Calibration Specification for High Speed Serial BERT People's Republic of China National Metrology Technical Specifications High-speed serial BERT calibration specification Issued on. 2014-11-17 2015-02-17 implementation The State Administration of Quality Supervision, Inspection and Quarantine released High-speed serial BERT calibration specification Focal point. the National Radio Technical Commission metering Drafting unit. Hubei Provincial Institute of Measurement and Testing Industry and Information Technology Ministry of Communications Measurement Center This specification commissioned the National Radio Technical Commission responsible for the interpretation of measurement The main drafters of this specification. Ge Hisashi (Hubei Institute of Measurement and Testing) DR (Industry and Information Technology Ministry of Communications Measurement Center) Jantje (Hubei Institute of Measurement and Testing) Drafters participate. Wang Yanfeng (Hubei Institute of Measurement and Testing) Qinhuai Ming (Ministry of Industry and Information Technology Telecommunication Metrology Center)

table of Contents

Introduction (Ⅱ) 1 Scope (1) 2. References (1) 3 Overview (1) 4 Metrological characteristics (1) 4.1 synthesized clock source (1) 4.2 the pulse pattern generator (2) 4.3 Functional (2) Calibration Condition 5 (2) 5.1 environmental conditions (2) 5.2 Calibration Equipment (2) 6 calibration items and calibration methods (3) 6.1 calibration items (3) 6.2 Calibration method (3) 7 Calibration result expression (9) 8 Recalibration interval (9) Appendix A high-speed serial BERT optical interface (10) Appendix B high-speed serial BERT calibration original record format (15) Appendix C in the high-speed serial BERT calibration certificate page format (20) Appendix D high-speed serial BERT (optical interface) calibration original record format (25) Appendix E high-speed serial BERT (optical interface) within a calibration certificate page format (27) Appendix F high speed serial BERT Uncertainty Analysis Report (29) Appendix G high-speed serial BERT (optical interface) Calibration Uncertainty Analysis Report (35)

Introduction

This specification based JJF 1071-2010 "National Calibration Specifications writing rules" establishment. This specification is the first release. High-speed serial BERT calibration specification

1 Scope

This instruction applies to rate 100Mbit/s ~ 12.5Gbit speed serial BERT calibration within the range of s /. Other similar instrument calibration can also be implemented by reference. 2. References This specification references the following documents. ITU-T Recommendation O.150 (05/96) Digital transmission equipment performance measuring instruments - General requirements (GeneralRe- quirementsforInstrumentationforPerformanceMeasurementsonDigitalTransmission Equipment) For dated references, only the dated edition applies to this specification; undated reference documents Member, the latest edition (including any amendments) applies to this specification.

3 Overview

High-speed serial BERT is the instrument for high-speed digital communications components and system error performance tests, the basic structure As shown in Figure 1. High-speed serial BERT generally made of synthetic clock source (synthesizer), pulse pattern generator (PPG), the error detector (ED) and optical modules. High-speed serial BERT calibration includes calibration and electrical parameters Optical calibration parameters, optical parameters refer to Appendix A calibration method can be. 1 high-speed serial BERT basic structure diagram

4 Metrological characteristics

4.1 synthesized clock source 4.1.1 the reference clock frequency Range. 100MHz ~ 12.5GHz; the maximum permissible error. ± 1 × 10-5. 4.1.2 Signal Rise, Fall Time Less than 80ps (20% with 80% amplitude of Zhi). 4.1.3 Signal amplitude-frequency characteristics ± 15% or ± 0.1V, whichever is greater.
......
