JJG 1082.1-2013: Verififcation Regulation of Means of Measuring Instrument for Wheel-Diameter of Railway Locomotives and Vehicles. Part 1: Means of Ruler for Wheel-Diameter

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Verififcation Regulation of Means of Measuring Instrument for Wheel-Diameter of Railway Locomotives and Vehicles.Part 1. Means of Ruler for Wheel-Diameter State verification procedures People's Republic of China Railway rolling stock wheel diameter measuring gage Part 1. round foot diameter gage Part 1. MeansofRulerforWheel-Diameter Issued on. 2013-01-06 2013-04-06 implementation The State Administration of Quality Supervision, Inspection and Quarantine released Railway rolling stock wheel diameter measuring gage calibration Regulations Part 1. round foot diameter gage Part 1. Focal point. the National Railway special equipment metering metering technology committee Special railway length of the Technical Committee The main drafting units. the Ministry of Railways Institute of Measurement Standards Liuzhou Branch Road, measuring instruments limited liability company Participated in the drafting unit. Zhengzhou Railway Bureau of quality and technical supervision Wuhan Railway Bureau of quality and technical supervision This procedure entrust the national railway special equipment measurement technology committee railway length measurement technology division The Committee is responsible for interpreting surgery The main drafters of this procedure. Wang Yanchun (MOR Standards and Metrology Institute) Ancient Healer (Liuzhou Branch Road, measuring instruments limited liability company) Drafters participate. Hua Xia Wei (Zhengzhou Railway Bureau of quality and technical supervision) Chu Shusheng (Wuhan Railway Bureau of quality and technical supervision)

table of Contents

Introduction (Ⅱ) 1 Scope (1) 2 Overview (1) 3 metering performance requirements (1) Surface roughness 3.1 (1) Straightness 3.2 dipstick (1) 3.3 measuring tape jaws two parallel measuring surface (1) 3.4 measuring tape mark width (1) 3.5 measuring tape indication error (1) 3.6 the amount of rod length and the amount of change (1) 4 General Requirements (2) 4.1 Appearance (2) 4.2 Interaction of each part (2) 5 control of measuring instruments (2) 5.1 verification Conditions (2) 5.2 Verification Project (3) 5.3 Verification Methods (3) 5.4 test results processing (4) 5.5 test cycle (4) Appendix A foot diameter wheel railway vehicles seized a test record sheet (5) Appendix B calibration certificate and test results in the notice page format (6)

Introduction

JJG 1082 "railway rolling stock wheel diameter measuring gage" consists of two parts. --- Part 1. round foot diameter gage; --- Part 2. wheel diameter measuring gage. When using this procedure in Railway Locomotive wheel diameter measuring gage calibration, this Regulation should be selected according to the type of gage Cheng corresponding portions. This part of the contents on foot diameter wheel gage verification, according JJF1002-2010 "national verification regulations Cheng write rules ", JJG 1081.1-2013" railway rolling stock wheel diameter measuring Part 1. round foot diameter "and to Seeking compiled. This procedure was first formulated. Railway rolling stock wheel diameter measuring gages test procedures Part 1. round foot diameter gage

1 Scope

The order applies to railway rolling stock wheel foot diameter gage initial verification, use and subsequent verification check.

2 Overview

Indication foot diameter wheel railway vehicles Gage (hereinafter referred to as round foot diameter gage) is used to test Locomotive wheel diameter feet Error and center of the probe positioned at a distance to the surface, where the left and right wheel diameter measuring tape to measure the scale center of the probe to the vertical positioning block Straight from the positioning surface. Wheel diameter gage foot structure is shown in Figure 1. Figure 1 foot diameter gage structure diagram 1- floor; 2,3,4,5-foot diameter wheel positioning block; 6- the right foot box; 7- left foot box; 8- left measuring tape; 9- left cursor; 10,13,17- dipstick positioning block; 11- left locking screw; 12- right locking screw; 14- and right cursor; 15- the right measuring tape; 16- dipstick; 18- limit screw

3 metering performance requirements

3.1 surface roughness Face positioning block surface roughness Ra measuring tape and the upper limit is 0.8μm. Surface roughness measuring rod end face Ra upper limit is 0.4μm. Straightness of 3.2 dipstick Straightness measuring rod should be less than 0.1mm. 3.3 measuring tape jaws two parallel measuring surface Measuring tape jaws two parallel measuring surface should be less than 0.01mm. 3.4 mark width measuring tape Measuring tape main scale and vernier mark width of 0.08mm ~ 0.18mm, the width of the difference should be less than 0.05mm. 3.5 indication error measuring tape Left and Right indication error measuring tape should not exceed ± 0.04mm. 3.6 the amount of rod length and the amount of change Given the amount of the actual value of the length of the rod. Its length fluctuation amount dipstick should meet the requirements in Table 1. ......
