JJF 1947-2021 English PDF

US$399.00 · In stock
Delivery: <= 4 days. True-PDF full-copy in English will be manually translated and delivered via email.
JJF 1947-2021: Calibration Specification for Platinum-Cobalt Colorimeters
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
JJF 1947-2021	399	Add to Cart	4 days	Calibration Specification for Platinum-Cobalt Colorimeters	Valid

Similar standards

JJF 1033   JJF 1050   JJF 1030

Basic data

Standard ID: JJF 1947-2021 (JJF1947-2021)
Description (Translated English): Calibration Specification for Platinum-Cobalt Colorimeters
Sector / Industry: Metrology & Measurement Industry Standard
Word Count Estimation: 17,171
Issuing agency(ies): State Administration for Market Regulation

JJF 1947-2021: Calibration Specification for Platinum-Cobalt Colorimeters

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Calibration Specification for Platinum-Cobalt Colorimeters National Metrology Technical Specification of the People's Republic of China Calibration Specification for Platinum-Cobalt Colorimeters Published on 2021-12-28 2022-06-28 Implementation Released by the State Administration for Market Regulation Calibration Specification for Platinum-Cobalt Colorimeters Focal Point. National Technical Committee of Physical Chemistry and Metrology Main drafting unit. Guangxi Zhuang Autonomous Region Metrology and Testing Research Institute Participating in the drafting unit. Suzhou Metrology and Testing Institute Shanghai INESA Scientific Instrument Co., Ltd. Hangzhou Caipu Technology Co., Ltd. Beijing Coast Hongmeng Standard Material Technology Co., Ltd. This specification is entrusted to the National Technical Committee of Physical Chemistry and Metrology to be responsible for the interpretation The main drafters of this specification. Feng Kerong (Guangxi Zhuang Autonomous Region Metrology and Testing Research Institute) Fan Xiaohui (Guangxi Zhuang Autonomous Region Metrology and Testing Research Institute) Wei Qiuye (Guangxi Zhuang Autonomous Region Metrology and Testing Research Institute) Participating drafters. Zhang Chengchun (Suzhou Metrology and Testing Institute) Jin Jianyu (Shanghai INESA Scientific Instrument Co., Ltd.) Yuan Kun (Hangzhou Caipu Technology Co., Ltd.) Dou Xiaoliang (Beijing Coast Hongmeng Standard Material Technology Co., Ltd.)

Table of contents

Introduction (Ⅱ) 1 Scope(1) 2 References (1) 3 Units of Measure(1) 4 Overview(1) 5 Metrology Characteristics(1) 5.1 Compatibility of cuvettes (1) 5.2 Platinum-cobalt chromaticity error(1) 5.3 Repeatability(1) 5.4 Indication drift(2) 6 Calibration Conditions(2) 6.1 Calibration ambient conditions(2) 6.2 Measurement standards and other equipment(2) 7 Calibration items and calibration methods (2) 7.1 Preparation before calibration(2) 7.2 Compatibility of cuvettes (2) 7.3 Platinum-cobalt chromaticity error(2) 7.4 Repeatability(3) 7.5 Indication drift(3) 8 Expression of calibration results (3) 9 Recalibration interval(4) Appendix A Preparation method of platinum-cobalt color series standard solution (5) Appendix B Calibration Raw Record Reference Format(6) Appendix C Calibration Certificate Inner Page Format(8) Appendix D Example of Calibration Uncertainty Evaluation of Platinum-Cobalt Chromaticity Error(9)

Introduction

JJF 1071-2010 "Rules for the Compilation of National Metrology Calibration Standards", JJF 1001-2011 "General Metrology Terms and Definition" and JJF 1059.1-2012 "Measurement Uncertainty Evaluation and Representation" together constitute the support for the preparation of this specification The basic series of specifications. This specification refers to ISO 6271.2015 "Platinum-Cobalt Grade Color for Transparent Liquids" (Clear Measurement requirements, the measurement unit adopts the platinum-cobalt chromaticity unit (Pt-CoUnit, PCU) in ISO 6271.2015. This specification is published for the first time. Calibration Specification for Platinum-Cobalt Colorimeters

1 Scope

This specification is applicable to platinum-cobalt color based on the principle of spectrophotometry and platinum-cobalt color within the measurement range of (0~500) Calibration of the meter.

2 Reference documents

This specification cites the following documents. GB/T 6682-2008 Specifications and test methods for water used in analytical laboratories ISO 6271.2015 Platinum-cobalt grading for color evaluation of transparent liquids (Clearliquids-Estimationof For dated references, only the dated version applies to this specification; for undated references The latest version (including all amendments) applies to this specification.

3 units of measure

The following definitions from ISO 6271.2015 apply to this specification. Platinum-cobalt chromaticity unit Pt-CoUnit, PCU The platinum-cobalt color unit is a unit containing defined concentrations of platinum [as the chloroplatinum(IV) salt ion] and chlorine Solution color of cobalt(II) hexahydrate.

4 Overview

Platinum-cobalt colorimeter (hereinafter referred to as colorimeter) is a kind of colorimeter designed based on the principle of spectrophotometry It can be used to measure and grade the chromaticity or color of liquid chemical products, water quality, turpentine and other liquids. Colorimeter is generally composed of light source, optical system, cuvettes, measurement chamber, photoelectric detection element and display unit. composition. It illuminates the sample to be tested through a light source, and the transmission spectrum of the liquid in the cuvette is converted into electrical energy by the photoelectric detection element. signal, the spectral transmittance of the sample to be measured is measured, and then processed by electronic components or software to directly calculate the sample to be measured The platinum-cobalt chromaticity value of the product is displayed by the display unit.

5 Metrology characteristics

5.1 Compatibility of cuvettes When the resolution (PCU) is less than or equal to 1, the compatibility (PCU) is less than or equal to 1; when the resolution (PCU) is greater than 1, the compatibility should be Does not cause a change in the indication value. 5.2 Platinum-Cobalt Chromaticity Error not more than ±10%. 5.3 Repeatability Not more than 2%FS. ......
