JJF 1737-2019 English PDF

Q: How long will the true-PDF of English version of JJF 1737-2019 be delivered?

Upon your order, we will start to translate JJF 1737-2019_English as soon as possible, and keep you informed of the progress. The lead time is typically 2 ~ 4 working days. The lengthier the document the longer the lead time.

Q: Can I share the purchased PDF of JJF 1737-2019_English with my colleagues?

Yes. The purchased PDF of JJF 1737-2019_English will be deemed to be sold to your employer/organization who actually pays for it, including your colleagues and your employer's intranet.

Q: Does the price include tax/VAT?

Yes. Our tax invoice, downloaded/delivered in 9 seconds, includes all tax/VAT and complies with 100+ countries' tax regulations (tax exempted in 100+ countries). Avoidance of Double Taxation Agreements (DTAs) between Singapore and 100+ Countries: https://www.iras.gov.sg/taxes/international-tax

Q: Do you accept my currency other than USD?

Yes. If you need your currency to be printed on the invoice, please write an email to Sales@ChineseStandard.net. In 2 working-hours, we will create a special link for you to pay in any currencies. Otherwise, follow the normal steps: Add to Cart -- Checkout -- Select your currency to pay.

US$369.00 · In stock
Delivery: <= 4 days. True-PDF full-copy in English will be manually translated and delivered via email.
JJF 1737-2019: Calibration Specification for Power Frequency Magnetic Field Simulators
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
JJF 1737-2019	369	Add to Cart	4 days	Calibration Specification for Power Frequency Magnetic Field Simulators	Valid

Similar standards

JJF 1234 JJF 1396 JJG 376 JJF 1741 JJF 1742 JJF 1740

Basic data

Standard ID: JJF 1737-2019 (JJF1737-2019)
Description (Translated English): Calibration Specification for Power Frequency Magnetic Field Simulators
Sector / Industry: Metrology & Measurement Industry Standard
Classification of Chinese Standard: A56
Classification of International Standard: 17.220
Word Count Estimation: 16,165
Date of Issue: 2019
Date of Implementation: 2019-12-27
Issuing agency(ies): State Administration for Market Regulation

JJF 1737-2019: Calibration Specification for Power Frequency Magnetic Field Simulators

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Calibration Specification for Power Frequency Magnetic Field Simulators National Measurement Technical Specification of the People's Republic of China Calibration Specification of Power Frequency Magnetic Field Simulator 2019-09-27 release 2019-12-27 Implementation Issued by the State Administration of Market Supervision and Administration Calibration Specification of Power Frequency Magnetic Field Simulator Focal point. National Radio Measurement Technical Committee Main drafting unit. Liaoning Institute of Metrology Chinese Academy of Metrology Participated in the drafting unit. Jiangsu Institute of Metrology Guangdong Academy of Metrology Shanghai Institute of Metrology and Testing Technology This specification is entrusted to the National Radio Measurement Technical Committee for interpretation The main drafters of this specification. Tang Hong (Liaoning Institute of Metrology) Bai Bing (Chinese Academy of Metrology) Hao Song (Liaoning Institute of Metrology) Participating drafters. Zhao Pinzhang (Jiangsu Institute of Metrology) Liu Wengang (Guangdong Institute of Metrology) Jiansheng Zuo (Shanghai Institute of Metrology and Testing Technology)

Introduction (Ⅱ) 1 Scope (1) 2 References (1) 3 Terms and units of measurement (1) 4 Overview (1) 5 Metrological characteristics (2) 5.1 Current (2) 5.2 Magnetic field strength (2) 5.3 Magnetic field uniformity (2) 6 Calibration conditions (2) 6.1 Environmental conditions (2) 6.2 Measurement standards and other equipment (2) 7 Calibration items and calibration methods (3) 7.1 Appearance and work normality inspection (3) 7.2 Current (3) 7.3 Magnetic field strength (3) 7.4 Magnetic field uniformity (4) 8 Expression of calibration results (4) 9 Recalibration time interval (5) Appendix A Original Record Format (6) Appendix B. Internal page format of the calibration certificate (8) Appendix C Examples of calibration uncertainty assessment of main items (9)

Introduction

This specification is based on JJF 1071-2010 "Rules for Compiling National Measurement and Calibration Specifications" and JJF 1059.1-2012 The preparation of the "Measurement Uncertainty Evaluation and Expression". This specification refers to GB/T 17626.8 "Electromagnetic compatibility test and measurement technology power frequency magnetic field immunity test" And IEC 61000-4-8..2009 "Electromagnetic Compatibility (EMC) Part 4-8.Test and Measurement Technology Power Frequency The relevant clauses in "Magnetic Field Immunity Test" are prepared. This specification is the first release. Calibration Specification of Power Frequency Magnetic Field Simulator

1 Scope

This specification is applicable to power frequency magnetic field immunity according to GB/T 17626.8 "Electromagnetic Compatibility Test and Measurement Technology" Test "and IEC 61000-4-8..2009" Electromagnetic Compatibility (EMC) Part 4-8.Test and Measurement Technology The calibration of the power frequency magnetic field simulator required in the Power Frequency Magnetic Field Immunity Test is also applicable to the comprehensive EMC immunity The calibration of the power frequency magnetic field simulator part in the test system.

2 Reference documents

This specification refers to the following documents. GB/T 17626.8 EMC test and measurement technology power frequency magnetic field immunity test IEC 61000-4-8..2009 Electromagnetic Compatibility (EMC) Part 4-8.Test and Measurement Technology Power Frequency Electromagnetic Compatibility (EMC) -Part 4-8.Testing and measurementtechniques-Powerfrequencymagneticfieldimmunitytest) For dated reference documents, only the dated version applies to this specification; for those without date references The latest version (including all amendments) is applicable to this specification.

3 Terms and units of measurement

3.1 Inductive coil A conductor ring with a certain shape and size, when current flows through the ring, it is generated in its plane and the enclosed space Definite magnetic field. 3.2 Inductive coil factor The ratio of the magnetic field strength generated by the induction coil of a certain size to the corresponding current. In the case of equipment, measured at the center of the coil plane. 3.3 Standard induction coil standardinductivecoil Induction coil with 1 turn and size of 1m × 1m or 1m × 2.6m.

4 Overview

The power frequency magnetic field simulator is generally composed of a power frequency current generator and an induction coil. Among them, the main frequency current generator It should be composed of voltage regulator, control loop and current transformer; the induction coil is made of copper, aluminum or other conductive non-magnetic materials Material. The power frequency magnetic field simulator is mainly used to simulate the influence of the magnetic field generated by the power frequency current on the equipment under operating conditions. Check the ability of the tested electronic equipment to resist power frequency magnetic fields. ......
