JJF 1640-2017 English PDF

Q: How long will the true-PDF of English version of JJF 1640-2017 be delivered?

Upon your order, we will start to translate JJF 1640-2017_English as soon as possible, and keep you informed of the progress. The lead time is typically 4 ~ 6 working days. The lengthier the document the longer the lead time.

Q: Can I share the purchased PDF of JJF 1640-2017_English with my colleagues?

Yes. The purchased PDF of JJF 1640-2017_English will be deemed to be sold to your employer/organization who actually pays for it, including your colleagues and your employer's intranet.

Q: Does the price include tax/VAT?

Yes. Our tax invoice, downloaded/delivered in 9 seconds, includes all tax/VAT and complies with 100+ countries' tax regulations (tax exempted in 100+ countries). Avoidance of Double Taxation Agreements (DTAs) between Singapore and 100+ Countries: https://www.iras.gov.sg/taxes/international-tax

Q: Do you accept my currency other than USD?

Yes. If you need your currency to be printed on the invoice, please write an email to Sales@ChineseStandard.net. In 2 working-hours, we will create a special link for you to pay in any currencies. Otherwise, follow the normal steps: Add to Cart -- Checkout -- Select your currency to pay.

US$859.00 · In stock
Delivery: <= 6 days. True-PDF full-copy in English will be manually translated and delivered via email.
JJF 1640-2017: Program of Pattern Evaluation for Piezoresistive Pressure Sensors(Static)
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
JJF 1640-2017	859	Add to Cart	6 days	Program of Pattern Evaluation for Piezoresistive Pressure Sensors(Static)	Valid

Similar standards

GB/T 36126 JJF 1368 GB/T 1885 JJF 1635 JJF 1639 JJF 1633

Basic data

Standard ID: JJF 1640-2017 (JJF1640-2017)
Description (Translated English): Program of Pattern Evaluation for Piezoresistive Pressure Sensors(Static)
Sector / Industry: Metrology & Measurement Industry Standard
Classification of Chinese Standard: A53
Word Count Estimation: 37,365
Date of Issue: 2017-09-26
Date of Implementation: 2017-12-26
Regulation (derived from): General Administration of State Quality Inspection Announcement 2017 No. 78
Issuing agency(ies): General Administration of Quality Supervision, Inspection and Quarantine

JJF 1640-2017: Program of Pattern Evaluation for Piezoresistive Pressure Sensors(Static)

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
(Piezoresistive pressure sensor (static) type evaluation outline) People's Republic of China National Measurement Specifications Piezoresistive pressure sensor (static) Type evaluation outline Program of Pattern Evaluation PiezoresistivePressureSensors (Static) 2017-09-26 Posted 2017-12-26 Implementation General Administration of Quality Supervision, Inspection and Quarantine released Piezoresistive pressure sensor (static) Type evaluation outline Program of Pattern Evaluation PiezoresistivePressureSensors (Static) The focal point. National pressure measurement technical committee The main drafting unit. Shaanxi Institute of Metrology Xi'an Jiaotong University Shanghai Hao Ge Group Co., Ltd. Participate in the drafting unit. Jiangxi Province Institute of Measurement and Testing This specification entrusts the national pressure measurement technical committee to explain The main drafters of this specification. Wang Hongyan (Shaanxi Institute of Metrology) Zhao Yulong (Xi'an Jiaotong University) Guan Weijun (Shaanxi Provincial Institute of Metrology) Hao Wu (Shanghai Hao Ge Group Co., Ltd.) Participate in the drafters. Zhao Libi (Xi'an Jiaotong University) Han Fei (Shaanxi Provincial Institute of Metrology) Zhang Xinlin (Jiangxi Institute of Measurement and Testing)

