mark (2) 3.5 Straightness of the ruler (2) 3.6 Straightness of the limit hook working surface (2) 3.7 Coplanarity of the working surface of the limit hook at both ends (2) 3.8 Distance and distance difference between the center line of the rod to the limit hook working surface (2) 3.9 Force (2) 3.10 repeatability (2) 3.11 indication error (2) 4 General technical requirements (2) 4.1 Appearance (2) 4.2 Interaction of various parts (3) 4.3 Graduation value or resolution (3) 5 measuring instrument control (3) 5.1 Verification conditions (3) 5.2 Verification project (4) 5.3 Verification method (4) 5.4 Processing of verification results (6) 5.5 Verification cycle (6) Appendix A Schematic diagram of the structural form of the wheel alignment gauge for railway locomotives (7) Appendix B Railway locomotive vehicle wheel alignment distance calibration record (8) Appendix C Format of verification certificate and verification result page (9)

Introduction

This regulation is based on JJF1002-2010 "Rules for the preparation of national metrological verification procedures", JJF1001-2011 Refer to the provisions of Measurement Terms and Definitions, and JJF1059.1-2012 "Measurement and Expression of Measurement Uncertainty". TB/T 1362-2017 "Special Measuring Tool for Locomotive Wheelsets" was formulated. This procedure is the first release. Railway locomotive vehicle wheel alignment gauge

1 Scope

This procedure is applicable to the first verification and subsequent verification of the distance between the wheelsets of railway locomotives (hereinafter referred to as the inner distance ruler). And check in use.

2 Overview

The internal distance gauge is a measuring instrument used to measure the distance inside the wheel of a railway locomotive. The measurement range is (1345~). 1365)mm, divided into integral and combined according to the structure, divided into cursor type and digital display according to the reading form (see Figure 1 and Figure 2). Figure 1 Schematic diagram of the vernier type internal distance ruler 1-activity rod; 2-limit hook; 3-reading device; 4-fastening screw; 5-foot body; 6-fixed rod Figure 2 Schematic diagram of the digital display internal distance ruler 1-activity rod; 2-limit hook; 3-reading device; 4-fastening screw; 5-foot body; 6-fixed rod ......
