JJF 1765-2019: Program of Pattern Evaluation of UV Radiometers
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
JJF 1765-2019	819	Add to Cart	6 days	Program of Pattern Evaluation of UV Radiometers	Valid

Similar standards

JJG 879   JJF 1106   JJG 810   JJF 1772   JJF 1773   JJF 1755

Basic data

Standard ID: JJF 1765-2019 (JJF1765-2019)
Description (Translated English): Program of Pattern Evaluation of UV Radiometers
Sector / Industry: Metrology & Measurement Industry Standard
Classification of Chinese Standard: A60
Classification of International Standard: 17.180
Word Count Estimation: 38,320
Date of Issue: 2019
Date of Implementation: 2019-12-27
Issuing agency(ies): State Administration for Market Regulation

JJF 1765-2019: Program of Pattern Evaluation of UV Radiometers

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
(Outline of Type Evaluation of Ultraviolet Radiometer) National Metrology Technical Specifications of the People's Republic of China Type Evaluation Outline of Ultraviolet Irradiance Meter 2019-09-27 released 2019-12-27 Implementation Issued by the State Administration for Market Regulation Type Evaluation Outline of Ultraviolet Irradiance Meter Focal point. National Optical Metrology Technical Committee Main drafting unit. China Institute of Metrology Beijing Normal University Participating in the drafting unit. China Institute of Metrology China Testing Technology Research Institute Shenzhen Institute of Metrology and Quality Inspection Xiamen Metrological Verification and Testing Institute This specification entrusts the National Optical Metrology Technical Committee to be responsible for the interpretation The main drafters of this specification. Dai Caihong (China Institute of Metrology) Wang Yanfei (China Institute of Metrology) Zhang Baozhou (Beijing Normal University) Participating drafters. Wu Zhifeng (China Institute of Metrology) Zeng Limei (China Testing Technology Research Institute) Li Xiangzhao (Shenzhen Institute of Metrology and Quality Inspection) Ruan Yujiao (Xiamen Metrological Inspection and Testing Institute)

table of Contents

Introduction (Ⅱ) 1 scope (1) 2 Reference documents (1) 3 Term (1) 4 Overview (1) 5 Legal management requirements (2) 5.1 Unit of measurement (2) 5.2 Requirements for the marking of measurement legal system and the marking of measuring instruments (2) 6 Measurement requirements (2) 6.1 Spectral response and band division (2) 6.2 Zero error (3) 6.3 Long wave response error (3) 6.4 Cosine characteristic (directional response) error(3) 6.5 Linearity error(3) 6.6 Shift error (3) 6.7 Fatigue error(4) 6.8 Maximum allowable relative indication error (4) 7 General technical requirements (4) 7.1 Appearance and structure (4) 7.2 Electrical safety(4) 7.3 Environmental adaptability (5) 8 Type evaluation item list (5) 9 Provide the number of prototypes and how to use the prototypes (6) 9.1 Number of prototypes provided (6) 9.2 How to use the prototype (7) 10 Test methods and conditions of test items, data processing and qualification criteria (7) 10.1 Measurement requirements(7) 10.2 General technical requirements (14) 11 List of measuring instruments and equipment used in test items (20) 12 Problems that should be paid attention to in type evaluation (21) 13 Judgment of type evaluation results (22) 14 Type evaluation original record format (22) Appendix A Original Record Format of Type Evaluation of Ultraviolet Irradiance Meter (23)

Introduction

This type evaluation outline is based on JJF 1015-2014 "General Specification for Type Evaluation of Measuring Instruments" and JJF 1016- The.2014 "Guidelines for the Compilation of the Type Evaluation Outline for Measuring Instruments" was prepared as a basic specification. The technical indicators of this type evaluation outline refer to the verification regulations of JJG879-2015 "Ultraviolet Irradiance Meter". This type evaluation outline is released for the first time. Type Evaluation Outline of Ultraviolet Irradiance Meter

1 Scope

This type evaluation outline is applicable to UV-A, UV-B, UV-C, UV-A1, UV-365, UV-310, UV- Type evaluation of 254-band ultraviolet illuminance meter.

2 Reference documents

This specification refers to the following documents. JJG755-2015 UV radiation illuminance working standard device verification regulation JJG879-2015 UV radiation illuminance meter verification regulations JJF 1032-2005 Terms and definitions of optical radiation measurement GB 4793.1 Safety requirements for electrical equipment for measurement, control and laboratory use Part 1.General requirements GB/T 11606-2007 Environmental test methods for analytical instruments GB/T 12085.2-2010 Optical and optical instrument environmental test method Part 2.Low temperature, high temperature, Damp heat For dated reference documents, only the dated version applies to this specification; for undated references The latest version (including all amendments) is applicable to this specification.

3 term

3.1 Long-wavelength range response characteristics long-wavelengthrangeresponsecharacteristics Describe the long-wavelength spectral response characteristics of the ultraviolet radiometer outside the spectral response wavelength range. 3.2 cosine (directional response) characteristics cosine (directional response) characteristics Describe the response characteristics of the ultraviolet illuminance meter when the angle of the incident light deviates from the normal incidence (the law of cosine).

4 overview

The International Commission on Illumination (CIE) divides ultraviolet radiation into UV-A (315nm~400nm), UV-B (280nm~315nm) and UV-C (100nm~280nm) three bands. Since 100nm~200nm Ultraviolet radiation is strongly absorbed in the air, so for the UV-C band, this outline only considers.200nm~280nm The test in the wavelength range is suitable for the measurement of the UV-C band in the air, but not for the measurement in the vacuum. Figure 1 Schematic diagram of the general composition structure of the UV illuminance meter detector Comply with ultraviolet radiation UV-A, UV-B, UV-C, UV-A1, UV-365, UV-310, UV-254 bands ......