Introduction (Ⅲ) 1 Scope (1) 2 References (1) 3 Terms (1) 4 Overview (2) 5 Legal Management Requirements (2) 5.1 unit of measure (2) 5.2 Accuracy level (2) 5.3 Metering of legal signs and measuring equipment logo (2) 5.4 installation signs (2) 5.5 Test prototype (2) 6 measurement requirements (3) 6.1 Accuracy level and the maximum allowable error (3) 6.2 Repeatability (3) 6.3 Hysteresis (3) 6.4 Nonlinear (3) 7 General technical requirements (3) 7.1 Appearance (3) 7.2 Electrical Characteristics (4) 7.3 Zero drift (4) 7.4 Temperature effects (4) 7.5 Vibration (4) 7.6 Shock (5) 7.7 Static pressure effect (only for differential pressure sensor) (5) 7.8 Static overload (5) 7.9 Fatigue life (5) 7.10 damp heat effect (5) 7.11 external magnetic field (5) 8 type evaluation items (5) 9 Test conditions and test methods (6) 9.1 Test conditions (6) 9.2 Test points (7) 9.3 Appearance (7) 9.4 Repeatability (8) 9.5 Hysteresis (8) 9.6 Nonlinearity (8) 9.7 Basic error (9) 9.8 Electrical Performance (10) 9.9 Zero Drift (11) 9.10 Temperature effects (11) 9.11 Vibration test (12) 9.12 Impact test (13) 9.13 Static Pressure Effects (Differential Pressure Sensors Only) (13) 9.14 Static overload (14) 9.15 Fatigue life test (14) 9.16 Damp heat effects (15) 9.17 external magnetic field (15) 10 type evaluation results of the decision principle (16) 11 Type Evaluation Record Format (16) Appendix A Pressure sensor data processing and calculation method (17) Appendix B Pressure Sensor Type Evaluation Recording Format (22)

Introduction

JJF 1015 "General Specification for Evaluation of Measurement Instruments", JJF 1016 "Guide for Evaluation of Measurement Instruments Then, "JJF 1001" common measurement terms and definitions ", JJF 1059.1" Measurement Uncertainty Evaluation and Expression "common Constitute the norms of the formulation of the basic series of norms. Piezoresistive pressure sensors have developed very rapidly in recent decades as a new physical property sensor. It has spirit High sensitivity, fast response, good reliability, high accuracy, low power consumption, easy to miniaturization and integration of a series of sudden Out of advantages. Piezoresistive pressure sensor works is the use of piezoresistive effect, the measured pressure in accordance with certain laws into A certain relationship between the electrical signal output. The application of piezoresistive pressure sensors as pressure measurement of the growing industry, in the production of piezoresistive pressure Sensors have taken the lead in the pressure sensor market. The outline of a clear piezoresistive pressure sensor type evaluation of the scope and application of the conditions of the piezoresistive pressure transmission Sensor legal management requirements, measurement requirements, general technical requirements made clear the provisions of a detailed test items The purpose of the test conditions and test methods, clear type evaluation results of the decision principle. The outline of the data used by the processing and calculation methods cited JJG860-2015 "pressure sensor (static) inspection Set procedures. " Piezoresistive pressure sensor (static) Type evaluation outline

1 Scope

This type of evaluation program for the measurement range of (-0.1 ~ 250) MPa piezoresistive pressure sensor (static State) (hereinafter referred to as the sensor) type evaluation.

2 reference documents

This specification cites the following documents. JJG860-2015 pressure sensor (static) GB/T 2423.1-2008 Environmental testing for electric and electronic products Part 2. Test methods Test A. Low temperature GB/T 2423.2-2008 Environmental testing for electric and electronic products Part 2. Test methods Test B. high temperature GB/T 2423.3-2016 Environmental testing Part 2. Test methods Test Cab. Constant hot and humid test GB/T 2423.5 Environmental testing for electric and electronic products Part 2. Test methods Test Ea and guidance. Impact GB/T 2423.10 Environmental testing for electric and electronic products Part 2. Test methods Test Fc. Vibration (Sine) GB/T 15478 pressure sensor performance test methods JB/T 6170 pressure sensor For dated references, only the dated version applies to this specification; for undated references The latest version (including all amendments) applies to this specification.

3 Terms

3.1 zero drift zerodrift Under normal operating conditions and the provisions of the time interval, the zero indication drift. [JJF 1008-2008 definition 5.21] 3.2 zero (bit) output zerooutput Under normal operating conditions, enter the indication of the zero (bit) output when it is zero. [JJF 1008-2008 definition 5.20] 3.3 full-scale output ful-spanoutput The absolute value of the difference between the pressure sensor measurement upper limit output and the measurement lower limit output. [JB/T 6170-2006] 3.4 thermal zero offset thermalzerooffset Zero indication shift due to ambient temperature change. ......
