JJG 1000-2005: Verification regulation for electrodynamic horizontal vibration generator for testing

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Verification regulation for electrodynamic horizontal vibration generator for testing National Metrology Verification Regulations of the People's Republic Electric horizontal vibration test bench Released on.2005-09-05 Implementation of.2005-12-05 The General Administration of Quality Supervision, Inspection and Quarantine issued This regulation was approved by the General Administration of Quality Supervision, Inspection and Quarantine on September 5,.2005, and since.2005. It will take effect on December 5th. Focal Point. National Vibration, Shock and Rotating Speed Calculation Technical Committee Main drafting unit. Shaanxi Institute of Metrology and Testing Participated in the drafting of the unit. Institute 202 of the Ministry of Weapons Industry Beijing Institute of Metrology This regulation entrusts the National Vibration Shock Velocity Measurement Technical Committee to explain The main drafters of this procedure. Yang Jianhui (Shaanxi Institute of Metrology and Testing) Gu Guofu (Ordnance Industry 202th Institute) Li Xuerui (Beijing Institute of Metrology) Participate in the drafters. Wang Xiao (Shaanxi Institute of Metrology and Testing) Fifth Xingle (Shaanxi Institute of Metrology and Testing)

table of Contents

1 Scope (1) 2 Citations (1) 3 terms (1) 3.1 Electric horizontal vibration test bench (1) 3.2 Maximum overturning moment (1) 3.3 Maximum deflection torque (1) 4 Overview (1) 5 Metrological performance requirements (2) 5.1 Work surface tilt error (2) 5.2 Vibration frequency (2) 5.3 Vibration acceleration (or displacement) indication error (2) 5.4 Vibration acceleration stability (2) 5.5 Vibration acceleration waveform distortion (2) 5.6 Horizontal vibration table background noise acceleration (2) 5.7 Horizontal vibration table frequency response characteristics (2) 5.8 Mesa acceleration amplitude uniformity (2) 5.9 Table lateral vibration ratio (2) 5.10 Sweep rate and sweep tuning accuracy (3) 5.11 Other technical indicators (3) 6 General technical requirements (3) 6.1 Appearance and Accessories (3) 6.2 Horizontal vibration table working environment (4) 7 Measuring instrument control (4) 7.1 Verification conditions (4) 7.2 Verification project (4) 7.3 Verification method (4) 7.4 Processing of verification results (8) 7.5 Verification cycle (8) Appendix A Detection method of maximum overturning moment and maximum yaw moment of water smoothing table (9) Appendix B Certification Certificate Page Format (10) Appendix C Format of the verification result page (11) Electric horizontal vibration test bench verification procedures

1 Scope

This procedure is applicable to electric horizontal vibration test rigs with a sinusoidal thrust of 100 kN or less with a sliding table (below The first verification and subsequent verification of the horizontal vibration table.

2 Citations

JJG 948-1999 Digital Electric Vibration Test System JJG 190-1997 Electric Vibration Test Bench GB/T 11353-1989 Description of the characteristics of vibration generator auxiliary equipment JB/T 6869-1993 Horizontal vibration table (sinusoidal) technical conditions When using this procedure, care should be taken to use the current valid version of the above cited documents.

3 terms

3.1 Electric horizontal vibration test bench electrodynamichorizontalvibrationgeneratorfortest An electric vibration generator with a horizontal slide for vibration testing. 3.2 Maximum overturning moment Max.pitchmoment Under the condition that the horizontal vibrating table works normally, the applied dynamic force is generated in a longitudinal plane perpendicular to the mesa. The front and back overturning limit torque. 3.3 Maximum deflection torque Max.yawmoment The deflection limit of the applied dynamic force in the horizontal plane of the slide table under the condition that the horizontal vibration table is working normally Torque.

4 Overview

The horizontal vibration table is a device for generating horizontal vibration of the test piece. It and vibration controller, power amplification The instrument, accelerometer, adaptive amplifier and auxiliary equipment form a horizontal vibration test system (Fig. 1). Electric horizontal vibration The table is suitable for vibration test with large volume and heavy load. It can be divided into hydraulic guide and mechanical guide. Second class. Figure 1 Electric horizontal vibration test system ......
