JJF 1884-2020: Calibration Specification for Electromagnetic Field Probes from 10 kHz to 100 MHz
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
JJF 1884-2020	689	Add to Cart	5 days	Calibration Specification for Electromagnetic Field Probes from 10 kHz to 100 MHz	Valid

Similar standards

JJF 1234 JJF 1396 JJG 376 JJF 1894 JJF 1893 JJF 1876

Basic data

Standard ID: JJF 1884-2020 (JJF1884-2020)
Description (Translated English): Calibration Specification for Electromagnetic Field Probes from 10 kHz to 100 MHz
Sector / Industry: Metrology & Measurement Industry Standard
Classification of Chinese Standard: A56
Classification of International Standard: 17.220
Word Count Estimation: 30,333
Date of Issue: 2020-11-26
Date of Implementation: 2021-05-26
Quoted Standard: IEEE STD 1309-2013
Regulation (derived from): Announcement No. 57 (2020) of the State Administration for Market Regulation
Issuing agency(ies): State Administration for Market Regulation
Summary: This standard specifies the calibration method of electromagnetic field probes (including electric field probes and magnetic field probes, referred to as field probes) in the frequency range of 10 kHz to 100 MHz, and is suitable for the calibration of field probes used in electromagnetic compatibility testing and other fields. Other types of field probes (except antennas) can also be used for reference.

JJF 1884-2020: Calibration Specification for Electromagnetic Field Probes from 10 kHz to 100 MHz

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Calibration Specification for Electromagnetic Field Probes from 10 kHz to 100 MHz National Metrology Technical Specifications of the People's Republic of China 10kHz~100MHz electromagnetic field probe Calibration specification from10kHzto100MHz 2020-11-26 release 2021-05-26 implementation Issued by the State Administration for Market Regulation 10kHz~100MHz electromagnetic field probe Calibration specification FieldProbesfrom10kHzto100MHz Focal point: National Radio Metrology Technical Committee Main drafting unit: China Institute of Metrology Participating in the drafting: Guangzhou Institute of Metrology and Testing Technology Liaoning Institute of Metrology This specification entrusts the National Radio Measurement Technical Committee to be responsible for interpretation The main drafters of this specification: Liu Xiao (China Institute of Metrology) Li Bo (China Institute of Metrology) Kong Yuling (Chinese Academy of Metrology) Participating drafters: Shen Renyi (Guangzhou Institute of Metrology and Testing Technology) Song Hao (Liaoning Institute of Metrology)

Introduction (Ⅱ) 1 scope (1) 2 Reference documents (1) 3 Terms and measurement units (1) 3:1 Field sensor(1) 3:2 Field probe(1) 3:3 Electric field probe (1) 3:4 Magnetic field probe (1) 3:5 Reading device (1) 4 Overview (1) 5 Measurement characteristics (2) 6 Calibration conditions (3) 6:1 Environmental conditions (3) 6:2 Measurement standards and other equipment (3) 7 Calibration items and calibration methods (4) 7:1 Calibration items (4) 7:2 Calibration method (5) 8 Calibration result expression (8) 9 Re-calibration interval (9) Appendix A Original Record Format (10) Appendix B Internal page format of calibration certificate (13) Appendix C Calibration Uncertainty Evaluation Examples of Major Items (16)

Introduction

This specification is based on JJF 1071-2010 "Rules for the Compilation of National Metrology and Calibration Specifications" and JJF 1059:1-2012 "Evaluation and Expression of Measurement Uncertainty" was compiled: This specification refers to IEEE1309-2013 "IEEEStandardforCalibrationofElectromagnetic FieldSensorsandProbes (ExcludingAntennas) from9kHzto40GHz" in the relevant clauses Line preparation: It mainly stipulates the calibration method of electromagnetic field probe with frequency range of 10kHz~100MHz: Calibration items include: electric field intensity, magnetic field intensity, magnetic induction intensity and isotropy: And the measurement is given in the appendix Example of uncertainty evaluation for This specification is released for the first time: 10kHz~100MHz electromagnetic field probe Calibration specification

1 Scope

This specification specifies the electromagnetic field probes (including electric field probes, magnetic field probes, etc:) in the 10kHz~100MHz frequency band: The calibration method called field probe is suitable for the calibration of field probes used in electromagnetic compatibility testing and other fields: Other types The field probe (except the antenna) can also be used as a reference:

2 Reference documents

This specification refers to the following documents: IEEEStd1309-2013 9kHz~40GHz electromagnetic field probe and sensor (except antenna) calibration [IEEEStandardforCalibrationofElectromagneticFieldSensorsandProbes(Excluding Antennas)from9kHzto40GHz]: For dated reference documents, only the dated version applies to this specification; for undated references The latest version (including all amendments) is applicable to this specification:

3 Terms and units of measurement

3:1 Field sensor fieldsensor An electrically small-sized device used to measure electric or magnetic fields, does not contain electronic components, and should have as little disturbance as possible The field being tested: Theoretically its transfer function (the ratio of the output signal to the input electromagnetic field) can be measured by its physical parameters Number and electrical properties of materials are obtained: 3:2 fieldprobe Contains a field sensor or a combination of several field sensors, diode detectors, resistors, amplifiers and other electronics Pieces: It is used to measure the radio frequency field component in a certain medium, and should disturb the measured field as little as possible: Theoretically The output cannot be obtained by simply measuring its physical parameters: Field probes include electric field probes and magnetic field probes: 3:3 E-fieldprobe A field probe capable of measuring the electric field strength E (unit: V/m): 3:4 H-fieldprobe It can measure the magnetic field intensity H (unit is A/m) or magnetic induction intensity B (unit is Wb/m2 or T) Field probe: Note: 1Wb/m2=1T=106μT: 3:5 readout device readoutdevice The output signal of the acquisition field probe is converted into a readable signal and sent to the electronic device of the data acquisition analyzer:

4 overview

Field probes are usually divided into passive and active two types: passive field probes include field sensors, diode detectors and high-impedance transmitters: ......
