JJF 1517-2015: Calibration Specification for Contactless Electrostatic Voltage. Measuring Instruments
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
JJF 1517-2015	489	Add to Cart	4 days	Calibration Specification for Contactless Electrostatic Voltage. Measuring Instruments	Valid

Similar standards

JJF 1234   JJF 1576   JJG 376   JJF 2000   JJF 1519   JJF 1516

Basic data

Standard ID: JJF 1517-2015 (JJF1517-2015)
Description (Translated English): Calibration Specification for Contactless Electrostatic Voltage. Measuring Instruments
Sector / Industry: Metrology & Measurement Industry Standard
Classification of Chinese Standard: A55
Word Count Estimation: 21,280
Date of Issue: 2015-04-10
Date of Implementation: 2015-07-10
Regulation (derived from): State Quality Inspection Administration Announcement 2015 No. 47
Issuing agency(ies): General Administration of Quality Supervision, Inspection and Quarantine
Summary: This Standard applies to the measurement of the surface voltage not exceeding 20kV electrostatic voltage non-contact measuring instrument (also known as non-contact electrostatic voltmeter, hereinafter referred to as static tables) calibration. This specification does not apply to contact electrostatic voltage meter calibration.

JJF 1517-2015: Calibration Specification for Contactless Electrostatic Voltage. Measuring Instruments

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Calibration Specification for Contactless Electrostatic Voltage.Measuring Instruments People's Republic of China National Metrology Technical Specifications Non-contact electrostatic voltage meter calibration specification Issued on. 2015-04-10 2015-07-10 implementation The State Administration of Quality Supervision, Inspection and Quarantine released Non-contact electrostatic voltage Measuring instrument calibration specification Focal point. the National Technical Committee of the electromagnetic high-pressure metering metering Technical Committee Drafting. Jiangsu Institute of Metrology Beijing Oriental Institute of Metrology The national high voltage metering station Anhui Institute of Metrology Hubei Electric Power Company State Grid Electric Power Research Institute This specification commissioned the National Technical Committee of the electromagnetic high-pressure metering metering Technical Committee is responsible for interpretation The main drafters of this specification. Pan Baoxiang (Jiangsu Province Institute of Metrology) Liu Min (Beijing Oriental Institute of Metrology) Wang Haiyan (the national high voltage metering station) Luo Zhaoyu (Anhui Institute of Metrology) Wang Yongqin (Hubei Electric Power Company State Grid Electric Power Research Institute) Drafters participate. Zhu Jie (Jiangsu Province Institute of Metrology) Wei Jian (Jiangsu Province Institute of Metrology)

table of Contents

Introduction (Ⅱ) 1 Scope (1) 2 terminology and units of measurement (1) 2.1 Test distance (1) 2.2 standard plate electrode (1) 3 Overview (1) 4 Metrological characteristics (1) 4.1 electrostatic voltage basic error (1) 4.2 Voltage indication of short-term stability (2) Calibration Condition 5 (2) 5.1 environmental conditions (2) 5.2 standards and other measuring equipment (2) 6 calibration items and calibration methods (4) 6.1 Calibration item (4) 6.2 Calibration preparation (4) 6.3 Calibration method (4) 7 Calibration result expression (5) 8 recalibration intervals (6) Appendix A Measurement Uncertainty Example (7) Appendix B Calibration original record format (11) Appendix C calibration certificate page format (12) Appendix D standard test plate electrode (14)

Introduction

This specification based JJF 1071-2010 "National Calibration Specifications writing rules", IEC 61340-5-1-1998 "Electronic components protection under static environment General requirements" relevant provisions of the preparation. This specification is the first release. Non-contact electrostatic voltage meter calibration specification

1 Scope

This specification is suitable for measuring the surface voltage not exceeding 20kV non-contact electrostatic voltage measuring instrument (also available Called non-contact electrostatic voltmeter, hereinafter referred to as static tables) calibration. This specification does not apply to contact electrostatic voltage meter calibration.

2 terminology and units of measurement

2.1 Test distance testingdistance In the non-contact measurement, the measured surface and measuring instruments forefront of distance or measuring instruments defined in the specification distance. 2.2 standard plate electrode standardplateelectrode Connecting a standard high voltage power supply, and the edge of the insulation through the metal plate smooth process. In the center of the panel Near the flat surface, parallel to the normal direction of a uniform electrostatic field exists, the voltage on the metal plate can be marked Voltmeter readings or quasi-standard high-voltage power supply is set to determine.

3 Overview

Static table is a method for measuring the electrostatic potential of the surface of the ground equipment. Not in contact with the measured surface situation Under conditions, the use of electric field sensing principle or other principles, the measured voltage value surface. This voltage is infinity or earth A zero reference potential. Static tables are typically by an electric field sensor, a distance indicator, measuring unit, display unit and zero units, have These static tables have a ground terminal. The most common induction electric field sensor capacitive, rotor voltmeter and oscillating capacitor Type and so on. Static table instructions can be divided by distance and distance with a positioning indicator without distance indicator both targeting; press was Shows can be divided into two kinds of pointer and a digital display.

4 Metrological characteristics

4.1 electrostatic voltage basic error The basic error of static table into digital display and basic error pointer display two types of basic error, which is available under the formula One column in the form of representation. Absolute error 4.1.1 Digital Display Δ = ± (a% Ux b% Um) (1) Where. Δ --- basic error limit represents the absolute error, V; a --- error coefficient associated with the reading; ......
